CyberData 011446 Installation Quick Reference

Keyhole Details
Top
Backplate
Bottom
Wall Mounting Options
Pre-Drill Hole
to 3/16" [4.8mm]
for Plastic Ribbed Anchors
2.750 inches [70mm]
Center to Center
Screw Accessory KIt
© 2017, CyberData Corporation, ALL RIGHTS RESERVED
Dimensions are in
Inches [Millimeter]
Use Provided Screw
and Anchors
for Mounting
Network
Cable
Cable
Through
Slot
Plug-in
Through
Here
931429B Quick Reference
Installation Quick Reference
Multicast VoIP Microphone
The IP Endpoint Company
SIP Compliant
011446
Parameter
IP Addressing
a
IP Address
Web Access Username
Web Access Password
a
Subnet Mask
a
Default Gateway
a. Default if there is not a DHCP server present.
Getting Started
• Download the Multicast VoIP Microphone Operations Guide PDF file, from the product page at:
http://www.cyberdata.net/voip/011446/
• Create a plan for the locations of your Multicast VoIP Microphones.
• WARNING: This product should be installed by a licensed electrician according to all local electrical and building codes.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation
instructions.
• WARNING: The PoE connector is intended for intra-building connections only and does not route to the outside plant.
• WARNING: This enclosure is not rated for any AC voltages!
Parts
(1) Multicast VoIP Microphone
Contacting CyberData
Corporate Headquarters
Sales: (831) 373-2601 ext. 334
CyberData Corporation
Support: 831-373-2601 ext. 333
3 Justin Court
Support Website:
Monterey, CA 93940, USA
RMA Department: (831) 373-2601 ext. 136
RMA Email: RMA@CyberData.net
Phone: 831-373-2601
Fax: 831-373-4193 RMA Status:
http://www.cyberdata.net/
Warranty Information:
Quick Reference
Factory Default Setting
DHCP
10.10.10.10
admin
admin
255.0.0.0
10.0.0.1
(1) Wall Mounting Kit
(2) #6 x 1.25 inches
(2) #6 Ribbed Plastic
Sheet Metal Screw
Anchor
http://support.cyberdata.net/
http://support.cyberdata.net/
http://support.cyberdata.net/
