Specac Atlas Autotouch 8Ton User Manual

Hydraulic presses
Hide thumbs Also See for Atlas Autotouch 8Ton:

Advertisement

Quick Links

Download this manual
Atlas™ Autotouch 8Ton (8T),
15Ton (15T) and 25Ton (25T)
Hydraulic Presses
User Manual
2I-25800-3

Advertisement

loading
Need help?

Need help?

Do you have a question about the Atlas Autotouch 8Ton and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Specac Atlas Autotouch 8Ton

Summary of Contents for Specac Atlas Autotouch 8Ton

  • Page 1 Atlas™ Autotouch 8Ton (8T), 15Ton (15T) and 25Ton (25T) Hydraulic Presses User Manual 2I-25800-3...
  • Page 3 Atlas™ Autotouch 8Ton (8T), 15Ton (15T) and 25 Ton (25T) Hydraulic Presses User Manual 2I-25800-3...
  • Page 4 User Manual Specac manufactures and stocks a full range of IR sampling accessories for solids, liquids and gases and optical components. We design and manufacture fully integrated sampling solutions for the laboratory, at line and in-line process measurement, to cope with extremes of temperature from –190ºC to +800ºC, pressures...
  • Page 5 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses Atlas™ Autotouch 8Ton (8T), 15Ton (15T) and 25Ton (25T) Hydraulic Presses CONTENTS ................. 5 NTRODUCTION 2. U ........7 NPACKING HECKING NSTALLATION 3. G ................11 ENERAL SAFETY 4. D ™ A 8T/15T/25T P ..

  • Page 6: Table Of Contents

    PECIFICATIONS OF TLAS UTOTOUCH RESSES 13. EC D ..........79 ECLARTION OF ONFORMITY © November 2016 Specac Ltd. All rights reserved. Brilliant Spectroscopy is a trademark of Specac Ltd. Other product names mentioned herein may be trademarks of their respective owners.
  • Page 7 8 tons on the 8T, 15 tons on the 15T and 25 tons on the 25T. These presses are specifically suited to the preparation of solid sample discs using Specac Atlas™ evacuable pellet die assemblies, but they may also be adapted to provide heated pressing surfaces by installation of Specac Atlas™...
  • Page 8 The symbol (above) on the back of the press indicates that this product complies with the Waste Electrical and Electronic Equipment Directive (WEEE). If this product is in use and was purchased within the European Union, please contact your local sales agent or Specac to make arrangements for disposal of this equipment.
  • Page 9 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses 2. Unpacking, Checking and Installation Beware! The Atlas™ Autotouch 8T/15T/25T press is very heavy and care must be taken to transport it correctly. Please keep the press packing materials for future transportation if necessary by reversing the following procedure.
  • Page 10 User Manual Before the eye bolt can be put in place the internal packing in the press has to be removed. Cut the tape at the top of the plastic bag and around the base of the bag and lift clear of the press. You will see that there is further protective packing within the pressing area of the press behind the safety guard.
  • Page 11 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses Lifting Eye Bolt Assembly Parts Assembled The press is now ready to be lifted off of the wooden pallet. The press MUST be lifted into its working position using a suitable hoist (or crane) with a lifting hook to pass through the eye bolt.
  • Page 12 The press is supplied filled with hydraulic oil (VG68, P/N GS25900) and is ready to use. Specac would strongly advise that the Atlas™ Autotouch 8T/15T/25T press packing materials are retained and not destroyed (if at all possible), for future transportation should it be required. Using the purpose built packaging is the safest way of moving and containing the press to minimize for any possible damage in transit.
  • Page 13 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses 3. General Safety Specac recommends that certain safety precautions should be followed for any operational procedure of the Atlas™ Autotouch 8T/15T/25T press. The press is very heavy and it should only be lifted using suitable equipment and moved in a safe manner.
  • Page 14 User Manual Electrical Safety • Check that the input voltage (230v, 220v, 110v or 100v) and frequency 50Hz or 60Hz) printed on the appliance label at the back of your press is compatible with your AC mains voltage. • The electrical supply connection to the power plug must be earthed. The protective action earth contact must not be negated by use of an extension cable without a protective conductor.
  • Page 15 If the safety guard shows any visible signs of damage (marks, scratches etc), these may impair its effective performance for safe containment. Specac recommends that the safety guard is replaced if damaged to conform to the correct safety standards.
  • Page 16 User Manual • Do not exceed a load limit of 8 tons for the Atlas™ Autotouch 8T press, 15 tons for the Atlas™ Autotouch 15T or 25 tons for the Atlas™ Autotouch 25T press. • Do not attempt to press potentially combustible materials or materials with a low flash point temperature.
  • Page 17 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses 4. Diagrams of the Atlas™ Autotouch 8T/15T/25T Press Front View (Front Safety Guard Closed)
  • Page 18 User Manual Back View (Front Safety Guard Closed)
  • Page 19 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses Detail of Electronic Front Control Panel...

