Lifting very heavy patients requires special techniques
and specially designed lift equipment. Liko has developed
the Ultra product series to help lift such patients in a safe
and comfortable manner.
The Liko Ultra LiftPants also give very heavy patients the
chance to practice standing and gait training without risk
of falling. They also reduce the risk of injuries to care-
givers.
The Liko Ultra LiftPants aid in safe standing and gait
training for patients with poor balance and poor leg
function. The LiftPants allow the patient to move while
relieving him/her of a greater or lesser degree of body
weight.
The Liko Ultra LiftPants are equipped with two hip straps
on either side for more even weight distribution. There
are two different sizes.
In this document, the person being lifted is referred to as the patient and the person helping them is referred to as
the caregiver.
is a warning triangle used for situations that demand extra care and attention.
Read the instruction guide for both the sling and the lift used. Instruction guides are available for
downloading, free of charge, at www.liko.com.
Liko Ultra LiftPants™, Mod. 920
Product Description
Selecting a suitable lift
We recommend that at least two caregivers be present
when transferring a patient.
The Liko Ultra LiftPants can be used along with Liko's
overhead or mobile lifts. An overhead lift can be used
by the patient for unrestricted movement within the lift's
lifting area. You can choose between:
- Liko's UltraTwin system with two lift units. The maxi-
mum load is 500 kg (1100 lbs.), depending on which
individual products are included in the assembled lift
system. The UltraTwin system is available for both
stationary installation and for freestanding installation
in the UltraTwin FreeSpan.
- Viking XL for lifting up to 300 kg (660 lbs.). May be
equipped with arm rest to give extra support during
standing- and gait training
Instruction Guide
English
7EN160181-03
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hill-Rom Liko Ultra LiftPants 920
Summary of Contents for Hill-Rom Liko Ultra LiftPants 920
- Page 1 Liko Ultra LiftPants™, Mod. 920 Instruction Guide English 7EN160181-03 Product Description Lifting very heavy patients requires special techniques Selecting a suitable lift and specially designed lift equipment. Liko has developed We recommend that at least two caregivers be present the Ultra product series to help lift such patients in a safe when transferring a patient.
- Page 2 Table of Contents Safety Instructions ......................3 Care and Maintenance ....................3 Definitions .......................... 4 Applying the LiftPants ......................4-5 Adjustment of Loop Straps ....................6 Removing the LiftPants ...................... 6 Choosing the right size ....................... 7 Accessories ........................7 Overview, Liko Ultra LiftPants, Mod. 920................8 Recommended combinations ..................
- Page 3 Safety Instructions Before lifting, remember the following: • A responsible person within your organization should decide on a case-by-case basis whether one or more caregivers are needed. • Ensure that the sling selected meets the patient’s needs with reference to model, size, fabric and design. •...
- Page 4 Definitions Rear suspension straps Product label Serial number Label: Periodic Inspection Label: Individual marking (Belongs to) Size marking (only for size XXL) Loop straps Rear part Upper hip strap 10. Lower hip strap 11. Front part 12. Front suspension strap Applying the LiftPants The initial position when using the Liko Pull the front section of the...
- Page 5 Fasten the hip strap’s buckles and pull tight. Depending on the size Connect the rear suspension straps onto of the patient, either one or both hip straps may be fastened from the rear hooks on the sling bar, or onto the the standing position.
- Page 6 Adjusting the Loop Straps The loop straps should be neither A smaller person can have A larger person can have the too loose nor too tight around the suspension straps fed suspension straps fed through the upper body. Resistance with through an inner loop.
- Page 7 Choosing the right size Choosing the right size is important for a safe and secure lift and for reaching the required lift height. Liko Ultra LiftPants should reach above waist height but not so high that the loop straps cut into the armpits. Refer to the measurement table below for guidance.
- Page 8 Overview, Liko Ultra LiftPants, Mod. 920 Name Prod. No. Size Patient weight¹ Patient height¹ Maximum load² Material Liko Ultra LiftPants 35920328 200-500 kg (440-1100 lbs.) 170-210 cm (67-83 inch.) 500 kg (1100 lbs.) Net polyester Liko Ultra LiftPants 35920329 XXXL 200-500 kg (440-1100 lbs.) 170-210 cm (67-83 inch.) 500 kg (1100 lbs.) Net polyester ¹...
