X1/X2
Projector
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product
in a safe manner, as well as registering your product for future service. Warranty information contained in this
User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website. "Antes de operar su equipo lea cu idadosamente las instrucciones en este manual"
Model No. VS18969 / VS19041
Model Name: X1/X2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X1 and is the answer not in the manual?

Questions and answers

Related Manuals for ViewSonic X1

Summary of Contents for ViewSonic X1

  • Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.

  • Page 2: Table Of Contents

    Replacing the Remote Control Batteries ..............10 Initial Setup ............... 11 Choosing a Location ....................11 Projection Dimensions ..................12 16:9 Image on a 16:9 Screen ..................12 X1 ..........................12 X2 ..........................13 16:9 Image on a 4:3 Screen ..................13 X1 ..........................13 X2 ..........................14 Mounting the Projector ..................15...
  • Page 3 Operation ..............24 Turning the Projector On/Off ................24 Starting Up the Projector ..................24 First Time Activation ....................24 Shutting Down the Projector ................. 25 Selecting an Input Source ..................26 Adjusting the Projected Image ................27 Adjusting the Projector's Height and Projection Angle ..........27 Fine-Tuning the Image Size and Clarity ..............
  • Page 4 Appendix ..............70 Specifications ......................70 Projector Dimensions .................... 71 Timing Chart ......................71 Troubleshooting ....................74 Common Problems ....................74 LED Indicator ......................75 Maintenance......................76 General Precautions ....................76 Cleaning the Lens ....................76 Cleaning the Case ....................76 Storing the Projector ..................... 76 Disclaimer ......................

  • Page 5: Introduction

    Introduction Package Contents NOTE: The power cord and video cables included in your package may vary depending on your country. Please contact your local reseller for more information.

  • Page 6: Product Overview

    Product Overview Projector MENU BLANK EXIT ENTER SOURCE COLOR MODE Vent (heated air exhaust) Lens shift (up/down) Indicator Light *The lens shift function is only available on specific model. Vent (cold air intake) Vent (cold air intake) Remote IR sensor Projection Lens Focus Ring Zoom Ring...

  • Page 7: Connection Ports

    Connection Ports AUDIO IN USB C RS232 SERVICE HDMI 1 HDMI 2 USB A HDCP 2.2 HDCP 2.2 5V/1A AUDIO OUT Reset button for SMART SYSTEM Kensington Anti-theft Lock Slot AC Power Cord Inlet Remote IR sensor Security Bar Ceiling Mount Holes Adjuster Foot Port Description...

  • Page 8: Remote Control

    Remote Control Button Description Returns to the previous menu, main settings menu Controls and Functions or exit the app. Goes to the homepage of the SMART SYSTEM. Increases the projector volume. Decreases the projector volume. Mutes or unmutes the projector volume. Plays or pauses the playback of a file.

  • Page 9: Remote Control Effective Range

    Button Description Exits and saves menu settings. Goes to the homepage of the SMART SYSTEM. Increases the projector volume. Decreases the projector volume. Mutes or unmutes the projector volume. Not available. Remote Control Effective Range To ensure proper function of the remote control follow the steps below: The remote control must be held at an angle within 30°...

  • Page 10: Replacing The Remote Control Batteries

    Replacing the Remote Control Batteries Remove the battery cover from the rear of the remote control by pressing the finger grip and sliding it down. Remove any existing batteries (if necessary) and install two AAA batteries. NOTE: Observe the battery’s polarities as indicated. Replace the battery cover by aligning it with the base and pushing it back into position.

  • Page 11: Initial Setup

    Initial Setup This section provides detailed instructions for setting up your projector. Choosing a Location Personal preference and room layout will decide the installation location. Consider the following: • Size and Position of your screen. • Location of a suitable power outlet. •...

  • Page 12: Projection Dimensions

    Projection Dimensions NOTE: See “Specifications” on page 63 for the native display resolution of this projector. • 16:9 Image on a 16:9 Screen Lens shift (up/down) Lens shift (up/down) • 16:9 Image on a 4:3 Screen Lens shift (up/down) Lens shift (up/down) NOTE: (e) = Screen...