  • Page 20: 8T/15T/25T Press

    User Manual 5. Operation of the Atlas™ Autotouch 8T/15T/25T Press General Procedure The Atlas™ Autotouch 8T/15T/25T press is used to apply a constant load to a sample contained within the pressing area. The sample will usually take the form of a particular size evacuable pellet die loaded with a sample powder for compaction.
  • Page 21 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses For the procedural description of operation in how to install, press and remove a sample from an Atlas™ Autotouch 8T/15T/25T press, please refer to the diagrams of the press for the part identification where mentioned.
  • Page 22 User Manual SYMBOL FUNCTION Start pressing (apply load) button (11). Stop pressing (release load) button (12). Note: The stop button (12) should be considered a general “failsafe” function button and can be pressed to cease all operations in running of the press at any time or in case of emergencies. During the actual running of any program (PZ or a user created P1 to P6 program), if the stop button (12) is pressed once, this action will:- A) Abort a program if the load is actually rising or releasing.
  • Page 23 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses Movement between the Display Screens and interaction with the various sub-screen displays (changing a load or Editing a program, as examples) is achieved by touching and pressing of the appropriate operation symbol box in the green coloured section area of the Autotouch Display Screen (4).
  • Page 24 User Manual Program Number In Operation - e.g. P1, when illuminated, means program one is active. Program Number Step Forward – to move forward to a higher program number in a program directory listing. Program Number Step Backward – to move backwards to a lower program number in a program directory listing.
  • Page 25 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses Exit Symbol - Exit from a particular Display Screen operating environment back to the Main Operation Screen. (MOS). Add Symbol - To add a segment step in a stored program under the Edit operation environment. Delete Symbol - To delete a segment step in a stored program under the Edit operation environment.
  • Page 26 User Manual Operation – Steps to Press a Sample Powering up the Atlas™ Autotouch 8T/15T/25T Press Note: Before switching on the Atlas™ Autotouch 8T/15T/25T press ensure that the Safety Guard (5) is in its safe/down position. When operating the Atlas™ Autotouch 8T/15T/25T press for the first time ensure that the power on/off switch (1) on the front panel (2) is in the off position.
  • Page 27 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses The (MOS) Display Screen area will be presented having both blue and green coloured backgrounds. Operation symbols that appear over a green background can be touched for activation to move to their individual Display Screen environment for the necessary functions that can be selected within.
  • Page 28 User Manual Changing the Language Display and the Units of Load The Atlas™ Autotouch 8T/15T/25T press displays any message status in English, French, German, Spanish or Italian languages. The change of language is achieved by choosing the Language option from the Options (Opt) screen.

