KD-T922BT / KD-DB622BT
CD RECEIVER
INSTRUCTION MANUAL
RECEPTOR CON CD
MANUAL DE INSTRUCCIONES
CD-RECEIVER
GEBRUIKSAANWIJZING
RECEPTOR CD
MANUAL DE INSTRUÇÕES
JS_JVC_KD_T922BT_E_C.indd 1
JS_JVC_KD_T922BT_E_C.indd 1
KD-X38MDBT
DIGITAL MEDIA RECEIVER
INSTRUCTION MANUAL
RECEPTOR DE MEDIOS DIGITALES
MANUAL DE INSTRUCCIONES
DIGITALE MEDIAONTVANGER
GEBRUIKSAANWIJZING
RECEPTOR MÉDIA DIGITAL
MANUAL DE INSTRUÇÕES
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
ENGLISH
ESPAÑOL
NEDERLANDS
PORTUGUÊS
B5A-3547-00 [E]
20/1/2020 11:24:30 AM
20/1/2020 11:24:30 AM

Advertisement

Table of Contents
loading

Related Manuals for JVC KD-T922BT

Summary of Contents for JVC KD-T922BT

  • Page 1 ENGLISH ESPAÑOL NEDERLANDS PORTUGUÊS KD-T922BT / KD-DB622BT KD-X38MDBT CD RECEIVER DIGITAL MEDIA RECEIVER INSTRUCTION MANUAL INSTRUCTION MANUAL RECEPTOR CON CD RECEPTOR DE MEDIOS DIGITALES MANUAL DE INSTRUCCIONES MANUAL DE INSTRUCCIONES CD-RECEIVER DIGITALE MEDIAONTVANGER GEBRUIKSAANWIJZING GEBRUIKSAANWIJZING RECEPTOR CD RECEPTOR MÉDIA DIGITAL MANUAL DE INSTRUÇÕES...
  • Page 2 Informatie over het weggooien van elektrische en elektronische apparatuur en batterijen (particulieren) Dit symbool geeft aan dat gebruikte elektrische, elektronische producten en batterijen niet bij het normale huishoudelijke afval mogen. Lever deze producten in bij de aangewezen inzamelingspunten, waar ze gratis worden geaccepteerd en op de juiste manier worden verwerkt, teruggewonnen en hergebruikt.
  • Page 3 KD-T922BT/KD-DB622BT: Declaration of Conformity with regard to the RE Directive 2014/53/EU Declaration of Conformity with regard to the RoHS Directive 2011/65/EU Manufacturer: JVCKENWOOD Corporation The marking of products using lasers 3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, JAPAN The label is attached to the chassis/case and says that the component uses laser beams that have been EU Representative: classified as Class 1.
  • Page 4 Par la présente, JVCKENWOOD déclare que Por la presente, JVCKENWOOD declara que el JVCKENWOOD ezennel kijelenti, hogy a rádiové zariadenie „KD-T922BT/KD-DB622BT/ l’équipement radio « KD-T922BT/KD-DB622BT/ equipo de radio “KD-T922BT/KD-DB622BT/ „KD-T922BT/KD-DB622BT/KD-X38MDBT“ KD-X38MDBT“ vyhovuje smernici 2014/53/EÚ. KD-X38MDBT » est conforme à la directive KD-X38MDBT”...
  • Page 5 HRVATSKI / SRPSKI JEZIK Русский Käesolevaga JVCKENWOOD kinnitab, et JVCKENWOOD ovim izjavljuje da je radio oprema JVCKENWOOD настоящим „KD-T922BT/KD-DB622BT/KD-X38MDBT“ “KD-T922BT/KD-DB622BT/KD-X38MDBT” u skladu заявляет, что радиооборудование raadiovarustus on vastavuses direktiiviga s Direktivom 2014/53/EU. «KD-T922BT/KD-DB622BT/KD-X38MDBT» 2014/53/EL. Cjeloviti tekst deklaracije Europske unije o соответствует...
  • Page 6 SOFTWARE LICENSE AGREEMENT Article 4 Right pertaining to the Licensed Software Any and all copyrights and other rights pertaining to the Licensed Software and related documents The software embedded in the Product (hereinafter the "Licensed Software") provided by Licensor is shall belong to the Licensor or the original holder of the right who granted to the Licensor the license or copyrighted to or sublicensable by the Licensor, and this Agreement provides for the terms and conditions sublicense for the Licensed Software (hereinafter the "Original Rightholder"), and the User shall not be...
  • Page 7 Important Notice concerning the Software Article 9 Destruction of the Licensed Software If this Agreement is terminated pursuant to the provision of Article 8, the User shall destroy the Licensed -jansson Software, any related documents and copies thereof within two (2) weeks from such date of termination. Copyright (c) 2009-2012 Petri Lehtinen <petri@digip.org>...
  • Page 8 -CMP sha2 AUTHOR: Aaron D. Gifford - http://www.aarongifford.com/ The MIT License (MIT) Copyright (c) 2014 Charles Gunyon Copyright (c) 2000-2001, Aaron D. Gifford All rights reserved. Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without You may obtain a copy of the license at limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the...
  • Page 9 Copyright (c) 1995, 1996 Carnegie-Mellon University. All rights reserved. T-Kernel 2.0 Author: Chris G. Demetriou This product uses the source code of T-Kernel 2.0 under T-License 2.0 granted by T-Engine Forum (www.tron.org) Permission to use, copy, modify and distribute this software and its documentation is hereby granted, provided that both the copyright notice and this permission notice appear in all copies of the software, BSD-3-Clause derivative works or modified versions, and any portions thereof, and that both notices appear in supporting...