  • Page 13: 16:9 Image On A 4:3 Screen

    (a) Screen (b) Projection Distance (c) Image (d) Vertical Offset Size Height minimum maximum minimum maximum inch mm inch inch inch inch inch 1524 1091 1778 1061 1273 2032 1213 1455 2286 1364 1637 1121 100 2540 1516 1819 1245 110 2794 1667 2001...
  • Page 14 (a) Screen (b) Projection Distance (c) Image (d) Vertical Offset Size minimum maximum Height minimum maximum inch mm inch inch inch inch inch 60 1524 1002 70 1778 1169 80 2032 1113 1336 90 2286 1252 1503 1029 100 2540 1391 1670 1143...

  • Page 15: Mounting The Projector

    If you buy a third-party mount, please use the correct screw size. Screw size can vary depending on the thickness of the mounting plate. To ensure the most secure installation, please use a ViewSonic® wall or ceiling mount. 2. Ensure the screws used to attach a mount to the projector meet the following specifications: •...

  • Page 16: Preventing Unauthorized Use

    Preventing Unauthorized Use The projector has several built-in security features to prevent theft, access, or accidental setting changes. Using the Security Slot To help prevent the projector from being stolen, use a security slot locking device to secure the projector to a fixed object. Below is an example of setting up a security slot locking device: NOTE: The security slot can also be used as a safety anchor if the projector is...

  • Page 17: Using The Password Function

    Using the Password Function To help prevent unauthorized access or use, the projector offers a password security option. The password can be set through the On-Screen Display (OSD) Menu. NOTE: Make note of your password, and keep it in a safe place. Setting a Password Press MENU or to open the OSD Menu and go to:...

  • Page 18: Changing The Password

    Changing the Password SYSTEM > Security Settings Press MENU or to open the OSD Menu and go to: > Change Password. 2. Press ENTER/OK, the message, ‘INPUT CURRENT PASSWORD’ will appear. 3. Enter the old password. ͫ If the password is correct, the message, ‘INPUT NEW PASSWORD’ will appear.

  • Page 19: Forgetting The Password

    Forgetting the Password If the password function is activated, you will be asked to enter the six-digit password every time you turn on the projector. If you enter the wrong password, the password error message, as pictured to the right, will appear for 5 seconds, and the message ‘INPUT PASSWORD’...

  • Page 20: Locking The Control Keys

    Locking the Control Keys With the control keys on the projector locked, you can prevent your settings from being changed accidentally (by children, for example). NOTE: When the Panel Key Lock is On, no control keys on the projector will operate except Power.

  • Page 21: Making Connections

    Making Connections This section guides you on how to connect the projector with other equipment. Connecting to Power 1. Connect the power cord to the AC IN jack at the rear of the projector. 2. Plug the power cord into a power outlet. NOTE: When installing the projector, incorporate a readily accessible disconnect device in the fixed wiring, or connect the power plug to an easily accessible...

  • Page 22: Connecting To Video/Computer Sources

    Connecting to Video/Computer Sources HDMI Connection Connect one end of an HDMI cable to the HDMI port of your video/computer device. Then connect the other end of the cable to the HDMI port of your projector. USB C Connection Connect one end of an USB C cable to the USB C port of your video/computer device.
  • Page 23 The connection illustrations below are for reference only. The connecting jacks available on the projector vary with each projector model. Some cables may not be included with the projector. They are commercially available from electronics stores. AUDIO IN USB C RS232 SERVICE HDMI 1...

  • Page 24: Operation

    Operation Turning the Projector On/Off Starting Up the Projector 1. Press the Power button to turn on the projector. 2. The light source will light up, and a “Power On/Off Ring Tone” will play. 3. The Power Indicator Light stays green when the projector is On.

  • Page 25: Shutting Down The Projector

    Shutting Down the Projector 1. Press the Power or Off button and a confirmation message will appear to prompt you to press the Power or Off button a second time. Additionally you can press any other button to cancel. If you do not respond in a few seconds after the first press, the message will NOTE: disappear.

