1. Input Trim / ZaxNet Gain Control - The knob can be assigned to adjust input trim, or remote control the
control gain for the transmitter via ZaxNet
To assign a function press the FADER key on Aria or open the external fader menu in Nova
ZNet - When ZNet is selected, that knob will remotely adjust the input gain of the transmitter that is
•
assigned to that fader.
Input Trim - When Trim is selected that knob will adjust the input trim for the input assigned to that fader.
•
2. PFL key - The audio routed to a fader can be listed to pre-fader by pressing the PFL key - when pressed the
key will blink and the headphone monitor name will display what input is being listened to.
When the PFL Keys menu (located in the ENG Setup menu) is set to "Multi" additional inputs can be
•
simultaneously listened to by pressing additional PFL keys.
When the PFL Keys menu is set to "Single" only one input can be listened to at a time
•
To remove an input, press the PFL key again.
•

3. Star Key

Press to open the Setup menu for the input assigned to that fader.
•
When TRACK ROUTING is selected it will enable / disable that input to the mix track(s)
•
When RECORD ENABLES is selected it will enable / disable that inputs iso track.
•
When Fader assign is selected it will advance to that faders position in the external fader assign
•
menu.
4. 6 Segment Input LEDs - Displays the input audio levels for the assigned input.
5. Fader– Solid state faders.
