Porter-Cable 447 Instruction Manual

Double insulated circular saw
Hide thumbs
Table of Contents

Advertisement

Quick Links

Instruction
manual
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2003 Porter-Cable Corporation
ESPAÑOL: PÁGINA 17
FRANÇAISE : PAGE 37
Double Insulated

Circular Saw

Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
MODELS
347k and 447k
IMPORTANT
Part No. 900003 - 12-10-03