  • Page 26: Selecting An Input Source

    Selecting an Input Source The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. If you want the projector to automatically search for the input source, ensure the Quick Auto Search function in the SYSTEM menu is On.

  • Page 27: Adjusting The Projected Image

    Adjusting the Projected Image Adjusting the Projector's Height and Projection Angle The projector is equipped with one (1) adjuster foot. Adjusting the foot will change the projector’s height and the vertical projection angle. Carefully adjust the foot to fine tune the projected image’s position. Fine-Tuning the Image Size and Clarity To adjust the projected image to the size that you need, rotate the Zoom Ring.

  • Page 28: Correcting Keystone

    Correcting Keystone Keystoning refers to the situation where the projected image becomes a trapezoid due to angled projection. To correct this, besides adjusting the height of the projector, you may also: 1. Use the Left/ Right/ Up/ Down keys on the projector or remote control to display the keystone page (when the input source is not SMART SYSTEM).

  • Page 29: Adjusting 4 Corners

    Adjusting 4 corners You can manually adjusts the shape and size of an image that is unevenly rectangular on all sides. 1. To display the Corner Adj. page, you can do one of the followings: • Press ENTER/OK. • Open the OSD menu and go to the DISPLAY >...

  • Page 30: Menu Functions

    Menu Functions This section will introduce the On-Screen Display (OSD) Menu and its options. General On-Screen Display (OSD) Menu Operation The OSD screenshots in this manual are for reference only and may differ from NOTE: the actual design. Some of the following OSD settings may not be available. Please refer to the actual OSD of your projector.

  • Page 31: On-Screen Display (Osd) Menu Tree

    On-Screen Display (OSD) Menu Tree Menu Option Main Menu Sub-menu DISPLAY Aspect Ratio Auto 16:9 16:10 2.35:1 Native Keystone Auto V Keystone Off/On Vertical +40~-40 Horizontal +40~-40 Corner Adj. Top-Right Top-Left Bottom-Right Bottom-Left Zoom 0.8X ~2.0X OverScan Off/1/2/3/4/5 3X Fast Input Inactive Active...
  • Page 32 Menu Option Main Menu Sub-menu IMAGE Color Mode Brightest Gaming Movie User 1 User 2 Brightness 0~100 Contrast -50~50 Color Temp. 9300K/7500K/6500K Red Gain 0~100 Green Gain 0~100 Blue Gain 0~100 Red Offset -50~+50 Green Offset -50~+50 Blue Offset -50~+50 Advanced Color -50~50...
  • Page 33 1~240 m Timer Display Always/1 min/2 min/3 min/Never Timer Position Top-Left/Bottom-Left/ Top-Right/Bottom-Right Timer Counting Direction Count Down/Count Up Sound Reminder Off/On Start Counting/Off Pattern Test Card Blank Timer Disable/5 min/10 min/15 min/20 min/25 min/30 min Message Splash Screen Black Blue ViewSonic...
  • Page 34 Menu Option Main Menu Sub-menu ADVANCED Auto/SDR EOTF Low/Mid/High 3D Settings 3D Format Auto Frame Sequential Frame Packing Top-Bottom Side-by-Side 3D Sync Invert Disable/Invert Save 3D Settings Yes/No HDMI Settings HDMI Format Auto/RGB/YUV HDMI Range Auto/Enhanced/ Normal Light Source Settings Light Source Mode Normal/Eco/ Dynamic Black 1/ Dynamic Black 2/Custom...
  • Page 35 Menu Option Main Menu Sub-menu SYSTEM Language Multi-Language OSD Selection Projector Position Front Table Rear Table Rear Ceiling Front Ceiling Menu Settings Menu Display Time 5 sec/10 sec/15 sec/20 sec/25 sec/30 sec Menu Position Center/Top-Left/ Top-Right/ Bottom-Left/ Bottom-Right High Altitude Mode Quick Auto Search Security Settings Change Password...

