- Page 1 All manuals and user guides at all-guides.com Revision :1.0 AR-ES5495 Installation Guide Revision Description Date Release 2009/11/25...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com Revision :1.0 Contents Introduction to AR-ES5495………………………………………………….……… 3 1.1 Specifications…………………………………………………………………… 3 1.2 Packing List……………………………………………………………………… 3 1.3 System Dissection………………………………………………………………. 4 1.3-1 Dimensions………………………………………………………………… 4 1.3-2 Front Panel………………………………………………………………… 4 1.3-3 I/O Bracket………………………………………………………………… 5 1.4 System Configuration ………………………………………………………………………... -
Page 3: Introduction To Ar-Es5495
Revision :1.0 1 Introduction to AR-ES5495 AR-ES5495 is an Intel Atom N270 + 945GSE chipset based platform; it provides fanless, low power consumption, tiny size, easy installation and light weight for you. It is design for low cost communication device; user can use it to build up simply internal communication environment. -
Page 4: System Dissection
All manuals and user guides at all-guides.com Revision :1.0 1.3 System Dissection 1.3-1 Dimensions 230mm 1.3-2 Front Panel HDD Led(red) Power Led(green) Power Button 2 x USB Reset Botton... -
Page 5: I/O Bracket
1.3-3 I/O Bracket Parallel Port LAN Port x 2 Line-out PS2 Mouse PS2 Keyboard VGA1 Port Microphone Power Inlet Serial Port USB Port x 4 Serial Port (COM1) (COM2) 1.4 System Configuration Power Supply AR-ES5495 Case IDE DOM HDD Bracket AR-B5495 Board... -
Page 6: Procedure Of Assembly/Disassembly
All manuals and user guides at all-guides.com Revision :1.0 2 Procedure of Assembly/Disassembly 2.1 HDD Installation The following instructions guide you to install 3.5” HDD 1. Unscrew two screws to unfasten the top cover. Unscrew Unscrew 2. Take off the top cover. - Page 7 All manuals and user guides at all-guides.com Revision :1.0 3. Unscrew screws of the HDD-Bracket and take off the HDD-Bracket. Put the 3.5” HDD on the HDD-Bracket and fix it by four screws.
- Page 8 All manuals and user guides at all-guides.com Revision :1.0 5. Plug in the SATA cable and SATA power cable to the 3.5”HDD. 6. Then connect the SATA cable and SATA power cable to the AR-B5495 board. SATA cable SATA power cable...
- Page 9 All manuals and user guides at all-guides.com Revision :1.0 7. Put the HDD-Bracket back to chassis and fix it. Screw Screw 8. Fixed the top cover with the chassis. Screw Screw...
-
Page 10: Installation Memory Module
All manuals and user guides at all-guides.com Revision :1.0 2.2 Installation Memory Module 1. Please follow the steps above to remove the top cover. 2. Open the two latch of memory slot. RAM module Latch 2. Align the memory cutout with the memory module slot notch. Cut out Notch... - Page 11 All manuals and user guides at all-guides.com Revision :1.0 3. Slide the memory into the memory module. PUSH Check that the latches are closed, and memory module is firmly installed.
-
Page 12: Installation Ide-Dom
All manuals and user guides at all-guides.com Revision :1.0 2.3 Installation IDE-DOM 1. The IDE-DOM slot please look at below photo. IDE-DOM slot 2. Install IDE-DOM on below position. First pin...