  • Page 10: Table Of Contents

    3 Set the basic settings Specifications ..................44 Digital Radio ..................... 9 Analog Radio ..................11 CD/USB/iPod................... 13 AUX......................15 Spotify ..................... 16 JVC Remote Application ............... 17 Bluetooth® ....................18 Bluetooth — Connection Bluetooth — Mobile phone Bluetooth — Audio ENGLISH Data Size: B6L (182 mm x 128 mm) JS_JVC_KD_T922BT_E_EN_2.indd 2...

  • Page 11: Before Use

    • Never put or leave any metallic objects (such as coins or metal tools) inside the unit to prevent a short circuit. • KD-T922BT/KD-DB622BT: If a disc error occurs due to condensation on the laser lens, eject the disc and wait for the moisture to evaporate.

  • Page 12: Basics

    Basics Faceplate Attach KD-T922BT: Volume knob Loading slot Detach How to reset Detach button Display window* Reset the unit within 5 seconds after detaching the faceplate. * Only for illustration purpose. On the faceplate Press B SRC. Turn on the power •...

  • Page 13: Faceplate Kd-Db622Bt

    Basics Faceplate Attach KD-DB622BT: Volume knob Loading slot Detach How to reset Detach button Display window* Reset the unit within 5 seconds after detaching the faceplate. * Only for illustration purpose. On the faceplate Press B SRC. Turn on the power •...

  • Page 14: Faceplate Kd-X38Mdbt

    Basics Faceplate Attach KD-X38MDBT: Volume knob Detach How to reset Detach button Display window* Reset the unit within 5 seconds after detaching the faceplate. * Only for illustration purpose. On the faceplate Press B SRC. Turn on the power • Press and hold to turn off the power. Adjust the volume Turn the volume knob.

  • Page 15: Getting Started

    Getting Started To set the date Turn the volume knob to select [DATE SET], then press the knob. Turn the volume knob to make the settings, then press the knob. Set the date in the order of “Day” “Month” “Year”. Press to exit.
  • Page 16 [CLOCK] [TIME SYNC] [ON]: The clock time is automatically set using the Clock Time (CT) data in FM Radio Data System signal (for KD-T922BT) or DAB signal (for KD-DB622BT/KD-X38MDBT). ; [OFF]: Cancels. [CLOCK DISPLAY] [ON]: The clock time is shown on the display even when the unit is turned off.