  • Page 36: Display Menu

    DISPLAY Menu button to display the On-Screen Display (OSD) Menu. 1. Press the MENU or 2. Press to select the DISPLAY menu. Then press ENTER/OK or use access the DISPLAY menu. to select the menu option. Then press 3. Press ENTER/OK to display its sub- to adjust/select the setting.
  • Page 37 Menu Option Description Aspect Ratio Auto Scales an image proportionally to fit the projector’s native resolution in its horizontal width. This is suitable for the incoming image which is neither in 4:3 nor 16:9 and you want to make most use of the screen without altering the image’s aspect ratio.
  • Page 38 Menu Option Description This function is favorable to frame rate reducing. Quick 3X Fast Input response time in native timing can be achieved. When enabled, the following settings (if applicable) will return to factory preset values: Aspect Ratio, Zoom, OverScan. This function is only available when a native timing input NOTE: signal is selected.

  • Page 39: Image Menu

    IMAGE Menu button to display the On-Screen Display (OSD) Menu. 1. Press the MENU or 2. Press to select the IMAGE menu. Then press ENTER/OK or use access the IMAGE menu. to select the menu option. Then press 3. Press ENTER/OK to display its sub- to adjust/select the setting.
  • Page 40 Menu Option Description Color Mode Brightest Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high brightness is required, such as using the projector in well lit rooms. Optimized for viewing sports in well-lit environments. Gaming Suitable for playing video games in a bright living room.
  • Page 41 Menu Option Description Advanced Color A lower setting produces less saturated colors. If the setting is too high, colors will be overpowering and may appear unrealistic. Sharpness A higher value will sharpen the image, while a lower value will soften the image. Gamma Gamma refers to the brightness level of the projector’s grayscale levels.

  • Page 42: Power Management Menu

    POWER MANAGEMENT Menu button to display the On-Screen Display (OSD) Menu. 1. Press the MENU or 2. Press to select the POWER MANAGEMENT menu. Then press ENTER/OK or to access the POWER MANAGEMENT menu. to select the menu option. Then press 3.
  • Page 43 Menu Option Description Signal Auto Power On Selecting HDMI allows the projector to turn on automatically once the HDMI/USB C signal is fed through the HDMI/USB C cable. This projector supports CEC (Consumer Electronics Control) function for synchronized power on/off operation via HDMI connection.
  • Page 44 Menu Option Description Standby Settings The functions below are available in standby mode (plugged in, but not turned on). Audio Pass Through When selecting On, the projector outputs an audio signal when the Audio In and Audio Out sockets are correctly connected to a proper device.

  • Page 45: Basic Menu

    BASIC Menu button to display the On-Screen Display (OSD) Menu. 1. Press the MENU or 2. Press to select the BASIC menu. Then press ENTER/OK or use access the BASIC menu. to select the menu option. Then press 3. Press ENTER/OK to display its sub- to adjust/select the setting.
  • Page 46 Menu Option Description Audio Settings Audio Mode Select a prefereed audio mode to suit your audio content. Mute Select to temporarily turn off the projector’s internal speaker or the volume being output from the audio output jack. Audio Volume Adjusts the volume level of the projector’s internal speaker or the volume being output from the audio output jack.
  • Page 47 Menu Option Description Pattern Helps adjust the image size and focus, and checks for distortion in the projected image. Blank Timer Allows the projector to return the image automatically after a period of time when there is no action taken on the blank screen.

  • Page 48: Advanced Menu

    ADVANCED Menu button to display the On-Screen Display (OSD) Menu. 1. Press the MENU or 2. Press to select the ADVANCED menu. Then press ENTER/OK or use access the ADVANCED menu. to select the menu option. Then press 3. Press ENTER/OK to display its sub- to adjust/select the setting.
  • Page 49 Menu Option Description The projector supports HDR imaging sources. It can automatically detect the dynamic range of the source, and optimize image gamma and color settings to reproduce contents under wide range of light conditions. You also select SDR. EOTF The projector can automatically adjust the brightness levels of your image according to the input source.
  • Page 50 Menu Option Description HDMI Settings HDMI Format Select a suitable color space according to the color space setting of the output device connected. ͫ Auto: Sets the projector to detect the color space setting of the input signal automatically. ͫ RGB: Sets the color space as RGB. ͫ...
  • Page 51 Menu Option Description Reset Settings Returns all settings to the factory preset values. When using Reset Settings, the following settings will still remain: Zoom, Keystone, Language, Projector Position, High Altitude Mode, Security Settings, Control Method, and Baud Rate.

