- Page 1 X503U Product Manual Realtimes Beijing Technology Co., LTD. Fax：+86 010-84284669 / 84280996 Email: info@realtimes.cn Web Page: https://www.realtimesai.com Address: 11th Floor, Block B, 20th Heping Xiyuan, Pingxi Street, Chaoyang District, Beijing 100013,P.R.China...
- Page 2 V1.0 V2.0 2019-03-21 Manual style template update V1.0 V3.0 2020-06-18 Add notes and lights V1.0 V3.1 2020-09-24 Modify interface information and V1.0 RT0086 add line package configuration V3.2 2022-1-7 Add software version supporting V1.0 RT0086 instructions X503U Reference Manual V3.2...
-
Page 3: Table Of Contents
“L4T”）.................... 14 INUX FOR EGRA BBREVIATION ................................15 ETPACK 3.1 Jetpack Component summary........................15 3.2 How to install Jetpack..........................15 3.3 Sample application............................. 17 3.4 Developer tools............................17 3.5 Documentation............................18 TERMS OF WARRANTY............................19 COPYRIGHT NOTICE............................20 X503U Reference Manual V3.2... - Page 4 Therefore, it is recommended to observe anti-static safety precautions when handling any circuit board component (including X503U). Anti-static safety protection measures include, but are not limited to the following: a) The smart box should be placed in an anti-static bag during transportation and storage, and then the board should not be taken out during installation and deployment.
- Page 5 3) Burn in verification of all BSP support packages provided by the company; 4) The company released burn environment construction, entry-level use. ; 5) Various peripheral module drivers released by the company; 6) The company's product fault diagnosis and after-sales maintenance services; 2. Scope of technical discussion X503U Reference Manual V3.2...
- Page 6 Updates of subsequent documents, BSP, driver files and other official account will be updated in time. We will pay close attention to our developments in order to ensure that your information is up to date. We will push through WeChat public. X503U Reference Manual V3.2...
-
Page 7: Product Presentation
USB2.0, HDMI, serial port, gigabit network port, GPIO, microSD card socket, the system is an excellent platform for deep learning, computer vision, image processing and GPU computing. X503U is made of strong aluminum alloy with conductive heat dissipation design. The operating temperature is -25 -- +55℃... -
Page 8: Ordering Information
-20 -- +55℃; Includes power adapter, provides Ruitai RTSO-9003 Linux4Tegra software support package, has passed THE 3C and CE certification X503U-Cable Cable package for X503U interface (optional) Order online: https://shop340963258.taobao.com https://mall.jd.com/index-824786.html 1.3 Wiring package configuration Component Number Functional Description Micro USB turn Convert Micro USB2.0 interface to standard USB2.0 interface... -
Page 9: Product Specifications
Realtimes Beijing Technology Co.,LTD www.realtimesai.com Product specifications 1 External interface function and location X503U FRONT X503U BACK X503U Reference Manual V3.2... -
Page 10: Connectors Description
TX1/TX2 default serial port setting is: 115200bps, 8N1. and button connector 2.2 GPIO/I2C GPIO、I2C and button connection Function GPIO/I2C marking DB9 interface Type Pin define Signal Signal GPIO0 GPIO1 GPIO2 GPIO3 I2C CLK I2C SDA RECOVERY BUTTON POWER BUTTON X503U Reference Manual V3.2... -
Page 11: Can Connector
Pin 1 location: The green frame on the right. The CAN bus interface function is not available when used with the Jetson TX1 module 2.4 WiFi/Bluetooth antenna connection WIFI/Bluetooth antenna connection Function marking Antenna1 、 Antenna2 Type ipex to sma female X503U Reference Manual V3.2... -
Page 12: Power Input Terminal
Power switch Function marking On/Off 2.7 LED 指示标识 功能描述 状态描述 Power 电源指示灯 常亮-设备供电 2.8 HDMI connector HDMI output interface Function HDMI marking Type Standard HDMI connectors 2.9 Ethernet connector Function Gigabit Ethernet connector marking Ethernet Type RJ45 X503U Reference Manual V3.2... -
Page 13: Usb3.0 Connectors
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 2.10 USB3.0 connectors Function USB3.0 connectors marking USB3.0 Type Dual layer USB3.0 type-a interface 2.11 OTG-USB2.0 Function USB2.0 connectors USB-OTG marking USB 2.0 MicroType-B Type X503U Reference Manual V3.2... -
Page 14: Product Size Diagram
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 3 Product size diagram 4 Hardware update history X503U hardware update history edition Updata description V1.0 Initial release X503U Reference Manual V3.2... -
Page 15: Software Version Supporting Instructions
(BSP) and sample file system. X503U Smart Box is working on a system burned with the official original version of NVIDIA Linux For Tegra (L4T). HDMI, Gigabit Ethernet, USB2.0, serial port, GPIO, SD card, I2C bus can all be supported. -
Page 16: Jetpack
You must have a Linux host with internet access to run SDK Manager and refresh the developer kit. The supported host operating systems are: Ubuntu Linux x64 Version 18.04 or 16.04 Download and install NVIDIA SDK Manager. Installation package： sdkmanager-[version].[build#].deb sdkmanager The current version is： sdkmanager_1.2.0 X503U Reference Manual V3.2... - Page 17 Use SDK Manager to select and install the required components NVIDIA SDK Manager supports installing software to Jetson core (Flying Cloud Smart Box). For complete instructions, please refer to Chapter 5 of "TX2 System Programming Manual". X503U Reference Manual V3.2...
-
Page 18: Sample Application
API debugging through user interface and command line tools. •NSight Graphics for graphics application debugging and evaluation: a consolegrade tool for debugging and optimizing OpenGL and OpenGL ES programs. Run on the Linux host. Support all Jetson products. X503U Reference Manual V3.2... -
Page 19: Documentation
Documentation • CUDA Toolkit • NVIDIA Container Runtime • OpenCV Documentation • Jetson Linux Multimedia API Reference • Nsight Systems • nvprof • Visual Profiler • Nsight Graphics • Nsight Compute CLI • VPI–Vision Programming Interface X503U Reference Manual V3.2... -
Page 20: Terms Of Warranty
Other failures which are clearly due to misuse(such as overvoltage,polarity reversal, the pin bent or broken,the wrong connection,drop damage,transportation damage,damage due to over operating temperature and so on). e) The logo and part number on the product have been deleted or removed. The product is out of warranty. X503U Reference Manual V3.2... -
Page 21: Copyright Notice
Without the written permission of the company, no unit or individual may copy, extract, backup, modify, disseminate, translate into other languages, or use all or part of it for commercial purposes in any way or form. X503U Reference Manual V3.2...
