Viking™ M
mobile lift
Service Manual
Prod. No. 2040005
S/N 7 100 101-7 200 200
DISCONTINUED 2012
Prod. No. 2040035
S/N 9 200 001 - 9 300 000
DISCONTINUED 2016
3EN370401 Rev. 21
ENGLISH
Prod. No. 2040015
S/N 7 500 401 - 7 600 500
DISCONTINUED 2016
Prod. No. 2040045
S/N 9 400 001 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Liko Viking M Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hill-Rom Liko Viking M Series

Summary of Contents for Hill-Rom Liko Viking M Series

  • Page 1 Viking™ M mobile lift Service Manual Prod. No. 2040015 Prod. No. 2040005 S/N 7 500 401 - 7 600 500 S/N 7 100 101-7 200 200 DISCONTINUED 2016 DISCONTINUED 2012 Prod. No. 2040035 Prod. No. 2040045 S/N 9 200 001 - 9 300 000 S/N 9 400 001 - DISCONTINUED 2016 3EN370401 Rev.
  • Page 2 Components (manufacturing parts) are not available after last manufacturing date. Repairs and maintenance may only be performed by personnel authorized by Hill-Rom and using original Liko™ spare parts. For information regarding Service and Maintenance education, contact your Hill-Rom representative. For contact information please visit our website: www.hill-rom.com www.liko.com...

  • Page 3: Table Of Contents

    5.3 Control Unit Jumbo Care ............. 32 6.0 Liko Service System ..............33 7.0 Periodic Inspection Information ..........34 8.0 Preventive Maintenance ............35 9.0 Product Changes ................ 36 Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...

  • Page 4: Technical Data

    * These measures depend on in which hole the mast is levelled and secured. See assembly instructions page 5. Viking M • 7EN137102-04 www .l i ko .com Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...
  • Page 5 Different measurements apply to Viking M lift depending on the height-setting position, see ”Assembly”, in the Instruction Guide. Reference measurement according to Standard EN ISO 10535:2006. Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...
  • Page 6 Different measurements apply to Viking M lift depending on the height-setting position, see ”Assembly”, in the Instruction Guide. Reference measurement according to Standard EN ISO 10535:2006. Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...

  • Page 7: Viking M 2040005

    Note: The measurements are based on the lift being equipped with standard sling bar. When changing to other lifting accessories, check that the lift still achieves desired lifting height. Different measurements apply to Viking M lift depending on the height-setting position, see “Assembly”. Reference measurement according to Standard EN ISO 10535:2006. Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...
  • Page 8 5. Check that the contact plates on the battery pack are not defected or broken. 5. If the lift still does not work satisfactorily, contact Hill-Rom. Battery charging does not work. 1. Check that the emergency stop button is not pushed in.
  • Page 9 5. HandControl IR indicates battery change. 6. If the lift works via the operation panel, change the HandControl IR. 7. If the problem persists, please contact Hill-Rom. 1. Make sure that the emergency stop is not engaged. The lift does not work up/down with the operation panel.
  • Page 10 4. Check that the hand control cable is correctly connected. 5. If the lift works via the operation panel, change the Hand Control. 6. If the problem persists, please contact Hill-Rom. 1. Check that the emergency stop button has not been pressed.
  • Page 11 7. Check that the base widht actuator cable is correctly connected to the control box. 8. If the problem persists, please contact Hill-Rom. 1. Check that the charger cables are connected correctly. The charger doesn’t work. 2. Make sure that the battery is properly seated in the control box.

  • Page 12: Viking M 2040015

    Check to ensure that battery contact plates in the hand control are not defective or broken. - There´s no charging function? a) Verify contact between control box and battery. Perform step 4. b) Check charging function. Perform step 5. 3EN902101-01 Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...
  • Page 13 - Make sure the spare part is mounted according to the assembly instruction. Document Number - Check all functions related to the changed spare part. - Repairs and maintenance may only be performed by personnel authorized by Hill-Rom and using original Liko™ spare parts. 3EN650203 Rev. 5 ENGLISH www.hill-rom.com...

  • Page 14: Discontinued

    Prod. No. 2040005, 2040015, 2040035 and 2040045. One spare parts list for each model. Make sure to order correct spare part. 197 308 264 311 159 485 486 160 263 Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...

  • Page 15: Spare Parts List

    Cable for Charging AU/NZ 3EN630237 21090011 Extension Cable US 3EN630218 31590011 Latch Universal SlingBar pair 3SE630229 Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift Spare Parts List • Liko™ Mobile Lifts 3EN800804 Rev. 2 www.hill-rom.com www.liko.com...
  • Page 16 Fits Universal SlingBar from S/N 1299511 20490028 Restoration set motor attachment 3SE640258 20490030 Outer Tube 3SE640260 Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift Spare Parts List • Liko™ Mobile Lifts 3EN800804 Rev. 2 www.hill-rom.com www.liko.com...
  • Page 17 3SE690208 20090081 Wheel Fork pair 3SE690209 20490052 SlingBar Assembly set 3SE690210 20490064 Actuator LA34 CBJ 3EN690277 Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift Spare Parts List • Liko™ Mobile Lifts 3EN800804 Rev. 2 www.hill-rom.com www.liko.com...

  • Page 18: Discontinued

    Prod. No. 2040005, 2040015, 2040035 and 2040045. One spare parts list for each model. Make sure to order correct spare part. 264 311 159 485 486 Service Tool 348 349 Liko™ Service System Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...