  • Page 52: System Menu

    SYSTEM Menu button to display the On-Screen Display (OSD) Menu. 1. Press the MENU or 2. Press to select the SYSTEM menu. Then press ENTER/OK or use access the SYSTEM menu. to select the menu option. Then press 3. Press ENTER/OK to display its sub- to adjust/select the setting.
  • Page 53 Menu Option Description Sets the language for the On-Screen Display (OSD) Menu. Language Selects a proper position for the projector. Projector Position Menu Display Time Menu Settings Sets the length of time the OSD Menu will remain active after your last interaction. Menu Position Sets the OSD Menu’s position.

  • Page 54: Information Menu

    INFORMATION Menu button to display the On-Screen Display (OSD) Menu. 1. Press the MENU or 2. Press to select the INFORMATION menu and display its contents. Menu Option Description Source Shows the current input source. Color Mode Shows the selected mode in the IMAGE menu. Resolution Shows the native resolution of the input source.

  • Page 55: Smart System

    Smart System This section will introduce the SMART SYSTEM. Home Screen The screenshots in this manual are for reference only and may differ from NOTE: the actual design. Some of the following settings may not be available. Please refer to the actual design of your projector. The Home Screen is displayed when the input source is SMART SYSTEM.

  • Page 56: Menu Operations

    5. Upon successful connection, another sound effect will be audible. NOTE: The projector’s name will be labeled as “ViewSonic Projector”. Once paired, if both the projector and your device are powered on they will automatically connect via Bluetooth in Bluetooth Speaker mode. When...
  • Page 57 You can also connect the projector to external headphones or speakers that support Bluetooth: 1. Go to: Home Screen > Bluetooth. 2. Use the to select Bluetooth Out. Then press ENTER/OK. NOTE: Once paired, if both the projector and your device are powered on they will automatically connect via Bluetooth.
  • Page 58 Some Android devices support direct “Casting”. If your device does, go NOTE: to the Casting feature and choose “ViewSonic PJ-XXX” from the list of available devices. You can also scan the FAQ QR code and follow the steps to directly cast your Android device.
  • Page 59 3. Once removed, below dialogue box will appear. Application Access and view all the applications you have installed. To add an application to My Apps page or uninstall it: 1. After entering the Application page, all your applications are displayed. 2.
  • Page 60 succeeded, below dialogue box will appear and the application will be 3. Once displayed with an asterisk. My Apps page will be displayed under My Apps Applications that have been added to page from the homepage. To install an application: 1.

  • Page 61: Media Control Bar Buttons

    may require a keyboard or mouse to use. • Some applicaitons may be region-specific. Wallpaper ENTER/OK to set it as the wallpaper on the to select a wallpaper and press Home Screen. Media control bar buttons The media control bar buttons will appear on screen if a video or music file is played.

  • Page 62: Firmware Upgrade

    Extension Type Codec .mkv Video H.264 Video H.264, MPEG-2 .trp .mts Audio .m2ts Audio MPEG-1, MPEG-2 .vob Video DVD-LPCM .mpg Audio MPEG-1 Office formats Items Indicators doc/docx Able to open and read documents in doc/docx xls/xlsx Able to open and read documents in xls/xlsx Document viewing function ppt/pptx...
  • Page 63 2. Select Online update ENTER/OK. and press The system will check the ViewSonic website (OTA) and display below dialog message if there is a newer firmware. After selecting Download, a progress bar will appear as the download process begins.
  • Page 64 Upon reaching 100%, the following message will appear. Select Update Right Now. The Strat OTA update dialog message will appear. Select Update and the projector will restart the screen will turn black for a few minutes. The update process takes about 5 to 10 minutes. When finished, it will take a few minutes to restart the projector.
  • Page 65 Firmware update via a USB device 1. Download the latest firmware version form the ViewSonic website and copy the file to a USB device. Plug the USB device into the projector. 3. Go to Application > UPDATE > UpdateLocale. Click Select and press ENTER/OK.
  • Page 66 Select Update and the projector will restart the screen will turn black for a few minutes. The update process takes about 5 to 10 minutes. When finished, it will take a few minutes to restart the projector.