  • Page 29: Presses

    Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses Place the sample in the pressing area (6) on the piston pressing face (7). The maximum height of a sample that can be installed into the pressing area is 155mm. Note: It is essential to always place the sample in the centre of the piston pressing face (7) for safe loading.
  • Page 30 User Manual The first program segment step (S1) is illuminated in yellow (the “Pump up to” load value operation symbol and statement) as this is the condition wished to be changed at this stage for the loaded program (PZ). Note: Changing the load to set and apply is the ONLY aspect of the (PZ) program that can be changed/programmed.
  • Page 31 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses Display will now be as below. (18 Tons has been used as an example load to be set to apply.) When the correct “Pump up to” load has been reached, press the “tick”...
  • Page 32 User Manual An application of the “Pump up to” load selected is always the first segment (S1 - zero) of the (PZ) program sequence. The segment (S1) will be seen for the Simple Program (PZ) that is running. When the safety guard (5) is closed and the start button (11) has been pressed, the press motor will start and the Display Screen (4) will show a status of “Load Rising”...
  • Page 33 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses At this stage in the (PZ) program sequence, a green background display box is presented, but only for the Increase load symbol, which can be pressed for an increase change to the “Pump up to” load to set if desired, up to the maximum load allowable for the press being used.
  • Page 34 User Manual The “Maintain load” symbol will cease illumination and the Display Screen (4) will now show illumination of the “Fast rel to” load value, symbol and statement and a message “Fast Release” in red text is shown underneath the Applied Load Indicator and load value. At this stage the second segment (S2) for the “Maintain load”...
  • Page 35 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses When the applied load has been fully released and the (PZ) program (Run) steps have been completed, the Display Screen (4) will revert to the same status as the original (MOS), before the start button (11) had been pressed.
  • Page 36 User Manual Note: The press can be restarted by pressing the start button (11) for application of a load from either the (ok) or (OK) status indicator, but it is possible there may be more piston travel offered for a new pressing event when starting from an (OK) status due to the longer time period allowed for the piston retraction to its start/rest position from the previous pressing event.
  • Page 37 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses Operation – Further Features of the Press The Safety Guards The Atlas™ Autotouch 8T/15T/25T press incorporates a front safety guard mechanism (5) that is crucial for the safe operation of the press. The front (5) and rear (17) safety guards are made from PETG, a glycol modified polyethylene terephthalate, which is a clear, transparent material offering a high impact resistance to contain any...
  • Page 38 The Pressing Area The Atlas™ Autotouch 8T/15T/25T press has a sample compartment size that allows for use of the entire range of Specac evacuable pellet dies. The maximum distance between the pressing faces is 155mm with a fully raised lead screw pressing anvil face (10) and fully...
  • Page 39 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses From the back view diagram of the pressing area (6), there is protective rear safety guard (13). The rear safety guard is fixed and cannot be raised or lowered similar to the front guard (5). There is a recessed cut away area (14) between the curved rear safety guard (13) profile and the edge of the rear surface of the pressing area (6).
  • Page 40 User Manual Piston Travel There is a maximum piston travel of 24mm and the press motor and pump will automatically stop when this travel limit is reached. An error message “Reached Piston Limit!“ in red text will be momentarily illuminated as an indicator for the status when a program is running. Important! If at all possible it is desirable to avoid running the press piston to the limit of its travel.
  • Page 41 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses Applied Load Indicator reading during the “Load Rising” status. At the very end of the piston travel the Applied Load Indicator value rises almost instantaneously to the “Pump up to” load value and then the “Reached Piston Limit!”...
  • Page 42 User Manual The sample itself, particularly if pressing a sample within an evacuable pellet die, may though have been partially compressed from any load condition that had been attained before the piston of the press reached the limit of its travel. With retraction of the piston face (7) to its start/rest position, a gap will be created between the top of the evacuable pellet dies own plunger and the top lead screw anvil pressing surface (10), due to the partially, but not fully, compressed...
  • Page 43 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses Using the same example for a custom program (P4) that has been created to run, physically stopping the press by using the stop button (12) displays the “Stop key pressed!” message , whereas allowing the press to stop automatically of its own accord because the piston limit travel has been reached would display the message “Reached Piston Limit!”...
  • Page 44 User Manual 6. Display Screens – Operation, Options, Programming, Directory and Editing The Different Display Screen Environments 1) Main Operation Screen (MOS) As stated from Section 5) (Operation Of The Atlas™ Auto 8T/15T/25T Press), when the Atlas™ Autotouch 8T/15T/25T press is switched on at the mains, power to the press will also be indicated by illumination of the Electronic Display (4).
  • Page 45 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses respective boxes displayed on the green coloured background bar along the base of the (MOS). When entering a particular Display Screen environment you can carry out the functions allowed within that environment, such as programming for a customized load/hold/release sequence for the sample type to press or editing a particular saved program.
  • Page 46 User Manual Main Operation Screen (MOS) From the (MOS) with the (PZ) program loaded, if the (Dir) symbol in the green box is touched and pressed, the (Dir) Screen Display (A) environment is accessed and shown as follows:- (Dir) Display Screen (A) Accessed from (MOS) with (PZ) Program Note: From the step sequence from (MOS) to the (Dir) Display Screen (A), further steps to other environments can be made via touch pressing of the (P-), (P+) and (Exit) symbol green boxes.
  • Page 47 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses the (MOS). The (Edit) symbol box (although shown), is inactive when touched to step to another environment when the (PZ) program details are displayed. The (Pgm) box can be touched to access and step through to the next “free” program register from programs (P1) to (P6), but this (Pgm) button is also inactive if all program registers from (P1) to (P6) are already allocated and filled with details for a user custom created program that could...
