- Page 1 Installation and Operating Service Manual ELECTRIC STEAM BOILERS Bryan Steam LLC, 783 N. Chili Avenue, Peru, IN 46970, Phone 765.473.6651, Fax 765.473.3074 www.bryanboilers.com Form 2055 Revision Date 5/1/2015...
-
Page 2: Table Of Contents
T able of Contents S E C T I O N 1 – I N S T A L L A T I O N I N S T R U C T I O N S Boiler Foundation ..................1 Clearances .................... - Page 3 Table of Contents – cont. S E C T I O N 3 – C A R E A N D M A I N T E N A N C E Required Precautions During Temporary Use ........9-10 3.1.1 General 3.1.2 Operator Skills/Responsibilities...
-
Page 4: Boiler Foundation
INSTALLATIOIN INSTRUCTIONS Section ELECTRIC STEAM BOILERS Note: Please read the entire instruction manual before attempting installation. Insurance and local or state regulatory codes may contain additional or more stringent requirements than those contained in this manual. Installation must conform to these codes and any other authority having jurisdiction. -
Page 5: Boiler Connections
1.4 BOILER CONNECTIONS 1 . 4 . 1 G E N E R A L Do not run any pipes along the element access and power panel side of the boiler. Maintain clearances as shown on the dimensional drawing for servicing and as referenced in NEC. All piping should be designed and installed to avoid any loadings on the boiler connections or piping. -
Page 6: Safety Relief Valve(S)
1 . 4 . 4 S A F E T Y R E L I E F V A L V E ( S ) A connection is provided in the top of the boiler for the relief valve. The relief valve discharge piping must be the same size as the relief valve discharge opening. -
Page 7: Boiler Accessory Equipment
These circuits are broken down into branch circuits of no more than 50 amps per circuit. A distribution lug in the BE Series and a copper bus bar in the BH Series is used to branch the power to individual fuses and contactors in each branch circuit. Each leg in each circuit is individually fused with fast acting fuses to interrupt power if required. -
Page 8: Safety Relief Valves
Power is shut off to the elements until the modulating motor has driven the sequencer back to its original starting position. The relay is then activated, and the sequencer will bring the steps back on one at a time until the system is again balanced. There is also a limit supplied to be installed with the shunt trip on the main circuit breaker in order to completely shut down all power to the boiler. -
Page 9: Start-Up And Operation
Section START-UP AND OPERATION ELECTRIC STEAM BOILERS WARNING SERVICING AND START-UP MUST BE DONE ONLY BY FULLY TRAINED AND QUALIFIED PERSONNEL. CAUTION BEFORE DISCONNECTING OR OPENING ANY BOILER ITEMS OR ACCESSORIES, BEFORE CLEANING OR REPLACING PARTS OF ANY KIND, TAKE THE FOLLOWING PRECAUTIONS: TURN OFF AND LOCKOUT ALL ELECTRICAL DISCONNECTS TO THE BOILER AND ANY OTHER EQUIPMENT OR SYSTEMS ELECTRICALLY INTERLOCKED WITH THE... -
Page 10: Steam Pressure Operating Control
2 . 1 . 2 S T E A M P R E S S U R E O P E R A T I N G C O N T R O L The steam pressure in the boiler is regulated by the Boiler Operator. This is a pressure control which senses the steam pressure and turns the boiler on and off accordingly. -
Page 11: Chemical Feed System & Softener
2 . 1 . 8 C H E M I C A L F E E D S Y S T E M & S O F T E N E R Check the performance of the boiler water softener and chemical treatment system. Chemically test the feedwater to be certain it complies with the recommendations of the chemical treatment consultant. -
Page 12: S E C T I O N 3 - C A R E A N D M A I N T E N A N C E Required Precautions During Temporary Use
Section CARE AND MAINTENANCE ELECTRIC STEAM BOILERS CAUTION The boiler area should be kept free of combustible materials, gasoline and other flammable liquids. The following procedures must be conducted as outlined to assure safe operation of the boiler. ... -
Page 13: Cleaning The Boiler And System - New Systems
Assurance that the boiler is fed with only treated water at all times and that chemical treatment and blowdown procedures are always followed. Notification to the manufacturer (or manufacturer’s agent) to provide start-up services if the boiler was purchased with start-up by a factory representative. ... - Page 14 Before introducing the solution into the boiler, an overflow pipe should be attached to the top of the boiler and routed to a safe point of discharge. Remove all safety valves to ensure that none of the solution will come into contact with the valve seats.
-
Page 15: System Clean Out
3.3 SYSTEM CLEAN OUT Many boilers have been ruined with system contaminants such as pipe dope, cutting oil, metal shavings or chips and other debris which are left in the piping. If these contaminants are not removed, they will end up in the boiler. 3 . -
Page 16: Boiler Water Treatment
NOTE: For some old systems, there is a reluctance to clean the piping because of possible leaks occurring in badly corroded lines. Should the customer refuse cleaning, it is necessary to install filtration equipment. Install either a fibrous filter or a centrifugal filter in the boiler return piping. This will collect and remove sediment from the system. -
Page 17: Continuous Monitoring Required
3 . 5 . 4 C O N T I N U O U S M O N I T O R I N G R E Q U I R E D Water treatment should be checked and maintained whenever the boiler is operating. The boiler operator should be sure that the boiler is not operating for long periods without proper water treatment. -
Page 18: Monthly
3 . 6 . 3 M O N T H L Y Make visual inspection of all wiring and components. Check float low water cutoff as described above. 3 . 6 . 4 A N N U A L L Y ... -
Page 19: Maintenance
3 . 8 . 2 M A I N T E N A N C E Inspect the gauge glass regularly for any signs of clouding or scratching. In new processes, the gauge glass should be inspected daily until the need for replacement becomes apparent. This will help establish the routine inspection cycle. -
Page 20: Pre-Operational Cleaning And Lay-Up
3 . 9 . 2 P R E - O P E R A T I O N A L C L E A N I N G A N D L A Y - U P Proper lay-up techniques must be used on an idle boiler even if it has never been in operation. Before pre-operational lay-up, the boiler must be chemically cleaned as outlined in Section 3.2 and 3.3 of this manual. -
Page 21: Wet Lay-Up Of Steam Boilers - Short Term
3 . 9 . 7 W E T L A Y - U P O F S T E A M B O I L E R S - S H O R T T E R M In the wet lay-up procedure, the boiler is to be filled with chemically treated water and sealed to prevent air in-leakage. -
Page 22: Wet Lay-Up - Alternate Method
WATER LEVEL SUITABLE SMALL STEEL BOILER DRUM CONNECTION VALVE Figure 3.9A: WET LAY-UP STATIC HEAD DRUM BOILER DRUM If the tests indicate chemical concentration has decreased, chemical may be introduced to the boiler by putting it in the drum shown in Figure 3.9A. Then lower the boiler water level to introduce it into the boiler. -
Page 23: Returning Idle Boiler To Service
Drain the boiler before the steam pressure falls to zero. Then pressurize with 5 psig nitrogen gas through a suitable top opening during draining. The nitrogen pressure is to be maintained through draining and subsequent storage. An alternate method is to completely dry a clean boiler (by blowing hot dry air through the boiler) and then purge the air from the boiler and pressurized with 5 psig nitrogen.
