Ser[LOG]
Operator's Manual · Version 11.18

LAMBRECHT meteo GmbH ∙ Friedländer Weg 65‐67 ∙ 37085 Göttingen
Phone: +49 551 4958‐0 ∙ E‐Mail: info@lambrecht.net
LAMBRECHT meteo GmbH
Ser[LOG] Manual
Page 1 of 113

Advertisement

Table of Contents
loading

Related Manuals for Lambrecht Ser[LOG]

Summary of Contents for Lambrecht Ser[LOG]

  • Page 1 Ser[LOG] Operator's Manual · Version 11.18   LAMBRECHT meteo GmbH ∙ Friedländer Weg 65‐67 ∙ 37085 Göttingen  Phone: +49 551 4958‐0 ∙ E‐Mail: info@lambrecht.net LAMBRECHT meteo GmbH Ser[LOG] Manual Page 1 of 113...

  • Page 2: Table Of Contents

    Connection diagrams....................86 Supported serial protocols..................95 List of predefined sensors..................98 Jumper field terminating resistor and interface driver RS485 / RS422 .....104 Warranty ........................106 Ser[LOG] sensor assignment.................107 ASCII character table ....................111 Technical data......................112 LAMBRECHT meteo GmbH Ser[LOG] Manual Page 2 of 113...
  • Page 3 The use, storage, modification, copying and distribution of any content require our prior written consent. All brand and product names mentioned in this manual are registered trademarks and property of their respective owners. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 3 of 113...
  • Page 4 Description Ser[LOG]........................9 Description Ser[LOG] for serial sensors................11 Description AnDiMod · Measurement modul for analogue / digital sensors ......14 Description Ser[LOG]Plus · Combined logger for serial, digital and analogue sensors..15 Wiring - Device Connection......................16 Supply voltage ........................16 Connection - Serial devices....................
  • Page 5 Assignment of SDI-12 sensors to the measurement channels ......45 5.3.6.3.5 Assignment of Modbus RTU sensors to the measurement channels ....46 5.3.6.3.6 Assignment of Modbus TCP sensors to the measurement channels ....46 LAMBRECHT meteo GmbH Ser[LOG] Manual Page 5 of 113...
  • Page 6 Area monitoring ........................77 7.4.1 Simple area monitoring (OR operation)................77 7.4.2 Group-related area monitoring (AND operation) ............. 78 7.4.3 Modbus relay ........................80 7.4.4 Definition of new Modbus relays..................81 LAMBRECHT meteo GmbH Ser[LOG] Manual Page 6 of 113...
  • Page 7 Configuration of wind data processing ..............82 SDI-12 Dialogue - Tool ....................83 Firmware Update .......................84 Other functions - USB stick readout................85 Connection diagrams....................86 12.1 Overview - Terminal assignment Ser[LOG]Plus..............86 Supported serial protocols..................95 13.1 NMEA ............................ 95 13.2 RPT350..........................95 13.3 PTB330..........................
  • Page 8 Adding terminating resistors for RS485 or RS422 .............. 105 Warranty ........................106 Ser[LOG] sensor assignment.................107 17.1 Sensor assignment - AnDiMod or Ser[LOG]Plus analog section........108 17.2 Sensor assignment - AnDiMod or Ser[LOG]Plus analog section........109 17.3 Sensor assignment - AnDiMod or Ser[LOG]Plus analog section........110 ASCII character table ....................111...

  • Page 9: Description Ser[Log]

    A maximum of 60 channels are supported, wherein each respective channel corresponds to one measured parameter. The Ser[LOG]Plus already includes an AnDiMod module with the address 1 in its housing and can be extended by 2 more AnDiMod modules (address 2 and 3) each extension offering up to 36 analogue and 11 digital channels.
  • Page 10 Ser[LOG] can be easily and quickly assigned by "point and click" with sensors from the LAMBRECHT product range. In addition, users can add their own sensors and thus extend the sensor library.