  • Page 17: Digital Radio

    Digital Radio (for KD-DB622BT/KD-X38MDBT) About DAB (Digital Audio Broadcasting) Search for an ensemble Press B SRC repeatedly to select DAB. DAB is one of the digital radio broadcasting systems available today. It can deliver digital quality sound without any annoying interference or signal Press S / T to search for an ensemble automatically.
  • Page 18 Digital Radio (for KD-DB622BT/KD-X38MDBT) Default: [XX] Select a service [TUNER SETTING] Press  DAB to enter DAB service select mode. [RADIO TIMER] (Except for KD-DB622BT) Turn the volume knob to select [SRVC] (service list), then press the Turns on the radio at a specific time regardless of the current source. knob.

  • Page 19: Analog Radio

    Analog Radio Digital Radio (for KD-DB622BT/KD-X38MDBT) [TI] [ON]: Allows the unit to temporarily switch to Traffic Information if available (“TI” indicator lights up). ; [OFF]: Cancels. [PTY SEARCH] Select a PTY code (see the following “PTY code or Program type”). If there is a station broadcasting a program of the same PTY code as you have selected, that station is tuned in.
  • Page 20 Analog Radio Select a stored station [MONO SET] [ON]: Improves the FM reception, but the stereo effect will be lost. ; [OFF]: Cancels. Press one of the number buttons (1 to 6). (or) [NEWS SET]* [ON]: The unit will temporarily switch to News Programme if available. ; Press [OFF]: Cancels.

  • Page 21: Cd/Usb/Ipod

    CD/USB/iPod Insert a disc Connect an iPod/iPhone (for KD-T922BT/KD-DB622BT) (for KD-T922BT) Eject disc Label side iPod/ USB input terminal iPhone Accessory of the iPod/iPhone* The source changes to CD automatically and playback starts. The source changes to iPod USB automatically and playback starts.
  • Page 22 CD/USB/iPod On the faceplate Select music drive Press and hold S / T. Reverse/Fast-forward While in USB source, press 5 MODE repeatedly. Press S / T. Select a track/file Stored songs in the following drive will be played back. • Selected internal or external memory of a smartphone (Mass Storage Press 2 J / 1 K.

  • Page 23: Aux

    CD/USB/iPod You can listen to music from a portable audio player via the auxiliary input Alphabet search (applicable only for iPod USB source and iPod BT source) jack. You can search for a file according to the first character. Preparation: Press Select [ON] for [BUILT-IN AUX] in [SOURCE SELECT]. (Page 7) Turn the volume knob to select a list, then press the knob.

  • Page 24: Spotify

    Spotify You can listen to Spotify on the following device. On the faceplate KD-T922BT: iPhone/iPod touch (via Bluetooth or via Play back/pause Press the volume knob. USB input terminal) or Android device (via Bluetooth) Press S*1 / T. Skip a track KD-DB622BT/KD-X38MDBT: Android device (via Bluetooth) Press 2 J / 1 K.

  • Page 25: Jvc Remote Application

    JVC Remote Application Spotify You can control the JVC car receiver from the following device using Search for a song or station JVC Remote application. • KD-T922BT: iPhone/iPod touch (via Bluetooth or via Press USB input terminal) or Android device (via Turn the volume knob to select a list type, then press the knob.

  • Page 26: Bluetooth

    [ANDROID Selects the Android device to use from the list. Rear panel LIST] • For KD-T922BT: Displayed only when [ANDROID] of [SELECT] is set to [YES]. [STATUS] Shows the status of the selected device. Microphone (supplied) [IOS CONNECTED]: You are able to use the application using the iPhone/ iPod touch connected via Bluetooth or USB input terminal.
  • Page 27 • Once the pairing is completed, the Bluetooth device will remain registered in the unit even if you reset the unit. To delete the paired device, see Search and select the name of your receiver (“KD-T922BT”/ [DEVICE DELETE] on page 23.

