  • Page 1 Leica DFC Cameras Quick Start Guide...
  • Page 3 Leica Microsystems (Switzerland) Ltd, or their accredited representative. The information in this document is subject to change without notice and should not be construed as a commitment by Leica Microsystems (Switzerland) Ltd. Leica Microsystems (Switzerland) Ltd accepts no responsibility for any errors that may appear in this document.
  • Page 4 Feedback At Leica Microsystems (Cambridge) we are continually striving to improve the standards of our manuals and would welcome customer feedback. If you would like to comment on any aspect of this manual or our manuals in general, please send email to: LMIS.manuals@leica-microsystems.com...

  • Page 5: Table Of Contents

    Symbols Safety concept Introduction Computer and Camera Requirements and Conditions Overview of Leica DFC Cameras and components Overview of Hardware and Software Installation Installing Leica DFC Twain Software Installation of Leica Camera Hardware Setting up DFCTwain to view and acquire images...

  • Page 6: Symbols

    Failure to do so may lead to malfunction of, or damage to the equipment. User information This symbol denotes additional information or explanation. Action  This symbol within the text indicates that certain actions must be carried out. Leica DFC Cameras – Quick Start Guide...

  • Page 7: Safety Concept

    Use contrary to intended use The use of Leica DFC Cameras in a manner other than that described in this user manual could result in personal injury and damage to property.
  • Page 8 Observe the valid legal and country-specific regulations relating to accident prevention and environmental protection. Additional note This user manual is also available on the Leica DFC Camera CD supplied with your Digital Camera system. Visit our website regularly: http://www.leica-microsystems.com There you will find the very latest software drivers and additional information along with the most recent user manual and FAQs.
  • Page 9 EC declaration of conformity Leica DFC Cameras and their accessories are produced with state-of-the-art technology and are supplied with an EC declaration of conformity. FCC Compliance Note (for IC 3D and IC D only) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.

  • Page 10: Introduction

    Introduction Notes for the user Before fitting a Leica DFC Camera and putting it into operation, pay attention to the following points: Read this user manual and follow the directions for  safety and care. Read the user manual for your stereomicroscope, ...

  • Page 11: Computer And Camera Requirements And Conditions

    Graphic mode Best performance with 32bit true color Main Memory 1 Gb RAM or higher recommended Media CD-ROM drive and a hard disk to install the Leica DFC Camera software. Monitor Min: 19 inch, Resolution: 1280x1024 Storage + transport -20°C - +55°C...

  • Page 12: Overview Of Leica Dfc Cameras And Components

    Overview of Leica DFC Cameras and components Cameras This user manual refers to Leica DFC Cameras DFC280, DFC290, DFC320, DFC300 FX, DFC340 FX, DFC350 FX, DFC420, DFC420 C, DFC480, DFC490, DFC500, IC 3D and IC D cameras Leica DFC cameras are supplied with a 6pin – 6pin...
  • Page 13 FireWire Camera Laptop Power kits are available as optional extras for users with laptops and PCs that require an external source to power the cameras. Please follow the instructions contained within the kit. Leica DFC Cameras – Quick Start Guide...

  • Page 14: Overview Of Hardware And Software Installation

    FireWire card in your desktop or laptop computer. If necessary, install FireWire PCI card in a PC or a PCMCIA card in a laptop. If you have a Leica DFC camera already connected to your computer, you will be asked to disconnect it before software installation.

  • Page 15: Installing Leica Dfc Twain Software

    Host application programs such as Leica Application Suite, Leica IM, Leica QWin, Imaging ®, Photoshop ®, PaintShopPro ® etc., use Leica DFC Twain software to view and capture digital images. More detailed information on using DFC Twain is available in the Leica DFC Acquisition manual.
  • Page 16 Administrative or Power-User privileges to be able to install this software. If in doubt consult your System Administrator. Insert the Leica DFC Camera CD into the CD-drive. Installing Leica DFC Twain Software If the CD does not run automatically, open the CD using Windows Explorer and double-click on "Autorun.exe".

