1. OPERATOR
2. PROBE TYPE LWCO
3. RELIEF VALVE
4. AQUASTAT (HIGH LIMIT)
Dimensions
A
B
C
KW
208-230/3/60
60
50" 33"
35"
30"x36"x10"
75
50" 33"
35"
30"x36"x10"
90
50" 33"
35"
30"x36"x10"
105
50" 33"
35"
30"x48"x10"
120
50" 33"
35"
30"x48"x10"
135
50" 41" 42-1/2"
30"x48"x10"
150
50" 41" 42-1/2"
30"x48"x10"
165
56" 47"
49"
30"x48"x10"
180
56" 47"
49"
30"x48"x10"
195
56" 47"
49"
30"x66"x10"
210
56" 47"
49"
30"x66"x10"
** CONSULT FACTORY FOR UNITS ABOVE 1800 KW
BH Series Electric Boiler
150 psi Water Design 60 kw to 480 kw
5. POWER PANEL
6. CONTROL PANEL
7. LIFTING LUGS
8. PRESSURE GAUGE
Inlet
DxExF
DxExF
G
460-575/3/60
30"x36"x10"
2" 150#
30"x36"x10"
2" 150#
30"x36"x10"
2" 150#
30"x36"x10"
2" 150#
30"x36"x10"
2" 150#
30"x36"x10"
3" 150#
30"x36"x10"
3" 150#
30"x36"x10"
3" 150#
30"x36"x10"
3" 150#
30"x48"x10"
3" 150#
30"x48"x10"
3" 150#
9. TEMPERATURE GAUGE
10. ELEMENT ACCESS
11. DRAIN
12. STRUCTURAL STEEL BASE
Outlet
Dimensions
H
A
KW
2" 150#
210
56" 47"
2" 150#
225
56" 47"
2" 150#
240
56" 47"
2" 150#
270
56" 47"
2" 150#
300
56" 47"
3" 150#
330
56" 47"
3" 150#
360
56" 47"
3" 150#
390
56" 53"
3" 150#
420
56" 53"
3" 150#
450
56" 53"
3" 150#
480
56" 53"
EFFECTIVE DATE: 3-1-04
REPLACED DATE: 2-17-82
B
C
DxExF
DxExF
208-230/3/60 460-575/3/60
49"
30"x66"x10"
30"x48"x10"
49"
30"x66"x10"
30"x48"x10"
49"
30"x66"x10"
30"x48"x10"
49"
36"x72"x10"
30"x48"x10"
49"
36"x72"x10"
30"x48"x10"
49"
36"x72"x10"
30"x48"x10"
49"
60"x82"x16"
30"x48"x10"
55"
60"x82"x16"
30"x66"x10"
55"
60"x82"x16"
30"x66"x10"
55"
60"x82"x16"
30"x66"x10"
55"
60"x82"x16"
30"x66"x10"
Inlet
Outlet
G
H
3" 150#
3" 150#
3" 150#
3" 150#
3" 150#
3" 150#
3" 150#
3" 150#
3" 150#
3" 150#
3" 150#
3" 150#
3" 150#
3" 150#
4" 150#
4" 150#
4" 150#
4" 150#
4" 150#
4" 150#
4" 150#
4" 150#