  • Page 48 User Manual Display Screen Steps When (P1 to P6) Program Loaded If a (P1 to P6) program is loaded to the (MOS) environment to run from pressing the start button (11), a typical (MOS) that will be displayed is shown as follows:- Main Operation Screen (MOS) From the (MOS) example shown, a (P4) program has been created and loaded.
  • Page 49 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses Note: From the step sequence from (MOS) to the (Pgm) Display Screen (B), further steps to other environments can be made via touch pressing of the (S-), (S+), (Edit), (Add), (Del) and (Exit) symbol green boxes.
  • Page 50 User Manual the (MOS). In this instance for Screen Display (A) the (Edit) and (Pgm) boxes are active when touched to step to another environment when the (P1 to P6) program details are displayed. Pressing (Edit) takes you to the (Edit) environment (See page 56).
  • Page 51 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses 2) Options Screen (Opt) The Options Screen (Opt) is accessed from the (MOS) or any Display Screen environment where the green coloured background box with the (Opt) symbol is touched/ pressed. An example of the (Opt) screen is shown above.
  • Page 52 User Manual box to press. To change the cursor setting on the sliding scale indicator the (15) or the (95) box is pressed respectively to dim or brighten the overall display. If the display intensity is changed the change is saved by pressing the green tick box to return to the Opt screen.
  • Page 53 If the press motor/pump continues to overheat, please contact Specac for advice. Pressure Cal. – A typical value shown (circa 1.090) is a factory set calibration factor for load application readings that is a standard factor for any Autotouch press variant (8T, 15T, 25T).
  • Page 54 User Manual “Pump up to” Loads The “Pump up to” loads that can be programmed are dependent upon the load range and the tonnage steps offered from each press variant. For the Autotouch 8T and 15T presses the “Pump up to” load can be a minimum of 1.0 ton or 2.0 tons to a maximum of 8.0 tons and 15.0 tons respectively in 0.2 ton steps and for the Autotouch 25T is 3.0 tons minimum to 25.0 tons maximum in 0.5 ton steps.
  • Page 55 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses Programming The (Pgm) box button can be pressed directly from the (MOS), only when a user created custom program from (P1) to (P6) has been loaded to run from the (MOS). (See details for a typical (Pgm) screen display (B) environment accessed when program P4 is loaded on page 46.) If any program from (P1 to P6) is loaded, the (Pgm) Display Screen...
  • Page 56 User Manual 4) Directory Screen (Dir) The Directory Screen (Dir) allows for checking of any programs and their segment details that have been stored on the Atlas Autotouch press for its operation. Up to 6 user (custom) created programs (P1 to P6) can be stored at any one time and selected for use.
  • Page 57 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses The last program that was stored and used is presented to the (Dir) screen. From the example of (Dir) screen display (A) for (P4) being loaded, program number 4 is shown displayed for 7 (seven) segments (S#’s) that have been used in this program in the blue background area of the display screen.
  • Page 58 User Manual 5) Editing Screen (Edit) Editing of a program for a segment (S#) addition, deletion or change of function can only be achieved for programs (P1 to P6) when loaded for potential operation and displayed as accessed through to the (Edit) Display Screen (B) environment.
  • Page 59 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses (S4) of Program (P4) Illuminated from (S+) Box Pressing Whilst in Display Screen (B) Environment Adding (Add) a Segment to a Program Sequence Up to 10 (ten) segments (S#’s) can be created for use in a program. From our example, if a segment is to be added at the (S4) position in (P4), when (S4) is illuminated as shown, press the (Add) box.
  • Page 60 User Manual At this stage if the segment being added is not required, the (Add) change can be corrected by pressing the (Exit) box from the Display Screen (C) environment. The press condition steps to the (Dir) Display Screen (A) environment for any loaded (P1 to P6) program as shown on page 54.) Deleting (Del) a Segment from a Program Sequence Up to 10 (ten) segments (S#’s) can be created for use in a program.
  • Page 61 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses At this stage if the deleted segment (S4) was not to have been removed from (P4), the (Del) change can be corrected by pressing the (Exit) box from the Display Screen (B) environment. An intermediate Display Screen for choice of saving any changes to a displayed program sequence can be made by pressing of either a green tick or red cross box.
  • Page 62 User Manual Display Screen after Increase Load Symbol Box Pressed from Display Screen (C) Environment For our example program (P4), segment (S4) is illuminated to change the “Pump up to” load from its current 20 tons setting. However, in this instance of a program creation and sequence of events, the previous load holding setting has been at 7 tons for segment step (S3), from a Fast Release Load Rate function of the load initially being “Pumped...
  • Page 63 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses If either the upper or lower load range limit green box is continually pressed, then the load rise or decrease to a new load set point is accelerated. If the new load to set and apply is “overshot” for the cursor position on the slide scale indicator from an accelerated approach, then individually step press to the precise load to set using the appropriate lower or upper load range limit green box.
  • Page 64 User Manual Display Screen after Maintain or Hold Load Symbol Box Pressed from Display Screen (C) Environment For our example program (P4), segment (S2) is illuminated to change the Maintain Load function from its current 0.3 minute setting having pressed the Maintain Load symbol box from the Display Screen (D) environment.
  • Page 65 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses If either the upper or lower time range limit green box is continually pressed, then the time rise or decrease to a value is accelerated. If the new time to set and apply is “overshot” for the cursor position on the slide scale indicator from an accelerated approach, then individually step press to the precise time to set using the appropriate lower or upper time range limit green box.
  • Page 66 User Manual Release Load Rate Function Symbol Program Segment To release any load being applied by a Maintain or Hold Load function segment from a running program, a Release Load Rate function is used as the next segment (S#) of a program sequence after the Maintain or Hold Load timed function.
  • Page 67 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses press to the screen display (C) environment with no changes to the program. Pressing the (Exit) box at this stage returns the press to the (Dir) Display Screen (A) environment. Press the Fast, Medium or Slow Release Load Rate box to set for the segment (S#) detail.
  • Page 68 User Manual pressing the right side (upper load limit) green box to increase the tonnage load value. Each individual press of the box will change the load in step increments for the appropriate press being used and be shown for its value in the illuminated segment (S3) underneath the Release Load Rate symbol chosen.

