- Page 1 90cm Glass Gas Cooktop I N S T R U C T I O N M A N U A L IM VERSION: V1.3 | MODEL: HBRCGG905W | PRODUCT CODE: 706143 | ISSUE DATE: 09/2021 SUPPORT: 1300 11 4357 | WWW.HARBOUR-APPLIANCES.COM.AU...
-
Page 2: Welcome
Welcome Congratulations on purchasing your new Glass Gas Cooktop. All products brought to you by Harbour are manufactured to the highest standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year In Home Warranty. -
Page 3: Table Of Contents
Contents Welcome Warranty Details General Safety Instructions Product Overview 10 Installation Instructions 18 Operation Instructions 20 Maintenance and Cleaning 22 Troubleshooting 24 Specifications 26 Repair and Refurbished Goods or Parts Notice 27 Warranty Returns... - Page 4 90cm Glass Gas Cooktop REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION Congratulations! You have made an excellent choice of this quality product. Our commitment to quality also includes our service. Should you, contrary to expectations, experience defects due to manufacturing faults, ALDI will provide you with a warranty against defects as follows: Warranty The product is guaranteed to be free from defects in workmanship and parts for a period of 36 months from the date of purchase.
-
Page 5: General Safety Instructions
General Safety Instructions IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety precautions enclosed in here reduce the risk of electric shock and injury when correctly adhered to. Make sure you understand all instructions and warnings. - Page 6 GENERAL SAFETY INSTRUCTIONS CONT. DANGER: GAS LEAKS If gas seems to leak,take the actions as follow: • Do not turn on the light. • Do not switch on/off any electrical appliance and do not touch any electric plug. - Do not use a telephone.
- Page 7 GENERAL SAFETY INSTRUCTIONS CONT. WARNING: OPERATING THE APPLIANCE • The appliance and its accessible parts become hot during use. • Care should be taken to avoid touching heating elements. • Only use the appliance for preparing food. • Do not modify this appliance. Burner panel is not designed to operate from an external timer or separate remote control system.
- Page 8 GENERAL SAFETY INSTRUCTIONS CONT. WARNING: CLEANING AND MAINTENANCE • Never use abrasive or caustic cleaning agents. • This appliance should only be repaired or serviced by an authorised service agent and only genuine spare parts should be used. • Before attempting to clean the appliance it should be disconnected from the mains and cooled. •...
-
Page 9: Product Overview
Product Overview YOUR 90CM GLASS GAS COOKTOP 1. Semi-rapid Burner 4. Rapid Burner Key: Description of the appliance 2. Triple-crown Wok Burner 5. Semi-rapid Burner 3. Auxilary Burner 6. Knob Controls ccessories Accessories: Sponge (4) Voltage regulator valve (1) Bracket (4) Injector Pressure joint(1) Screw (4) -
Page 10: Installation Instructions
Installation Instructions INSTALLATION WARNINGS • Do not modify this appliance. • This appliance must be installed by an authorised technician or installer. • Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the adjustment of the appliance are compatible. - Page 11 700mm 400mm INSTALLATION INSTRUCTIONS CONT. 400mm CLEARANCES REQUIRED POSITIONING WHEN FITTING THE HOB • Clearances required when fitting the cooktop with a cooker hood above. WITH A COOKER HOOD ABOVE FO 0813 700mm 400mm s appliance is to be built into a kitchen unit or 600mm worktop,providing 400mm following minium distances are allowed;...
- Page 12 Remove and flam Installing the appliance applianc INSTALLATION INSTRUCTIONS CONT. cushione Take ca flame su INSTALLING THE APPLIANCE in this op Remove • Remove the pan supports, the burner lid and and flam flame spreader and carefully turn the appliance 2.
- Page 13 nnection Gas Connection INSTALLATION INSTRUCTIONS CONT. GAS CONNECTION f power for safety and appliance protection. Close middle valve to WARNING! gas leakage. • This appliance must be installed and connected in accordance with installation regulations in force in the county in which the appliance is to be used. way from inflammable materials around appliance.