  • Page 11: Description Ser[Log] For Serial Sensors

    AnDiMod measurement modules. The modules also provide this voltage to supply the sensors. This means that for the sensor supply terminals always re- ceive the same voltage as the Ser[LOG] unit. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 11 of 113...
  • Page 12 The COM1 to COM4 may be configured with the Ser[LOG] -Commander to RS232. An RS232 interface with handshake line is only available on the COM1. COM2 to COM6 can be switched via jumper RS485 (default) to RS422. The COM1 LAMBRECHT meteo GmbH Ser[LOG] Manual Page 12 of 113...
  • Page 13 If the Ser[LOG] is extended with one or more AnDiMod modules, the connection is AnDiMod made via the 4-pin terminal on the bottom of the housing. terminal clamp LAMBRECHT meteo GmbH Ser[LOG] Manual Page 13 of 113...

  • Page 14: Description Andimod · Measurement Modul For Analogue / Digital Sensors

    The first module (upon extending a Ser[LOG]) must carry address 1. The first module (upon extending a Ser[LOG]Plus) must carry address 2, since AnDiMod with address 1 in Ser[LOG]Plus is already integrated. The respective address of AnDiMod is fixed and can not be customized by the user.

  • Page 15: Description Ser[Log]Plus · Combined Logger For Serial, Digital And Analogue Sensors

    Description Ser[LOG]Plus · Combined logger for serial, digital and analogue sensors The Ser[LOG]Plus consists of a Ser[LOG] and a AndiMod module (address 1) in a housing. Controls, interfaces and label are mostly identical. Since the Ser[LOG]Plus already has an integrated AnDiMod module has the COM6 interface is occupied by the AnDiMod module and COM6 terminal (unlabeled) is disabled.

  • Page 16: Wiring - Device Connection

    Example of lower jumper field: RS485 hardware driver for COM2 to COM6 activated. Note: In order to use the occupied COM interfaces, they must be switched on and configured with the Ser[LOG]-Commander. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 16 of 113...

  • Page 17: Special Case - Sensors With Rs485 Interface In Talker Mode Rs422

    Some sensors transmit their readings automatically within a fixed time interval; they are operating in the so-called talker mode. LAMBRECHT meteo sensors that have an RS485 interface and are oper- ated in talker mode, can be connected to the Ser[LOG] and to the "R +" and "R" terminal (Read-lines) of a RS422 configured interface.

  • Page 18: Special Case Sensors With Rs422 Interface In Talker Mode On Rs485

    Some sensors transmit their measured values automatically in a fixed time interval; they are then op- erated in the so-called talker mode. Sensors from LAMBRECHT meteo, which have an RS422 inter- face that is operated in talker mode, can also be connected to the "D+" and "D-" terminals of an inter- face configured as RS485 on the Ser[LOG].

  • Page 19: Connection - Pc With Rs232 Interface

    Ser[LOG]-Commander. Connection of analogue sensors Analogue sensors can be connected to the Ser[LOG]Plus or the AnDiMod modules. For each AnDi- Mod module (Ser[LOG]Plus already contains one), 12 analogue signals can be measured. The sys- tems can be expanded to a maximum of up to 36 analogue signals.

  • Page 20: Connection - Sensors With Voltage Signal

    Connection - Sensors with voltage signal Voltage signals can be measured by the Ser[LOG]Plus or AnDiMod up to a maximum of 5V. If sensors with higher voltages (e. g. 10 V) are to be measured, suitable voltage dividers must be used. For the measurement of millivolts (mV) signals, the analog inputs can be set to the measuring range ±...

  • Page 21: Connection Of Digital Sensors

    Connection - Sensors with pulse signals (counter) Sensors with pulse outputs (e. g. precipitation meter with tilting scale) can be connected to the inputs "D1","D2" and "D3" of the Ser[LOG]Plus or AnDiMod. Note: No pulses can be measured with the digi- tal inputs "DA" and "DB"!

  • Page 22: Connection Terminals For The Supply Of Sensors

    Connection terminals for the supply of sensors With Ser[LOG]Plus or AnDiMod, 6 sensors can be supplied with the voltage at each of the terminals "SENSOR SUPPLY", which is applied to the Ser[LOG]. VIN = VOUT (VIN=10... 30 VDC) applies. Important note: Do not remove more than 0.5 A in sum from all supply terminals (max. 18)!
  • Page 23 Ser[LOG] must have the address 1. The first module that can be used to expand a Ser[LOG]Plus must have the address 2, since an AnDiMod with the address 1 is already integrated in the Ser[LOG]Plus. An AnDiMod module with address 3 can only be connected to the Ser[LOG] if the AnDiMod modules with address 1 and address 2 have already been connected to the Ser[LOG] bus.
  • Page 24 Note: Do not connect more than 3 AnDiMod to the Ser[LOG] resp. 2 AnDiMod to the Ser[LOG]Plus. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 24 of 113...

