Good Earth Lighting SE1303-BP2-00LFW-G Quick Start Manual

Good Earth App Download and Pairing – Easy 3-Step Quick Start Guide
Note: Only 2.4 GHz Wi-Fi networks are supported; router may need to be set in 2.4G signal mode. Make sure light fixture is placed within
proximately of Wi-Fi network signal.
Visit Good Earth You Tube Channel at https://www.youtube.com/c/GoodEarthLighting for more "How-To" videos and support.

1 APP DOWNLOAD/REGISTER

Search "Good Earth Lighting" on the App Store
on Google Play and download. Once successfully
downloaded, open the Good Earth App, review,
and agree to the privacy agreement and terms of
condition by tapping "Agree".Register by entering
your email address. Enter the provided verification
code sent via email and create a password for the
account.

3 RESET AND SYNC WITH SMART DEVICE

To successfully sync with a smart device (i.e. smartphone, tablet, etc.) the light fixture must first be rapidly flashing in paring/reset
mode. To reset the light fixture, press and hold the pairing button located on the bottom of Passive Infrared Sensor (PIR) for 6
seconds. Once successfully reset, the light fixture will begin to rapidly flash at the same pace as the light on the screen. The flash
will last about 3 minutes to allow time to pair. Click "Confirm". Select the WiFi network that you would like your smart device
connected to, and enter the password to begin syncing the device (NOTE: Your smart device must be connected to the same
network only for pairing process). Once successfully paired, the light fixture will stop flashing and the home screen will appear on
the smart device. Select the recently synced device from the home screen to control all light functions via the smart device.
LED Indicator:
1) No connection to WiFi network: RED LED off
2) Pairing the network: RED LED Flashing
3) Pairing successful: RED LED off
4) PIR Triggered: Red LED flash twice (2 flashes per trigger)
When the device is paired for the first time, it will automatically pair via Wi-Fi network. When the Wi-Fi network goes down, the device will connect via Bluetooth® wireless technology.
The user must turn on their Bluetooth
enabled control. The range of the Bluetooth
metal, wall, etc.) or electromagnetic environment.
Select "Me" at bottom right. Tap "Home Management". Tap "Create a home" to create a new Home Name, Home Location, and which Rooms this light is installed. It is important to set
Home Location to ensure Location and Time are set to your preference because the dusk-to-dawn feature is based on time of your location on your phone, following sunset to sunrise
on your time zone. (NOTE: Between sunset/dusk and sunrise/dawn is about 30 minutes variances.)
Wi-Fi Control No hub required to control via smart device. Control from anywhere as long as you have a connection to the internet.
Custom, Default, Manual Settings Customize area light and security light settings, or simply pick default setting are set to go.
Selectable White Lights Create cozy warm white for outdoor ambiance or energetic daylight white for security purposes. Select from soft white (2700K), warm white (3000K), or to
daylight white (5000K) to suit your lighting needs.
Detection Range Select the distance in which the passive infrared sensor (PIR) activates the lights at. Up to 100-ft.
Easy Setup Successfully sync devices in 5 minutes.
Dimmable Control the lights brightness from 20%-100%.
Create Scenes Create unique scenes with customizable effects, color cycles, brightness, and speed.
Home Management Assign multiple Wi-Fi lights to different rooms to control room by room. Hands-Free Control Voice control works with Amazon Alexa and Google Assistant.
Schedule Timer Set timer on both area and security light how long the lights to stay on; and/or set lights to activate during certain conditions (time, date, and weather).
Create Groups Group multiple Wi-Fi lights together to control simultaneously (only for the same lighting type).
or
®
Lower Motion Sensor
on their mobile device in order to control this way. Once the Wi-Fi network turns back on, then the device will automatically change back to Wi-Fi
®
connection is approximately 300 feet (91 meters). However, maximum communication range will vary depending on obstacles (person,
®
App Controls and Functions

DEFAULT SETTINGS

The "Default Settings" mode has pre-set settings that cannot be changed by the user. When the device is paired for the first time, the
default settings mode become active.
DEFAULT SETTINGS MODE
If the user wants to use a different mode, click on "EDIT" to select which mode the light is using.
Area Light
Color Temperature: 3000K Warm White
Timer: (Turns the Area Light on at dusk for duration of the light until it shuts off at dawn)
Brightness: 30%
Security Light
Color Temperature: 5000K Daylight White
PIR Motion Sensor: Dusk to dawn (Motion activates during the duration from dusk to dawn for energy savings).
Timer: 2 Minute (Light will stay on for 2 minutes when motion is activated)
Detection Range: 60 Feet (The detection zone of the motion sensor is up to 60 Feet)
Brightness: 100%
LAMPE DE SÉCURITÉ INTELLIGENTE À DEL POUR L'EXTÉRIEUR (Page 3)
LUZ DE SEGURIDAD LED INTELIGENTE PARA EXTERIORES (Página 6)
Model / Modèle / Modelo #: SE1303-BP2-00LFW-G, SE1303-WH3-00LFW-G
ENGLISH

2 SELECTING LIGHT TYPE

Mattsmith@fakeemail.com
Get Verification Code
I Agree to User Agreement and Privacy Policy
Pairing Button
BLUETOOTH 4.0
®

SET "ME" PROFILE

FEATURES

(When motion is activated)
SAVE AND ATTACH RECEIPT HERE
OUTDOOR LED SMART SECURITY LIGHT (Page 1)
On the Home Screen,
select "Add Device". In the
Wi-Fi Lighting section,
manually add the lighting
fixture by selecting the
appropriate light category
from the options presented.
Confirm
Confirm