- Page 14 ■ Manufacturer’s Installation instructions ■ Local Gas Fitting Regulations ■ Municipal Building Codes ■ Refer to AS/NZS 5601.1 for Gas Installations ■ S.A.A. Wiring Code INSTALLATION INSTRUCTIONS CONT. ■ Local Electrical Regulations ■ Any other statutory regulations Preparing to install Refer to AS/NZS 5601.1 for piping size details.
- Page 15 st comply with AS/NZS nd installed in natural gas appliance with integral test point using s of the compound to the elbow may be installed INSTALLATION INSTRUCTIONS CONT. ot be subjected to abrasion, to be inspected along its the brass test point adaptor Unions compatible with proved gas thread tape or ed for gas leaks.The...
- Page 16 Electrical Connection ■ This appliance is designed to be connected to a 220-240V, 50Hz-60Hz AC electricity supply. INSTALLATION INSTRUCTIONS CONT. - Green/yellow = Earth - Blue = Neutral ELECTRICAL CONNECTION - Brown = Live • This appliance must be earthed •...
- Page 17 Gas adjustment INSTALLATION INSTRUCTIONS CONT. Gas adjustment Gas adjustment GAS ADJUSTMENT • Take precautions on the operations and adjustments to be carried out when converting from one gas to another. • All work must be carried out by a qualified technician Change the injector of the burners.
-
Page 18: Operation Instructions
Operation Instructions OPERATION OF YOUR GLASS GAS COOKTOP KNOB CONTROLS • The following symbols will appear on the control panel, next to each control knob. GAS OFF MAX. MIN. BURNER INDICATOR • The minimum setting is at the end of the anti-clockwise rotation of the control handle. •... - Page 19 OPERATION INSTRUCTIONS CONT. Safety and Energy saving advice SAFETY AND ENERGY SAVING ADVICE • The diameter of the bottom of the pan should correspond to that of the burner • CAUTION Do not use cookware that overlaps the edge of the burner. - The diameter of the bottom of the pan should correspond to that of the burner.
-
Page 20: Maintenance And Cleaning
Maintenance and Cleaning CAUTION • Cleaning operations must only be carried out when the appliance is completely cool • The appliance should be disconnected from your mains supply before commencing any cleaning process. • Clean the appliance regularly preferably after each use. •... - Page 21 cloth and wipe dry with a clean cloth. blocked. MAINTENANCE AND CLEANING CONT. RE-ASSEMBLE THE BURNERS AS FOLLOWS 1.Place the flame spreader ( 4 ) on to the burner cup ( 5 ) so that the ignition device and the flame supervision device extend through their respective holes in the flame spreader.The flame spreader must click into place correctly.
-
Page 22: Troubleshooting
Troubleshooting OPERATION IN CASE OF EMERGENCY In the event of an emergency you should: • Turn the cooktop off by pressing the “On/Off” button. • Switch off the appliance at the power outlet and remove the plug. • Call the Residentia Group support team on 1300 11 HELP (4357). Some minor faults can be fixed by referring to the instructions given in the Troubleshooting section below. - Page 23 TROUBLESHOOTING CONT. Issue Possible Cause Resolution Unstable flame • The burner lid is badly • Assemble the burner lf correctly assembled Gas smell • Gas leakage. • Stop using the product and close the middle valve. Open the window to ventilate.
-
Page 24: Specifications
Specifications Model: HBRCGG905W Cooking Zones: 5 Zones Ignition Device: Continuous Ignition Type Rated Voltage: 220-240V~ Rated Frequency: 50Hz – 60Hz Rated Power 2.0W Product Dimensions (W × D × H): 900mm × 510mm × 99mm Gas Type: Set for Natural Gas (includes LPG conversion kit) - Page 25 THIS PAGE IS INTENTIONALLY LEFT BLANK...
-
Page 26: Repair And Refurbished Goods Or Parts Notice
60cm/90cm Canopy Rangehood 90cm Glass Gas Cooktop Repair and Refurbished 7kg Clothes Dryer Repair and Refurbished Goods or Parts Notice Goods or Parts Notice Unfortunately, from time to time, faulty products are manufactured which need to be returned to the Supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files Unfortunately, from time to time, faulty products are manufactured which need to stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs... - Page 27 For an electronic copy of this manual, go to www.harbour-appliances.com.au and download a copy.