  • Page 25: Display Menu

    By turning the rotary pushbutton, it is possible to switch between the individual sensors. The number of the measuring channel (01), the configured sensor designation and the current measured value are displayed. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 25 of 113...

  • Page 26: Data Export

    The configuration to be imported can have been saved by a Ser[LOG] via the "Data Export" function on the USB stick or was created using the Ser[LOG]Commander. The configuration file "serlog cfg" must be stored on a USB memory stick in the "serlog" directory. The import is started by the Config Import function.

  • Page 27: Firmware Update

    When all necessary data is set, a USB memory stick is required. Note: The input cannot be cancelled. If an incorrect password has been set by mistake, the function is aborted and the display returns to the basic menu. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 27 of 113...

  • Page 28: Bluetooth On

    While a Bluetooth adapter is connected, communication with other "wireless" devices (e. g. modem for GPRS / LTE / e-mail, FTP, SMS) cannot be carried out. The Bluetooth connection is switched off again by pressing the rotary pushbutton again or by removing the adapter. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 28 of 113...

  • Page 29: Info

    JJMMTTT/hhmmss (JJ=year, MM=month, TT=day, hh=hour, mm=minute, ss=second). Display Off The menu item "Display Off" switches the display off until the rotary pushbutton is pressed again. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 29 of 113...

  • Page 30: General Operation Of The Ser[Log]-Commander

    Ser[LOG] and Ser[LOG]Plus are put into operation, configured and tested with the configuration tool "Ser[LOG]-Commander". Ser[LOG]_Commander is a 32 bit Windows application that can be used under the operating systems Windows XP to Windows 10. The application can be used from a USB memory stick. Installation on the PC is not necessary.

  • Page 31: Configuring The "Ser[Log] Function

    Wind data Up to 2 pairs of wind sensors can be defined The data calculated here can be for which the moving average value is calcu- visualized with the LAMBRECHT lated. MeteoWare-CS3 software. Outputs Configuration of up to 10 switching channels and actuators for "process control","error...
  • Page 32 New record Saves the current configuration loaded in the display. Exits the configuration tool and closes the window. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 32 of 113...

  • Page 33: Function „Tools

    The information content corresponds to the "stan- nection via UDP dard format". UDP is only possible via network / Ethernet Stops data retrieval Exit function Exits the tool and closes the window. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 33 of 113...

  • Page 34: Function „Retrieve Measured Values

    Copies the currently opened sensor definition and displays a window for as- signing a new name for the sensor. Saves the currently opened sensor. Changes in factory defined sensors can- not be saved. Exit function. Exits the tool and closes the window. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 34 of 113...

  • Page 35: Function „Actuator Definition

    Construction and concentration of data files (station, sensor, relays) Data base reorganisation Change the language (currently German and English are available). Language After selection, the Ser[LOG]-Commander is terminated and must be restarted. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 35 of 113...

  • Page 36: Commissioning / Basic Configuration

    Ser[LOG] and Ser[LOG]Plus are put into operation, configured and tested with the configuration tool "Ser[LOG]-Commander". Ser[LOG]_Commander is a 32 bit Windows application that can be used under the operating systems Windows XP to Windows 10. The application can be used from a USB memory stick. Installation on the PC is not necessary.

  • Page 37: Configuration Via Mini-Usb Service Interface

    7 to Windows 10. This port operates independently of the set baud rate. After the PC has detected the USB connection, the "PC Settings" box appears in the "Interface" selec- tion field with the "LAMBRECHT Service Port". Select the "LAMBRECHT Service Port".

  • Page 38: Create New Configuration

    The number of measuring modules can be set in the frame "Analog Measuring Modules". With a Ser[LOG], the number of measurement modules is set to "0". With a Ser[LOG]Plus, an AnDiMod measurement module is already integrated in the housing. Therefore, check whether the number of measurement modules in the Ser[LOG]Plus is set to "1".

  • Page 39: Setting The Measured Value Storage

    In this case, the 3-second moving average value is generated directly in the Ser[LOG] and can be sent directly to further processing programs such as the LAMBRECHT MeteoWare CS-3 for display. The setting has no influence on the storage of the mean values.