  • Page 69: Procedure

    Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses 7. Non-Routine Procedures for the Atlas™ Autotouch 8T/15T/25T Press Aborting a Pressing Procedure Should you wish to cancel or change the pressing procedure after the start button (11) has been pushed, the pressing routine from the program (P#) running can be aborted at any time by pushing the stop button (12).
  • Page 70 User Manual the start (11) button. When the load to reset has been re-applied (which may be a fairly rapid event due to the fact that the work components have probably already been fully compressed), press the stop button (12). Whilst the re-applied load is being released as indicated by the display screen message (4) and as oil is draining back into the press oil reservoir, trying turning the lead screw handle (9) anticlockwise now to loosen the components involved in the pressing...
  • Page 71 However, some faults that may develop can be identified and fixed without the potential need for return of the press to Specac. The following information is provided to identify some faults and carry out the necessary repairs and adjustments should you decide to do so.
  • Page 72 (possible piston cylinder assembly problem). If there is an oil leak contact Specac and give serial number of press. Replace the main piston assembly from the Atlas™ Autotouch 8T/15/25T Press using the Piston Assembly Kit of...
  • Page 73 Remedy: Contact Specac and give serial number of press. Cause F: Motor/pump damaged or worn out. Remedy: Contact Specac and give serial number of press. Replace the motor/pump assembly for the Atlas™ Autotouch 8T/15T/25T Press using the Motor/Pump Assembly Kit of parts P/N GS25882 –...

