Specifications - Harman Infinity Reference 6001A Owner's Manual

WIRING FOR AUDIO OUTPUT
One subwoofer (4ohm/2ohm)
+ -
Subwoofer
SUB
L
R
Two subwoofers (4ohm)
+ -
Subwoofer
SUB
L
R
CONNECTING THE REMOTE BASS
CONTROLLER
+ -
Subwoofer
REMOTE
CONTROL
SETTING GAIN, CROSSOVERS, AND BASS
BOOST
Setting the gain
1. Start with
and the crossover control rotated midway.
2. Choose music with substantial bass
MAX
content.
GAIN
3. Turn the volume control on your receiver to
MIN
¾ of its total output.
4. Adjust the
listening carefully to the bass output. If
you hear distortion, turn the
counterclockwise to decrease the gain.
Selecting the crossover frequency
Choose the crossover point to suit listening
320Hz
preferences. Turn the dials to the left to lower
FREQ
the crossover point and to the right to raise
32Hz
the crossover point. Exact crossover settings
depend on your listening preferences.
Selecting the subwoofer phase
0°
Switch the
PHASE
determine which setting provides the most
clean bass output.
180°
Selecting the bass boost
12dB
BASS
Adjust the
BOOST
counterclockwise to suit your taste.
0dB

SPECIFICATIONS

Reference 6001A Reference 10001A
Power output @
350 watts RMS x 1 600 watts RMS x 1
4 ohms
Power output @
600 watts RMS x 1
2 ohms
Frequency response 10-320 Hz
32-320 Hz variable,
Crossover frequencies
12 dB/ octave
Line-level input 200 mVrms -
sensitivity 2.0 V rms
High-level input
2 Vrms - 20V rms.
sensitivity
Signal-to-noise ratio
THD+N @ rated
power
Fuse rating 30 A x 2
Operating voltage
8-11/16" x 2-1/16"
Dimensions (W x H x D) x 7-1/8" (220 mm x
51.3 mm x 180 mm)
Weight
Recommended wire
gauge
control set to minimum,
control clockwise,
control
back and forth to
control clockwise or
1000 watts RMS
x 1
10-320 Hz
32 - 320Hz Variable,
12 dB/ octave
200 mVrms -
2.0 V rms
2 Vrms - 20V rms.
>80 dB >80 dB
<1% <1%
35 A x 3
9~16 V 9~16 V
12-5/8" x 2-1/16"
x 7-1/8" (320 mm x
51.3 mm x 180 mm)
2.54 kg 3.58 kg
8 4
