CyberData 011446 Installation Quick Reference

Keyhole Details
Top
Backplate
Bottom
Wall Mounting Options
Pre-Drill Hole
to 3/16" [4.8mm]
for Plastic Ribbed Anchors
2.750 inches [70mm]
Center to Center
Screw Accessory KIt
© 2017, CyberData Corporation, ALL RIGHTS RESERVED 931429B
Dimensions are in
Inches [Millimeter]
Use Provided Screw
and Anchors
for Mounting
Network
Cable
Cable
Through
Slot
Plug-in
Through
Here
Quick Reference
All manuals and user guides at all-guides.com
The IP Endpoint Company
Getting Started
• Download the Multicast VoIP Microphone Operations Guide PDF file, from the product page at:
http://www.cyberdata.net/voip/011446/
• Create a plan for the locations of your Multicast VoIP Microphones.
• WARNING: This product should be installed by a licensed electrician according to all local electrical and building codes.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation
instructions.
• WARNING: The PoE connector is intended for intra-building connections only and does not route to the outside plant.
• WARNING: This enclosure is not rated for any AC voltages!
Parts
(1) Multicast VoIP Microphone
Contacting CyberData
Corporate Headquarters
CyberData Corporation
3 Justin Court
Monterey, CA 93940, USA
Phone: 831-373-2601
Fax: 831-373-4193
http://www.cyberdata.net/
Quick Reference
Installation Quick Reference
Multicast VoIP Microphone
SIP Compliant
011446
Parameter Factory Default Setting
IP Addressing DHCP
a
IP Address 10.10.10.10
Web Access Username admin
Web Access Password admin
a
Subnet Mask 255.0.0.0
a
Default Gateway 10.0.0.1
a. Default if there is not a DHCP server present.
(1) Wall Mounting Kit
(2) #6 x 1.25 inches
Sheet Metal Screw
Sales: (831) 373-2601 ext. 334
Support: 831-373-2601 ext. 333
Support Website: http://support.cyberdata.net/
RMA Department: (831) 373-2601 ext. 136
RMA Email: RMA@CyberData.net
RMA Status: http://support.cyberdata.net/
Warranty Information: http://support.cyberdata.net/
931429B © 2017, CyberData Corporation, ALL RIGHTS RESERVED
(2) #6 Ribbed Plastic
Anchor