  • Page 40: Communication Via Serial Interface Rs232 / Rs485 / Rs422

    If necessary, make the settings for "Handshake" and the baud rate (Baud). The settings for handshake and baud rate must match those in the "General" tab of the "Serial Interface" frame. Note the settings for later communication. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 40 of 113...

  • Page 41: Communication Via Gsm / Csd Modem

    5.3.5 Password for remote configuration The configuration is password protected. The default password is "Lambrecht". The password must also be entered in the "PC Settings" frame in the "Configuration Password" field. If the password is to be changed, it must first be changed in the "Station ID" frame of the remote con- figuration in the "Password CFG"...

  • Page 42: Configuration Of The Sensors

    Analog Digital Status (status) Serial / Virtual Ser[LOG] Ser[LOG]+1AnDiMod = Ser[LOG]Plus Ser[LOG]+2AnDiMod Ser[LOG]+3AnDiMod The designation in the "Channel" column designates the channel number and the connection to the Ser[LOG] or AnDiMod. S03 - 1 Kanal S03 belegt durch Analogeingang Klemme 1 von AnDiMod-Modul mit Adresse 1 DA/DB Statuseingang;...

  • Page 43: Configuration Global Radiation Sensors

    If no vector partner is selected in each case, the calculation of the mean value for the wind direction is still vectorial, whereby a wind speed of constant 1 m/s is calculated. In this case, the mean value of the wind speed is calculated scalar. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 43 of 113...

  • Page 44: Configuration Serial Sensors

    * Please note that for RS422 and RS485, the corresponding jumpers must also be set in the jumper field. See chapter 14. For more information about the supported protocols, see chapter “Protocols”. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 44 of 113...

  • Page 45: Setting The Data Retrieval Interval For Sdi-12, Modbus Rtu And Modbus Tcp Sensors

    For SDI-12 sensors, the address of the respective sensor must be specified. Note: SDI-12 sensors often supply several parameters. For the Ser[LOG], each parameter must be treated as a single sensor. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 45 of 113...

  • Page 46: Assignment Of Modbus Rtu Sensors To The Measurement Channels

    Assignment of virtual sensors to the measurement channels When selecting virtual sensors, the window "Definition of virtual sensors" is opened, in which the pa- rameters for calculating the respective value are defined. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 46 of 113...

  • Page 47: Configuration Of Sensors With Look-Up Table

    "OK" button (green token), the table is automatically sorted and saved. Note: If you want to delete a marker, simply double-click on the number field (1-15) of the respective line. Example: LAMBRECHT meteo GmbH Ser[LOG] Manual Page 47 of 113...

  • Page 48: Creating New Sensors

    The "Abbreviation" is the text that appears on the display of the data logger and is used by the LAMBRECHT programs "MeteoWare_CS" or "MeteoWare_Net_Center". Only a restricted charac- ter set (ASCII) is available for this field. A table with the permitted characters can be found in Chapter Enter the unit of the sensor in the "Unit"...
  • Page 49 Accordingly, you can select in the field "Exceeded" whether an error is reported if the maximum value is exceeded or whether the measured value is set to the maximum value. See also chapter 5.3.6.5.8. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 49 of 113...
  • Page 50 Please also enter the rocker factor (mm per pulse) for this application. In addition, the Ser[LOG] calculates an frequency-dependent correction of the precipitation quantity. (The correction is only valid for LAMBRECHT precipitation sensors without integrated correction.) Harmonic mean Calculates and stores the harmonic mean value of the measured value.

  • Page 51: Channel Type - Analog

    Select the required measuring range. If you want to measure a voltage greater than 5 V, apply the voltage via a suitable voltage divider which generates a voltage suitable for Ser[LOG]. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 51 of 113...
  • Page 52 • Look_Up_Table_2 Scaling with the use of up to 15 calibration points in table 2. See also chapter 5.3.6.4 Configuration of sen- sors with look-up table Example: Sensor type “Polynom” LAMBRECHT meteo GmbH Ser[LOG] Manual Page 52 of 113...

  • Page 53: Channel Type - Status

    0 or 100. This means that an average value can be displayed for the status in %. A value of 50% then means that the status was 50% of the measurement interval active and 50% inactive. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 53 of 113...

