SOLOS Kids Standing Desk Shelf
Installation Guide
SD-KStand001-WH
STEP1
A
x4
B
x4
E
4x4
F
5x5
Connect the supporting metal plate(3) to the shelf panel(2)
with screw(A), and tighten it with 4*4 allen key(E)
STEP2
Install the decorative cover
Max:10KG
Install the supporting metal plate, shelf panel and Supporting cover
2
E
3
Press the decorative cover (6) into the hole of the lower shelf set(2)
A(M5x10mm)
B(ST4 .2x16mm)
4pcs
4pcs
1.Shelf Set X1
2.Lower Shelf Set X1
5.Upper Shelf
6.Decorative
Cover X2
Panel X1
8.Cushion X2 9.Briquetting X2
A
4
Press into
6
C (M4x8mm )
D (3x3)
4pcs
1pc
3.Supporting
4.Supporting coverX2
metal plate X2
7.Plastic Block X4
Anti-tip set X1
1
Place the shelf panel (1) on the supporting sheet
metal(3) from top to bottom, and then buckle into
the supporting cover(4), using screw(B) to tighten it
with 5*5 wrench (F)
E (4x4)
F(5x5)
1pc
1pc
F
B