  • Page 19: Prod. No

    3SE650270 Can only be ordered if S/N (serial number) can be provided to Liko™ Customer Service. Will be programmed at Liko™ before delivery. 2 weeks delivery time from Hill-Rom/Liko™ Alvik, Sweden 20090026 Cable for charging EU 3EN630237 20090027 Cable for charging UK...
  • Page 20 3SE650216 21090019 Extension cable CBL 20 US, 3SE650216 2006107 Extra battery box 7EN137106 Instruction Guide Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift Spare Parts List • Liko™ Mobile Lifts 3EN800804 Rev. 2 www.hill-rom.com l www.liko.com...
  • Page 21 Fork locking attachment, 4 pair 3SE690208 20090081 Wheel Fork pair 3SE690209 20490052 SlingBar Assembly set 3SE690210 Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift Spare Parts List • Liko™ Mobile Lifts 3EN800804 Rev. 2 www.hill-rom.com l www.liko.com...

  • Page 22: Discontinued

    One spare parts list for each model. Make sure to order correct spare part. 264 311 159 485 486 348 349 Service Tool Liko™ Service System Liko™ Service System Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...

  • Page 23: Viking M 2040005

    3SE690227 Can only be ordered if S/N (serial number) can be provided to Liko™ Customer Service. Will be programmed at Liko™ before delivery. 2 weeks delivery time from Hill-Rom/Liko™ Alvik, Sweden 20090089 Hand control 6-Button 3SE690232 20090026 Cable for charging EU...

  • Page 24: Viking M 2040015

    Extension cable CBL20 21090019 Extension cable CBL 20 US, 3SE650216 2006107 Extra battery box 7EN137106 Instruction Guide Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift Spare Parts List • Liko™ Mobile Lifts 3EN800804 Rev. 2 www.hill-rom.com l www.liko.com...

  • Page 25: Viking M 2040035

    Wheel Fork pair 3SE690209 20490052 SlingBar Assembly set 3SE690210 20490057 Locking Ring CBL, 10 pce 3SE690231 Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift Spare Parts List • Liko™ Mobile Lifts 3EN800804 Rev. 2 www.hill-rom.com l www.liko.com...
  • Page 26 There are four models of Viking™ M mobile lift; Prod. No. 2040005, 2040015, 2040035 and 2040045. One spare parts list for each model. Make sure to order correct spare part. 159 485 486 161 263 Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...

  • Page 27: Viking M 2040045

    182904 from S/N 7102064 20490015 285 Rear Wheel 75 mm Standard 182903 from S/N 7102064 Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift Spare Parts List • Liko™ Mobile Lifts 3EN800804 Rev. 2 www.hill-rom.com l www.liko.com...
  • Page 28 S/N 7100308 20490038 Mast Viking M 3EN650269 including handle and motor attachment 20490040 Bracket Cover 3SE650273 Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift Spare Parts List • Liko™ Mobile Lifts 3EN800804 Rev. 2 www.hill-rom.com l www.liko.com...
  • Page 29 Control Box Jumbo Care 3SE690231 20490063 Hand control, buttons LED 3EN690276 kg/lbs 20490064 Actuator LA34 CBJ 3EN690277 Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift Spare Parts List • Liko™ Mobile Lifts 3EN800804 Rev. 2 www.hill-rom.com l www.liko.com...

  • Page 30: Service

    Resetting the Service Interval using the LSS, LDS or Manually, will reset the Accumulated Amp-hours (PAAxT), Accumulated Time (PAKT), Accumulated Operating Time (PADT) and Accumulated number of stops due to overload (PAOLUP). Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...

  • Page 31: Control Unit Cbl, Reset Service Interval Parameters

    * Indicates Service Periodic Inspection interval reached. ** Service Interval Parameters (the PAAxT, PAKT, PADT and PAOLUP are all used to determine Service intervals) *** Parameters to use in the Preventative Maintenance Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...

  • Page 32: Control Unit Jumbo Care

    Press the “fast speed” up and down buttons on the hand control or kg/lbs up and down buttons on the control box for 5 seconds. An audio signal will confirm the resetting. Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...

  • Page 33: Liko Service System

    CBL 20. It also gives the service technician the possibility to program the spare part on the field. Detailed information can be found in the instruction guide supplied with the product. Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...

  • Page 34: Periodic Inspection Information

    If you don’t have access, contact Ann-Christin Sundström for registration: E-mail: ann-christin.sundstrom@hill-rom.com, Tel: +46 (0)920 - 47 47 10 Periodic Inspection may only be performed by personnel authorized by Hill-Rom and using original Liko™ spare parts. Available Liko Periodic Inspections: •...

  • Page 35: Preventive Maintenance

    252 000 As (prod No 2040045) which comes first, provided that required Periodic Inspection and Preventive Maintenance is performed by personnel authorized by Hill-Rom and using original Liko™ spare parts. However certain parts have a shorter life cycle and will need to be replaced in order for the mobile lift to meet its expected life time.

  • Page 36: Product Changes

    Spring in Outer Tube altered. New screws to fasten the handle. Diagonal profile has been 7 503 472 shortened. 2009 OuterTube also introduced on Prod. No. 2040005. 7 108 587 Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...
  • Page 37 Viking M delivered with the old Slingbar Standard 450. 7 100 382 Width of base increased with 40 mm. 7 100 308 Viking M is from now on equipped with a new Adapter. Service Manual Viking™ M • 3EN370401 Rev. 21 www.liko.com www.hill-rom.com mobile lift...
  • Page 38 I www.liko.com Liko AB Nedre vägen 100 SE-975 92 Luleå , Sweden...