  • Page 17: Installation Of Leica Camera Hardware

    C-mount interface and a video lens. Leica DFC280, DFC290, DFC320, DFC420 & DFC340 FX These Leica DFC cameras can be used with a 0.5x video lens, but a 0.63x video lens is preferred. The image areas obtained with the 0.32x, 0.5x, 0.63x and 1.0x video lenses are illustrated below:...
  • Page 18  Using the C-mount, attach the video objective Fitting to stereomicroscopes (2) to the Leica DFC Camera (3).  Screw the video objective (2), with the Leica DFC Camera attached (3), to the photo device (1). Leica DFC Cameras – Quick Start Guide...
  • Page 19 Leica DFC Camera correctly. The Leica DFC Camera fits onto the side of the HD videotube or phototube and onto the top of all other videotubes or phototubes (HV, HU and A) and trinocular heads.
  • Page 20 Leica DFC Cameras are also suitable for use with upright Fitting to research and inverted microscopes (Leica DM-series). microscopes For assembly instructions and the correct choice of C- mount adapter, please refer to the user manual for your microscopes or consult your Leica adviser.
  • Page 21 Leica IC 3D and IC D Cameras The Leica IC 3D and IC D camera can be fitted to any Stereomicroscope of the M-Series without any additional accessory. Leica DFC Cameras – Quick Start Guide...
  • Page 22 Windows does not display a difference between the two standards in Hardware Device Manager. If in doubt contact your Leica dealer or Leica Support. Your camera may not display a live image otherwise.  If you have an onboard FireWire port or FireWire...
  • Page 23 Before installing the PCI card, follow all relevant instructions provided by your computer manufacturer. The computer must be switched off and the power cord unplugged before and while you are installing the PCI card. Leica DFC Cameras – Quick Start Guide...
  • Page 24  Secure the PCI card to the computer with a screw or retaining bracket.  Close the computer case in accordance with the instructions provided by the manufacturer.  Reconnect the power cord. Leica DFC Cameras – Quick Start Guide...
  • Page 25 Connecting Leica DFC Cameras to the computer If you are connecting a Leica DFC camera for the first time on your computer make sure you install the software before connecting the camera to the computer. The FireWire connector at the back of the camera...
  • Page 26  Connect the DC output plug of the Power Supply Unit to the DC input socket of the Y-Split cable, and connect to the mains electricity supply via the plug provided. Leica DFC Cameras – Quick Start Guide...
  • Page 27 Only connect the 6-pin plug with trailing power jack of the Y-Split cable to your computer. Connecting the free 6-pin end (ie the end that will now contain additional power) to your computer may cause permanent damage to your computer. Leica DFC Cameras – Quick Start Guide...
  • Page 28 DFC280 – DFC490 After connecting a Leica DFC or IC camera for the first IC D IC 3D: time, the operating system will detect the new hardware. Select to install the software automatically and click Windows XP “Next”. This will automatically install the new drivers.
  • Page 29 However to install manually, the location of the camera driver will be on the root of the Leica DFC Camera CD. Select the “CD-Rom drives” checkbox. If the CD is not available, the driver can also be found in “\Program Files\ Leica Microsystems\DFCTwain”...
  • Page 30 A confirmation informs you that the correct driver was found. Click “Next”. At the end of a successful installation, click “Finish”. The camera is now available for use. Leica DFC Cameras – Quick Start Guide...
  • Page 31 (This is the case when any driver it is not verified explicitly by Microsoft.) Click “Continue Anyway”. This will automatically install the new drivers. Click “Finish” at the end. Leica DFC Cameras – Quick Start Guide...
  • Page 32 Windows 2000 Click “Next” to continue with the Found New Hardware Wizard. It will search for the Leica DFC500 drivers.  Select “Search for a suitable driver…” and click "Next" to continue. The Found New Hardware Wizard displays a search dialog box in which you can enter the location of the new driver.
  • Page 33 However to install manually, the location of the camera driver will be on the root of the Leica DFC Camera CD. Select the “CD-Rom drives” checkbox. If the CD is not available, the driver can also be found in “\Program Files\ Leica Microsystems\DFCTwain” - select “Specify a location”.
  • Page 34 At the end of the driver installation, a confirmation informs you that installation was successful. The DFC500 is now ready for use. The camera appears in the Hardware Device Manager under Imaging Devices as a Leica DFC500. Leica DFC Cameras – Quick Start Guide...
  • Page 35 Uninstalling Leica Camera Software There are two ways to uninstall the software: Start>>Programs>>Leica DFCTwain, and select “Uninstall”, Start>>Settings>>Control Panel>>Add or Remove Programs, and select “Leica DFCTwain..” and Remove, Leica DFC Cameras – Quick Start Guide...

  • Page 36: Setting Up Dfctwain To View And Acquire Images

    If not follow these next steps: In Leica Application Suite (LAS), select “Options>>Hardware Setup”. Select Leica DFC Cameras or Leica DFC500 Cameras, and then start LAS. The live image will show directly in LAS. Leica DFC Cameras – Quick Start Guide...
  • Page 37 “Configure>>Image Source Select” Select “Leica DC TWAIN Image Driver” and click “Settings”. Select the “Leica DFC280…DFC490” or “Leica DFC500” source and click OK The live image should then appear on your screen. Leica DFC Cameras – Quick Start Guide...
  • Page 38 (Image sources are sometimes identified as "Scanner", and menu items will be different depending in your image editor.) There may be other camera or image sources available. Select the “Leica DFC280…DFC490” or “Leica DFC500” source and click OK. Leica DFC Cameras – Quick Start Guide...
  • Page 39 If you have more than one camera connected, select either “Active Camera” and choose one from the list, or select “Configuration” and then choose a camera and click “OK”. The live image should then appear. Leica DFC Cameras – Quick Start Guide...
  • Page 40 The picture below shows the user interface of the Leica DFCTwain DFC Twain software: User Interface: For instructions on how to use this software, please refer to the “Image Acquisition” manual, which can be found on the Leica DFC Camera CD.

  • Page 41: Hints And Tips

    Color Wheel in the required direction. You will see the result immediately in the live image. For bright-field specimens use a Daylight Filter (DLF) in the light path. Leica DFC Cameras – Quick Start Guide...

  • Page 42: Troubleshooting

     For optimized live image focus adjustment, activate the "Find focus" tool.  Check the microscope settings. Poor image quality – bad color  Check the exposure settings to avoid under-exposure or over-exposure. Leica DFC Cameras – Quick Start Guide...
  • Page 43  Check the Gain setting. If you increase the Gain setting, you should expect an increase in noise. If you reduce the Gain setting, you should increase the exposure time by way of compensation. Leica DFC Cameras – Quick Start Guide...

  • Page 44: Service

    - Screenshot of the error message. - Description of exactly when and where the problem arises. Mechanical, electronic and/or optical maintenance may only be carried out by Leica-trained maintenance technicians. Only original Leica spare parts may be used. Leica DFC Cameras – Quick Start Guide...
  • Page 45 Leica DFC Cameras – Quick Start Guide...
  • Page 47 Leica Microsystems (Switzerland) Ltd Stereo and Macroscope Systems CH 9435 Heerbrugg Switzerland Email DI.Support@leica-microsystems.com Website www.leica-microsystems.com...
