How to pack a STX1000

Secure the Handler with air pad foil and safe the carrousel with the transport lock and etafon pads.

Put air pad foil between the glass- and Frontdoor.

Packing_STX1000.doc

Cut a piece of

bubble wrap, fold

it once and roll it.

Management-Handbuch

Apply a piece of adhesive tape

to keep the roll in shape

Transport lock

Etafon pads to safe the carrousel

2010.10.18

Produktion

Lift the Handling lift assembly by

hand and place the roll under it.

Page 1 of 3

Table of Contents

Do you have a question about the STX1000 and is the answer not in the manual?

Page 1 Management-Handbuch Produktion How to pack a STX1000 Apply a piece of adhesive tape to keep the roll in shape Cut a piece of bubble wrap, fold it once and roll it. Lift the Handling lift assembly by hand and place the roll under it.
Page 2 Management-Handbuch Produktion Pack the Unit in protection foil. Screw the „Etafon“ on the palette and then put the unit on. Attention: There has to be 20mm space between the Incubator and the palette. Packing_STX1000.doc 2010.10.18 Page 2 of 3...
Page 3 Management-Handbuch Produktion The screwing: Screw each side wall together with the palette with two screw at the outer bottom corner at first at the middle. and then with one screw Next step, screw the sidewalls at the upper corners together, also with two screws. Place screws the whole edge with a distance of 350 mm.