  • Page 67: System Related Settings

    System related settings More settings are available on the bottom list of the Home Screen. Settings Some functions may not be supported. The settings will be grayed out and NOTE: cannot be operated. Menu Option Description Network & Wi-Fi Sets the Wifi settings and AP hotspot. internet Portable hotspot Prvate DNS...
  • Page 68 Menu Option Description Displays the IP address of the System About IP address projector. device Wi-Fi MAC DIsplays the Wi-Fi MAC address. address Displays the Bluetooth address. Bluetooth address Build number Displays the version number of the system. Languages Languages You can set the language and input method here.
  • Page 69 Network Directly goes to the Wi-Fi page in the Settings. Storage cleaner Click this item to delete the log and apk files in the local storage and release the local storage space. Accelerator Click this item to terminate the processes that are not system’s. This operation can be performed when there are many APPs running in the back ground and the system response speed is slow.

  • Page 70: Appendix

    (14” x 4.8” x 9.6”) (14” x 4.8” x 9.9”) Weight Physical 3.6 kg (7.94 lb) Power 218 W (Typical) consumption < 0.5W (Standby) Please use the power adapter from ViewSonic® or an authorized source only. The test condition follows EEI standards.

  • Page 71: Projector Dimensions

    Projector Dimensions MENU BLANK EXIT ENTER SOURCE COLOR MODE 355 mm 121 mm MENU BLANK EXIT ENTER SOURCE COLOR MODE Timing Chart HDMI / USB-C Signal Resolution (dots) Aspect ratio Refresh rate (Hz) 640 x 480 04:03 60/70/75/85/120 SVGA 800 x 600 04:03 60/70/75/85/120 1024 x 768...
  • Page 72 HDMI / USB-C Signal Resolution (dots) Aspect ratio Refresh rate (Hz) UXGA 1600 x 1200 04:03 WUXGA 1920 x 1200 16:10 MAC 13" 640 x 480 04:03 MAC 16" 832 x 624 04:03 MAC 19" 1024 x 768 04:03 MAC 21" 1152 x 870 04:03 HDTV (1080p)
  • Page 73 3D (HDMI signal included) Signal Resolution (dots) Aspect ratio Refresh rate (Hz) 1280 x 720 16:09 60* / 120** WXGA 1280 x 800 16:09 60* / 120** HDTV (1080p) 1920 x 1080 16:09 for Video Signal SDTV (480i)*** 720 x 480 4:3 / 16:9 *60Hz signals are supported for Side-by-Side, Top-Bottom, and NOTE:...

  • Page 74: Troubleshooting

    Troubleshooting Common Problems This section describes some common problems that you may experience when using the projector. Problem Possible Solutions • Ensure the power cord is properly attached to the The projector does not turn on projector and to the power outlet. •...

  • Page 75: Led Indicator

    LED Indicator Light Status and Description Orange Stand-by mode Green Flashing Powering up Green Normal operation Downloading Orange Flashing Burn in off Red Flashing once per second Fan error Red Flashing once per 3 seconds Thermal and temperature error Green & Red Flashing alternately Light source error...

  • Page 76: Maintenance

    • ViewSonic® does not recommend the use of any ammonia or alcohol-based cleaners on the lens or case. Some chemical cleaners have been reported to damage the lens and/or case of the projector. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners.

  • Page 77: Light Source Information

    Light Source Information This section will provided a better understanding of your projector’s light source. Light Source Hour When the projector is being used, the duration (in hours) of light source usage is automatically calculated by the built-in timer. To obtain the light source hour information: 1.