  • Page 54: Channel Type - Digital

    The upper figure shows the scaling for a precipitation sensor with reed switch. The pulses are recalcu- lated minute by minute according to the correction of the intensity characteristic curve and multiplied by the rocker factor. In this case, a pulse = 0.1 mm/m² precipitation. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 54 of 113...

  • Page 55: Channel Type - Modbus

    Since there is no standardized value for the timeout in the Modbus protocol, a timeout time for the measured value can be defined in steps of 250 ms in the field "Timeout". LAMBRECHT meteo GmbH Ser[LOG] Manual Page 55 of 113...

  • Page 56: Channel Type - Sdi-12

    This example shows how the measured values are taken from an SDI data set that provides average, minimum and maximum values for a measured value for the period from data re- trieval to data retrieval. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 56 of 113...

  • Page 57: Channel Type - Serial (E. G. Nmea)

    Heading from the $HEHTD, $INHTD, $IIHTD protocol VTG Vessel Course Vessel course from the $INVTG, $IIVTG, $GPVTG protocol VTG Vessel Speed kt Vessel speed kt from the $INVTG, $IIVTG, $GPVTG protocol LAMBRECHT meteo GmbH Ser[LOG] Manual Page 57 of 113...

  • Page 58: Channel Type - Virtual

    Calculation of the wind direction from cosine and sine signal The input parameters for the respective formula are assigned during configuration of the measurement channels in the mask "Definition of virtual sensor". LAMBRECHT meteo GmbH Ser[LOG] Manual Page 58 of 113...

  • Page 59: Special Function For Sensor Definition

    180°. Service switch If a status input is defined as a "service switch", the mean value storage is sus- pended as long as the service state is > LAMBRECHT meteo GmbH Ser[LOG] Manual Page 59 of 113...

  • Page 60: Displaying Instantaneous Values

    On the analog channels it is determined that no sensor is connected and the channel is open. This cannot be detected on the digital channels. Serial channels indicate that no serial data is present. The button stops the data retrieval. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 60 of 113...

  • Page 61: Display Of The Current Electrical Raw Values

    5.3.4.1) of the PC setting (chapter 5.3.4). Pressing the "Start UDP instantaneous values" button starts the fast instantaneous value retrieval via UDP and the current scaled instantaneous values are displayed. The button stops the data retrieval. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 61 of 113...

  • Page 62: Display Of Moving Wind Data

    Over-Flow - The maximum permissible measurement value has been exceeded. Ov-Flow Under-Flow - The measured value has fallen below the minimum permissible value. Un-Flow No-Value - There is no valid measured value or no valid value can be supplied. No-Value LAMBRECHT meteo GmbH Ser[LOG] Manual Page 62 of 113...

  • Page 63: Recalling And Saving Measured Values

    The used field separators and the decimal characters that are used can be set under "Other functions" , "CSV settings". In this menu, you can define the date format and the decimal point / field separator for formatting the stored measured values. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 63 of 113...

  • Page 64: Display Measurement Data

    "Display measurement data". The function is started by pressing the button. The call of this function opens a Windows file dialog in which the data file can be selected. The data is displayed directly in tabular form. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 64 of 113...

  • Page 65: Ip Communikation

    All functions of the "IP Communication" tab and its sub-tabs can be deactivated with "IP OFF" in the "LAN / WAN" selection box. The corresponding functions are configured in the sub-tabs "GPRS","NTP","FTP","Email","SMS" and "Export Format". These are described in the following subchapters. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 65 of 113...

  • Page 66: Synchronization Of The Clock Via Ntp

    The "Path" field specifies the directory below the FTP root directory (for the logged on user) in which the data is to be stored. In the selection field "Dispatch interval" you can set the interval or time at which the data is stored on the FTP server. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 66 of 113...
  • Page 67 Settings for the export format.) The sequence of the data and its information content for FTP export is defined in the settings for the "Export format". See chapter 6.1.1.4. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 67 of 113...

  • Page 68: Transmission Of Measured Values Via Email / Email Alarm

    • • 11:00 23:00 Note: If the function is used in conjunction with mobile communication, a transmission interval of less than 30 minutes is not recommended for a poor network connection. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 68 of 113...

  • Page 69: Setting The Export Format For Ftp And Email

    60 channels can be selected according to their configuration (chapter 5.3.6). The sensors are selected in the column "Sensor". In the columns "Average", “Minimum” and “Maxi- mum” you can set the type of value that should be transferred. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 69 of 113...

