Installation INSTRUCTIONS
14682-4
SINGLE LEVER RECESSED BATH & SHOWER TRIM
14683-4
SINGLE LEVER RECESSED SHOWER ONLY TRIM
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co.
reserves the right to make changes in product characteristics, packaging, or availability at any time without
notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove any debris.
2. Do not remove the plaster guard from the valve body until instructed to.
3. Install valve 880 according to the rough-in dimensions of 14683-4, Install valve 882 according to the
rough-in dimensions of 14682-4.
HANDLE OPERATION
Lift the handle gently. Turn clockwise for hot water, counter-clockwise for cold water.
ROUGH-IN DIMENSIONS
The finished wall
32~42
MIN107
53
or 40~49
162X162
14682-4
1114995-2A-C
The finished wall
53
32~42
MIN107
162X162
or 40~49
14683-4
