ACS-N0831FLUD Installation Guide Version 1.0...
Page 2
Contents Introduction to ACS-N0831FLUD……………………………… 1-1 Description……………………………… 1-2 Packing List 1-3 Main system Procedure of Assembly/Disassembly……………………………… 4 2-1 Installing the 2.5”Hard Disk Drive(HDD)………………………... 4 2-2 Installing the Memory card…………………………………… 2-3 Installing Extension PCI card ………………………...
Page 3
1. Introduction to ACS-N0831FLUD The ACS-N0831FLUD is a system product mainly for ticket control, navigation, advertising, fleet managements applications. With fanless-design & powerful Intel CPU core, ACS-N0831FLUD can satisfy the users requirement in any application environment. ACS-N0831FLUD has diverse physical interface in the front panel, such as 2*10/100 LAN connectors, build-in LEDs, 4 USB Ports, four console ports, DSUB 44P port, power switch &...
Page 4
1.3 Main system (1) Dimension (2) Outlet (front side board)
Page 5
2. Procedure of Assembly/Disassembly 2-1 Installing the 2.5”Hard Disk Drive (HDD) The following are instruction for installation. 1. Remove bottom door screws 2. Installing rubber on the HDD bracket...
Page 6
3. Lock HDD and Bracket use screw (4pcs) 4. Insert HDD cable to HDD 5. HDD to place at system 6. Lock bracket to case use screw 7. Lock bottom door screw...
Page 7
2-2 Installing CF card & SO-DIMM The following are instruction for installation. Install SO-DIMM 1. Remove bottom door screw 2. Un-install HDD 3. Install SO-DIMM 4. Re-install HDD 5. Lock bottom door screw Install CF card Remove CF bracket screw...
Page 8
Install CF card to CF bracket Insert to CF card Hole Lock CF bracket use screw...