  • Page 70: Settings For Ip Communication Via Mobile Radio Modem

    Modems from different manufacturers can be used for IP-based communication, provided that they support "PPP" (Point-to-Point Protocol). In the field "Operating mode" you can choose between • „virtual leased line“ or • „GPRS on demand“. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 70 of 113...

  • Page 71: Setting Sms Alarm

    With the "virtual leased line", the Ser[LOG] establishes a connection to the Lambrecht application "Me- teoWare CS3" or "MeteoWare-Net-Center". With "GPRS on demand" only one connection to the Internet is established. For both types, Ser[LOG] can use "NTP","FTP" and "Email". If "SMS" is activated, the data connection (2G, 3G, 4G) is termi- nated and an SMS connection is established every time an SMS is sent.
  • Page 72 FTP or e-mail. From a cost point of view, it can also be cheaper to use the alarm via email instead of the SMS alarm. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 72 of 113...

  • Page 73: Configuration Of The Switching Outputs And Alarms

    "Channel" selection box. The following 4 control and monitoring func- tions are available for each switching channel: • Process control • Cycle control • fault monitoring • Area monitoring LAMBRECHT meteo GmbH Ser[LOG] Manual Page 73 of 113...

  • Page 74: Process Control

    The time after the cycle time at which the respective switching channel is set to 0 (OFF) is set in the fields next to "Run-on" in hours (HH), minutes (MM) and seconds (SS). The duration of the switching process (time period) results from the sum of pre run + post run. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 74 of 113...
  • Page 75 Example of a combination of process control and cycle control In the example above, relay 1 switches on every minute for 20 seconds (10 seconds advance + 10 seconds follow-up) from 7:00 to 17:00. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 75 of 113...

  • Page 76: Error Monitoring

    Note: Error monitoring can be combined with process control and area monitoring. A simultaneous cycle control together with error monitoring at the same switching output is not possible! LAMBRECHT meteo GmbH Ser[LOG] Manual Page 76 of 113...

  • Page 77: Area Monitoring

    25 °C of global radiation (S 06) when the set maximum limit value is exceeded: 700 W/m². with a switch-on delay of 30 seconds or a switch-off delay of one minute. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 77 of 113...

  • Page 78: Group-Related Area Monitoring (And Operation)

    Note: The segment from "45 to 315 degrees around north" goes above the zero point of the full circle. Since the mini- mum numerical value must always be smaller than the maximum numerical value, the switching logic "ON outside" LAMBRECHT meteo GmbH Ser[LOG] Manual Page 78 of 113...
  • Page 79 For the 135 to 225 degree segment, however, the switching logic must be set to "ON within". LAMBRECHT meteo GmbH Ser[LOG] Manual Page 79 of 113...

  • Page 80: Modbus Relay

    (Modbus actuator bus) must be configured on a COM interface. For this purpose, the standard:"RS485" and the protocol: "Modbus relay" must be selected in the Ser[LOG] configuration under the register selection "Interface" for the COM interface used. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 80 of 113...

  • Page 81: Definition Of New Modbus Relays

    Commander then switches to a "new" definition window. In this mode, the "Modbus Relay" selection box is an input field in which you can enter the name of the Modbus relay. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 81 of 113...

  • Page 82: Configuration Of Wind Data Processing

    WG Vector averaging with linked wind speed measurement. vectorial with WG = 1 m/s Vector averaging with a unit wind speed of 1 m/sec. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 82 of 113...

  • Page 83: Dialogue - Tool

    SDI-12 devices. In the "Station" field, first select the Ser[LOG] via which the SDI-12 dialog is to be executed. The SDI-12 dialog is started with the button LAMBRECHT meteo GmbH Ser[LOG] Manual Page 83 of 113...

  • Page 84: Firmware Update

    5.3.1.1, chapter 5.3.1.2 and chapter 5.3.4. Malfunctions or damaged firmware cannot affect the Ser[LOG]. If no valid, valid firmware is delivered, the Ser[LOG] ignores the update attempt and continues to work with its existing firmware. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 84 of 113...

  • Page 85: Other Functions - Usb Stick Readout

    Important note: The application asks after downloading the data whether the USB stick should be deleted! It is therefore recommended to use a USB stick that is only intended for data export and does not contain any other important data! LAMBRECHT meteo GmbH Ser[LOG] Manual Page 85 of 113...