  • Page 74: Lubrication

    Remedy: Contact Specac and give serial number of press. Cause E: Motor/pump damaged or worn out. Remedy: Contact Specac and give serial number of press. Replace the motor/pump assembly for the Atlas™ Autotouch 8T/15T/25T Press using the Motor/Pump Assembly Kit of parts P/N GS25882 –...
  • Page 75 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses Fault 10: Bleeping sound and ERROR 304 message. Cause: Pressure Transducer not connected or faulty. Remedy: Contact Specac and give serial number of press. Reconnect or replace transducer. Fault 11: Bleeping sound and ERROR 305 message.
  • Page 76 Depending on a typical suspected usage of the press (circa 50 pressings per day at maximum tonnage loads), Specac would recommend that the oil in the pressing system is changed every year.
  • Page 77 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses desirable to have the press returned to Specac or a local supplier to carry out this service. Change of the oil requires use of an Oil Kit of parts P/N GS25880 to carry out this procedure correctly and within the...
  • Page 78 Lead Screw Assembly Lubrication Periodically, Specac would recommend lubrication of the lead screw (8) assembly threading when raising or lowering it through the central threaded boss housing part. This helps prevent the risk of seizure and trapping of the lead screw assembly in use and turning by hand.

  • Page 79: Usb C

    USB connectivity port. This can be used to connect the press to a personal computer for automatic operation if desired. Please contact Specac Ltd for details of how you might wish to use this function. 11. Accessories for Atlas™ Autotouch Presses Atlas™...

  • Page 80: Autotouch

    User Manual 12. Specifications of Atlas™ Autotouch Presses ATLAS™ ATLAS™ ATLAS™ Model Name AUTOTOUCH AUTOTOUCH AUTOTOUCH UK/EURO (230v,50Hz) version P/N GS25820 GS25810 GS25800 USA (110v,60Hz) version part P/N GS25821 GS25811 GS25801 JAPAN (100v,50/60Hz) version P/N GS25822 GS25812 GS25802 CHINA (230v,50Hz) version P/N GS25823 GS25813 GS25803...
  • Page 81 Atlas™ Autotouch 8T, 15T and 25T Hydraulic Presses 13. EC Declaration Of Conformity...
  • Page 82 Legend for Atlas™ Autotouch 8T/15T/25T Press Diagrams (1) On/off power switch. (2) Front panel. (3) Rear power mains socket connection. (4) Electronic display screen. (5) Front movable safety guard. (6) Pressing area. (7) Lower piston pressing face. (8) Lead screw. (9) Handle of lead screw.
  • Page 83 Tel: 215 793 4044 Systems Engineering Inc. -Tokyo Fax: 215 793 4011 Tel: 03 3946 4993 Fax: 03 3946 4983 United Kingdom email:systems-eng@systems-eng.co.jp Specac Ltd. - London Website: www.systems-eng.co.jp River House, 97 Cray Avenue, Orpington Spain Kent BR5 4HE Teknokroma S.Coop C. Ltda...
  • Page 84 Brilliant Spectroscopy™ www.specac.com SPECAC INC. SPECAC LTD. 414 Commerce Drive River House, 97 Cray Avenue, Suite 175, Orpington Fort Washington, Kent BR5 4HE PA 19034, USA Tel: +44 (0) 1689 873134 Tel: 215 793 4044 Fax: +44 (0) 1689 878527 Fax: 215 793 4011 Registered No.
