907423 - 10-05-02.qxd
Instruction
manual
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2002 Porter-Cable Corporation
10/22/02
2:09 PM
Page 1
Trim Saw
HERITAGE
MODEL 314H
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
ESPAÑOL: PÁGINA 15
FRANÇAISE : PAGE 31
MODEL 314
IMPORTANT
Part No. 907423 - 10-05-02
Advertisement
Table of Contents
Related Manuals for Porter-Cable 314H
Summary of Contents for Porter-Cable 314H
- Page 1 HERITAGE MODEL 314H MODEL 314 IMPORTANT Please make certain that the person who is To learn more about Porter-Cable to use this equipment carefully reads and visit our website at: understands these instructions before http://www.porter-cable.com starting operations. The Model and Serial No. plate is located on the main housing of the tool.
-
Page 2: General Safety Rules
907423 - 10-05-02.qxd 10/22/02 2:09 PM Page 2 WARNING: SOME DUST CREATED BY POWER SANDING, SAWING, GRINDING, DRILLING, AND OTHER CONSTRUCTION ACTIVITIES contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: ·... - Page 3 907423 - 10-05-02.qxd 10/22/02 2:09 PM Page 3 Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. Avoid accidental starting.
- Page 4 907423 - 10-05-02.qxd 10/22/02 2:09 PM Page 4 SPECIFIC SAFETY RULES AND SYMBOLS FOR CIRCULAR SAWS DANGER! Keep hands away from cutting area and blade. Keep your second hand on auxiliary handle or motor housing. If both hands are holding the saw, they cannot be cut by the blade. Keep your body positioned to either side of the saw blade, but not in line with the saw blade.
- Page 5 Cable strongly recommends that this tool NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application DO NOT use the tool until you have written Porter-Cable and we have advised you. Technical Service Manager Porter-Cable Corporation...
-
Page 6: Replacement Parts
When servicing use only identical replacement parts. MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. -
Page 7: Selecting The Blade
Page 7 OPERATING INSTRUCTIONS FOREWORD Your Porter-Cable Trim Saw is designed for cutting trim, composition board, plywood, plastics, plexiglas, and other problem materials. Maximum depth of cut is 1-5/16" at 90° and 1-1/16" at 45° with 4-1/2" diameter blade. SELECTING THE BLADE A Combination Blade is furnished with your saw and is an excellent blade for all general ripping and crosscutting operations. - Page 8 907423 - 10-05-02.qxd 10/22/02 2:09 PM Page 8 Fig. 2 Fig. 1 TO ADJUST FOR BEVEL CUTS CAUTION: DISCONNECT SAW FROM POWER SOURCE. Loosen the front (A) Fig. 2, and rear (B) Fig. 2 angle adjusting knobs. Tilt saw housing until desired angle graduation mark, on the angle segment, lines up with the indicating line (C) Fig.
- Page 9 HOW TO USE THE SAW CAUTION: Never use your saw if the telescoping guard is not in working order. If telescoping guard movement is sluggish or binding exists, return the saw to your nearest AUTHORIZED PORTER-CABLE SERVICE STATION or PORTER-CABLE SERVICE CENTER FOR REPAIR.
- Page 10 907423 - 10-05-02.qxd 10/22/02 2:10 PM Page 10 WARNING: GUARD AGAINST KICKBACK. Kickback occurs when the blade is pinched and the saw is driven back towards the operator. Keep body to side of blade. Stay alert and maintain firm grip on saw for control.
-
Page 11: Maintenance
907423 - 10-05-02.qxd 10/22/02 2:10 PM Page 11 PANEL CUTS For making wide cuts, such as might be made in plywood and wide sheets, a wooden guide strip is helpful. This strip should be clamped or tacked to the work far enough back from the line of cut to act as a fence for the left edge of the saw base as shown in Fig. -
Page 12: Failure To Start
LUBRICATION Although all Porter-Cable tools have been thoroughly lubricated with a sufficient amount of high grade lubricant at the time of manufacture, it is recommended that the oil level in the gear chamber be checked before using your saw and periodically thereafter as follows: CAUTION: DISCONNECT TOOL FROM POWER SOURCE. -
Page 13: Service And Repairs
(model number, type, serial number, etc.). ACCESSORIES A complete line of accessories is available from your Porter-Cable • Delta Supplier, Porter-Cable • Delta Factory Service Centers, and Porter-Cable Authorized Service Stations. Please visit our Web Site www.porter- cable.com... - Page 14 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace, at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or Para obtener más infor...
- Page 15 Porter-Cable • Delta products should be obtained by contacting any Porter-Cable • Delta Distributor, Authorized Service Center, or Porter-Cable • Delta Factory Service Center. If you do not have access to any of these, call 888-848-5175 and you will be directed to the nearest Porter-Cable •...
