- Page 1 SOLOS Basic Standing Desk User Manual SKU: SD-B147 154 lbs 0.98"/s 100-240V 28.0" 47.6" 39.4"-63.0" 19.7"-31.5" Continuous operation for 2 mins at most after pause for 18 mins 0-40°C...
- Page 2 Install the Feet 0.2"x0.2" Install(1)&(2)(3) together,use 0.2’’x0.2’’/5x5mm wrench(C) to tighten the screws(A). Install Supporting beam(4) 0.16"x0.16" 0.2"x0.2" Please adjust the support beam size(4) according to table top size. Install supporting beam on the column(2)(3),tighten Tighten screws on supporting beam Loose screws on(4) with wrench 0.16’’x0.16’’/4x4mm(C),then screw(B) with wrench 0.2’’x0.2’’/5x5mm(C) with wrench0.16’’x0.16’’/4x4mm(C) stretch supporting beam...
- Page 3 Install Supporting plate(6) 0.2"x0.2" Install(6)&(2)(3),use Allen key 0.2’’x0.2’’/5x5mm to tighten the screws(A). Install baffle(8) Install desktop 0.1"x0.1" Distance≤200mm Install(8), use Allen key 0.1’’x0.1’’/2.5x2.5mm to tighten the screws. Install desktop with screw(F),use electric drill to tighten Connect all the cables onto the Adapter(7) Attach adapter(7) onto the desk top by cable tie(10) Use the cable tie(10) to fix all the connection cables on the desk to keep it clean.
- Page 4 How to use handswitch Adjust the desk upwards Adjust the desk downwards Instruction Press the UP button or DOWN button to lift or lower the height of desk surface Common fault treatment 154 lbs;...
