Residential Package
Gas / Electric
Features and Benefits
Refrigerant System
Environmentally friendly R410A refrigerant
•
• Copper tubing with enhanced fin coils
• External service gauge ports
Heat Exchanger
Aluminized steel tapered S-curve
•
• Crimped no weld construction for longer life
• L models comply with California Energy
Commission Low NOx regulations
Cabinet Construction
• Low profile, with compact footprint
Insulation to minimize heat loss plus reduce
•
sound
• Baked on pre-painted steel cabinet finish
• Easy service access
• Wire grill protection
• One piece "no leak" top design
Blower
Insulated compartment to reduce sound
•
• High efficiency multispeed motor for wide
airflow range
Controls
Solid state integrated blower control board
•
with L.E.D. diagnostics
• Direct spark ignition
Installation
• Full perimeter base rail system for easy
installation
Horizontal or down discharge, duct covers
•
provided
• Utility connections on "right side"
• Filter channels for 1" filter field provided
RGE 1 3
Warranty
• 10 year limited
warranty/lifetime heat exchanger warranty
available. See limited warranty document
for details.
13
SEER
Form No. DRGE13-100 (12/2011)
parts and compressor
Advertisement
Table of Contents
Related Manuals for Ducane RGE13
Summary of Contents for Ducane RGE13
-
Page 1: Features And Benefits
Residential Package Gas / Electric Features and Benefits Refrigerant System Environmentally friendly R410A refrigerant • • Copper tubing with enhanced fin coils • External service gauge ports Heat Exchanger Aluminized steel tapered S-curve • • Crimped no weld construction for longer life • L models comply with California Energy Commission Low NOx regulations Cabinet Construction • Low profile, with compact footprint Insulation to minimize heat loss plus reduce • sound • Baked on pre-painted steel cabinet finish • Easy service access • Wire grill protection • One piece “no leak” top design Blower Insulated compartment to reduce sound • • High efficiency multispeed motor for wide airflow range Controls Solid state integrated blower control board •... -
Page 2: Model Number Guide
Model Number Guide R GE Residential Packaged Gas / Electric SEER 13 Series Nominal Capacity 36 - 36,000 Btuh (24 through 60) Electrical and Physical Data Voltage/HZ/ Voltage Model Phase Range RGE13A24050(L) 208-230/60/1 197-253 15.7 RGE13A24075(L) RGE13A30050(L 208-230/60/1 197-253 19.3 RGE13A30075(L)P RGE13A36075(L)P 208-230/60/1 197-253 21.7 RGE13A36100P RGE13A42075(L)P 208-230/60/1 197-253 RGE13A42100(L)P... -
Page 3: Blower Performance
RCE13 Package Gas / Electric Performance Model BTUH SEER RGE13A24050(L)P 22,800 13.0 RGE13A24075(L)P RGE13A30050(L)P 28,000 13.0 RGE13A30075(L)P RGE13A36075(L)P 34,000 13.0 RGE13A36100P RGE13A42075(L)P 40,000 13.0 RGE13A42100(L)P RGE13A48100(L)P 46,000 13.0 RGE13A48125P RGE13A60100(L)P 56,000 13.0 RGE13A60125P Blower Performance Blower Model Tap* (1 - 5) RGE13A24***(L)P RGE13A30***(L)P RGE13A36***(L)P... - Page 4 Cooling Performance Extended Ratings Indoor Temp 65° Model DB/WB ºF Btuh 85/72 27,800 0.59 1.66 25,900 0.61 1.90 24,400 0.63 2.09 22,800 0.67 2.23 21,600 0.71 2.24 80/67 26,400 0.65 1.65 24,900 0.68 1.89 22,800 0.71 2.07 21,600 0.75 2.19 17,700 0.82 2.18 RGE13A24 75/63 25,100...
-
Page 5: Minimum Clearances To Combustible Material
RCE13 Package Gas / Electric Dimensions (in.) Model No. RGE13-24 RGE13-30 32-1/2 46-1/2 46-1/2 RGE13-36 RGE13-42 RGE13-48 34-1/2 55-1/2 50-1/2 RGE13-60 Model No. RGE13-24 RGE13-30 11-1/2 5-1/2 1-5/8 RGE13-36 RGE13-42 RGE13-48 5-1/2 1-5/8 RGE13-60 Model No. RGE13-24 RGE13-30 1-3/4 15-5/8 20-1/2... -
Page 6: Sound Ratings
Accessories Description Short Cycle Protector LP GAS Conversion Roof Curbs Roof Curbs Manual Fresh Air Damper Manual Fresh Air Damper Motorized Fresh Air Damper Motorized Fresh Air Damper Downflow Economizer Downflow Economizer Horizontal Economizer Horizontal Economizer Sound Ratings Sound Model RGE13A24***(L)P RGE13A30***(L)P RGE13A36***(L)P RGE13A42***(L)P... - Page 7 RCE13 Package Gas / Electric Accessories Dimensions inches (mm) ECONOMIZER DAMPERS - DOWNFLOW For 24, 30 and 36 Models Fresh Air Head with Filter 16-13/16 13-7/16 ECONOMIZER DAMPERS - HORIZONTAL Model No. RGE13A 24, 30, 36 17-5/8 RGE13A 42, 48, 60 21-3/4 FRESH AIR DAMPERS Manual Air Intake...
- Page 8 RCE13 Package Gas / Electric Accessories Dimensions inches (mm) ROOF CURB 1-1/2 (38) Insulated Pans Model No. RGE13A 24, 30, 36 1092 RGE13A 42, 48, 60 47-1/8 1197 44-1/8 1121 All specifications and illustrations subject to change without notice and without incurring obligations. Form No.