  • Page 86: Connection Diagrams

    Connection diagrams Overview - Terminal assignment Ser[LOG]Plus 12.1 LAMBRECHT meteo GmbH Ser[LOG] Manual Page 86 of 113...
  • Page 87 LAMBRECHT meteo GmbH Ser[LOG] Manual Page 87 of 113...
  • Page 88 LAMBRECHT meteo GmbH Ser[LOG] Manual Page 88 of 113...
  • Page 89 LAMBRECHT meteo GmbH Ser[LOG] Manual Page 89 of 113...
  • Page 90 LAMBRECHT meteo GmbH Ser[LOG] Manual Page 90 of 113...
  • Page 91 LAMBRECHT meteo GmbH Ser[LOG] Manual Page 91 of 113...
  • Page 92 LAMBRECHT meteo GmbH Ser[LOG] Manual Page 92 of 113...
  • Page 93 LAMBRECHT meteo GmbH Ser[LOG] Manual Page 93 of 113...
  • Page 94 LAMBRECHT meteo GmbH Ser[LOG] Manual Page 94 of 113...

  • Page 95: Supported Serial Protocols

    Proprietary protocol of Vaisala's LD-40 cloud height meter. The sensor is no longer available. 13.6 CL31 msg 2_base Proprietary protocol of the CL31 cloud height measuring device from Vaisala. 13.7 FS11 Proprietary protocol of the Vaisala FS11 visual range finder. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 95 of 113...

  • Page 96: Rain[E] 'Sdi-12 On Rs485

    SDI-12 sensors are configured in the Ser[LOG]-Commander via the COM5 interface. The Ser[LOG] supports only a subset of the SDI-12 specification. Only measured values from sensors generated with the CC command can be recorded. Predefined sensors in the sensor library are available for the LAMBRECHT rain[e]. LAMBRECHT meteo GmbH Ser[LOG] Manual...

  • Page 97: Snap

    "Modbus Actuator" must be selected accordingly. 13.20 Ser[LOG] – AnDiMod-Bus (only COM6) If the Ser[LOG] is extended by an AnDiMod module, the LAMBRECHT specific protocol "Ser[LOG] - AnDiMod-Bus" must be selected on the COM6 interface. LAMBRECHT meteo GmbH...

  • Page 98: List Of Predefined Sensors

    0 (wrong) at high level, e. g. 5V or switch open Serves as a basis for the definition of your own sensors. 14.1.2 LAMBRECHT status sensors E_16203.XX0004_Sunshine_duration Sunshine duration sensor (16203) with status output. 0 V = Sun does not shine and 1 V = Sun shines Service Status sensor that prevents the storage of all averages at values >...

  • Page 99: Predefined Analog Sensors

    Standard sensor for resistance measurements in the measuring range up to 500 Ω. Serves as a basis for the definition of own sensors. 14.3.2 LAMBRECHT analog sensors E_08091.000042_Humidity 4-20mA Humidity of the combined TH sensor 00.08091.000042 with 0…100%rh = 4…20 mA signal output E_08091.000042_T_4-20mA_-30-70°C...
  • Page 100 Second Class – Global radiation sensor with mV output. (EMK [in µV/(W/m²)] must be specified individually for each sensor.) E_16131.X00000_Radiation First Class – Global radiation sensor with mV output. (EMK [in LAMBRECHT meteo GmbH Ser[LOG] Manual Page 100 of 113...

  • Page 101: Available Serial Sensors

    NMEA Rel. Hum. Relative humidity from $WIMHU NMEA TA Air temperature from $WIMTA in °C NMEA TP Dew point from $WIMHU in °C NMEA TS Ground temperature from $WIMTS (LAMBRECHT specific) in °C LAMBRECHT meteo GmbH Ser[LOG] Manual Page 101 of 113...

  • Page 102: Additional Serial Sensors (Proprietary)

    LD40 Vertical Visibility m P2_Container_EZ P2_Container_NEZ Pluvio 2 precipitation sensor in SDI-12 mode. For detailed informa- P2_Int_EZ tion on the parameters, please refer to the instructions of the re- spective sensors. P2_Amount_by_total_NEZ P2_Amount_EZ-NEZ LAMBRECHT meteo GmbH Ser[LOG] Manual Page 102 of 113...

  • Page 103: Virtual Sensors

    If the primary sensor does not work or returns invalid values, the secondary sensor value is redundant air pressure processed further. If both sensors do not work, an error is displayed. redundant dew point LAMBRECHT meteo GmbH Ser[LOG] Manual Page 103 of 113...

  • Page 104: Jumper Field Terminating Resistor And Interface Driver Rs485 / Rs422

    4-pin terminal on the bottom of the housing. The AnDiMod modules occupy the COM6 interface and the COM6 connection is deactivated. Since the Ser[LOG]Plus already has an integrated AnDiMod module, COM6 is not available from the outset. COM2 to COM6 can be switched from RS485 (factory setting) to RS422 via jumper.

  • Page 105: Switching The Com2 To Com6 From Rs485 To Rs422

    By loosening the two Torx screws (size Tx6) the small cover on the right above the COM ports can be removed and the jumper fields underneath can be reached. LAMBRECHT meteo GmbH Ser[LOG] Manual Page 105 of 113...

  • Page 106: Warranty

    Please note the loss that unauthorised manipulation of the system shall result in the loss of warranty and non-liability. Changes to system components require express written permission from LAMBRECHT meteo GmbH. These activities must be performed by a qualified technician. The warranty does not cover: 1.

  • Page 107: Ser[Log] Sensor Assignment

    SDI-12 Note: SDI-12 occupies COM5 SDI-12 RS 422 RS 485 COM6 AnDiMod to Ser[LOG] bus Note: With Ser[LOG]Plus the COM6 is already occupied by an AnDiMod module! Digital sensors Interface Description Lambrecht Id No. Measurement range Status high-active / low-...

  • Page 108: Sensor Assignment - Andimod Or Ser[Log]Plus Analog Section

    17.1 Sensor assignment - AnDiMod or Ser[LOG]Plus analog section AnDiMod Address 1 AnDiMod Address 2 AnDiMod Address 3 Ser[LOG]Plus (analog) Analog sensors Scaling Interface Description Lambrecht Id No. Measurement range Unit Signal: Signal: Value: Value: Signal: Signal: Value: Value: Signal:...

  • Page 109: Sensor Assignment - Andimod Or Ser[Log]Plus Analog Section

    17.2 Sensor assignment - AnDiMod or Ser[LOG]Plus analog section AnDiMod Address 1 AnDiMod Address 2 AnDiMod Address 3 Ser[LOG]Plus (analog) Analog sensors Scaling Interface Description Lambrecht Id No. Measurement range Unit Signal: Signal: Value: Value: Signal: Signal: Value: Value: Signal:...

  • Page 110: Sensor Assignment - Andimod Or Ser[Log]Plus Analog Section

    17.3 Sensor assignment - AnDiMod or Ser[LOG]Plus analog section AnDiMod Address 1 AnDiMod Address 2 AnDiMod Address 3 Ser[LOG]Plus (analog) Analog sensors Scaling Interface Description Lambrecht Id No. Measurement range Unit Signal: Signal: Value: Value: Signal: Signal: Value: Value: Signal:...

  • Page 111: Ascii Character Table

    "E" , "u" "F" , "v" "G" , "w" "H" , "x" "I" , "y" "J" , "z" "K" , "{" "L" , "|" "M" , "}" "N" , "~" "O" LAMBRECHT meteo GmbH Ser[LOG] Manual Page 111 of 113...

  • Page 112: Technical Data

    NMEA, Modbus-RTU, Modbus-TCP, SDI12 and numerous proprietary protocols (other proto- cols available on request) Memory: 1 year in ring memory (8-byte IEEE real format) • independent of configuration Scope of delivery: USB cable • Configuration software Ser[LOG] Commander LAMBRECHT meteo GmbH Ser[LOG] Manual Page 112 of 113...
  • Page 113 Ser[LOG] extension: up to 3 AnDiMod Ser[LOG]Plus extension: up to 2 AnDiMod Ser[LOG] and Ser[LOG]Plus are max. expandable to: 36 analog / 11 digital inputs Resolution: 16-bit ADC (SAR) with up to 1024x oversampling Measurement data processing: 8-byte IEEE real format Power supply: via Ser[LOG] or Ser[LOG]Plus 10...30 VDC...

Table of Contents