  • Page 28: Bluetooth - Mobile Phone

    Press and hold or the volume knob. When there is an incoming call: • KD-T922BT/KD-X38MDBT: While talking on the first incoming call... The buttons will blink in the color you have selected in [RING COLOR]. Answer another incoming call Press or the volume knob.
  • Page 29 Turn the volume knob to select an item (see the following table), then press the knob. [RING COLOR] (For KD-T922BT/KD-X38MDBT) Repeat step 2 until the desired item is selected or activated. [COLOR 01] to [COLOR 49] ([COLOR 08]): Selects the illumination color for Press to exit.
  • Page 30 Bluetooth® [RECENT CALL] (Applicable only if the phone supports PBAP.) Store a contact in memory 1 Press the volume knob to select a name or a phone number. You can store up to 6 contacts into the number buttons (1 to 6). •...
  • Page 31 [DEVICE DELETE] 1 Turn the volume knob to select a device to delete, then press the knob. Search and select the name of your receiver (“KD-T922BT”/ 2 Turn the volume knob to select [YES] or [NO], then press the knob.

  • Page 32: Bluetooth - Audio

    Bluetooth® The connectivity result flashes on the display. Bluetooth — Audio “PAIRING OK” and/or “HANDS-FREE OK”*1 and/or “AUD.STREAM OK”*2 and/ or “PBAP OK”*3: Compatible *1 Compatible with Hands-Free Profile (HFP) *2 Compatible with Advanced Audio Distribution Profile (A2DP) *3 Compatible with Phonebook Access Profile (PBAP) After 30 seconds, “PAIRING DELETED”...

  • Page 33: Audio Settings

    Listen to iPod/iPhone via Bluetooth Press to exit. (for KD-T922BT) To return to the previous setting item, press You can listen to the songs on the iPod/iPhone via Bluetooth on this unit. Press B SRC repeatedly to select iPod BT.
  • Page 34 Audio Settings [EASY EQ] Adjusts your own sound settings. [SUB.W LEVEL]*1 [SPK-OUT]*2 (Not applicable when 3-way crossover is selected.) • The settings are stored to [USER] in [PRESET EQ]. [SUB.W 00] to [SUB.W +06] ([SUB.W +03]): Adjusts • The settings made may affect the current settings of [PRO EQ]. the output level of the subwoofer connected via speaker [SUB.W SP]*1*2: [00] to [+06] (Default: [+03]...
  • Page 35 “PRESS” “VOLUME KNOB” For connections through an external amplifier (Page 42, 43) “TO CONFIRM” Press the volume knob to acknowledge in order to proceed to the next KD-T922BT/KD-X38MDBT: desired operation. Audio signal through lineout terminal Setting on [2-WAY] (Displayed only when [3-WAY] is selected.) [SPK/PRE OUT] [YES]: Selects two way crossover type.
  • Page 36 [POSITION 00]. (Page 26) – 2-way crossover: [TWEETER] of [FRONT]/[REAR]/[SUBWOOFER] – 3-way crossover: [WOOFER] * Except for KD-T922BT/KD-X38MDBT. X ‘ OVER (crossover) • [FRQ]/[F-HPF FRQ]/[R-HPF FRQ]/[SW LPF FRQ]/[HPF FRQ]/[LPF FRQ]: Adjusts the crossover frequency for the selected speakers (high pass filter or low pass filter).
  • Page 37 Audio Settings 2-way crossover setting items [SUBWOOFER [SW LPF FRQ] [30HZ]/[40HZ]/[50HZ]/[60HZ]/[70HZ]/[80HZ]/ LPF]*2*3 [90HZ]/[100HZ]/[120HZ]/[150HZ]/[180HZ]/ [SPEAKER SIZE] [220HZ]/[250HZ]/[THROUGH] [FRONT] [SIZE] [8CM]/[10CM]/[12CM]/[13CM]/[16CM]/ [SW LPF SLOPE] [–06DB]/[–12DB]/[–18DB]/[–24DB] [17CM]/[18CM]/[4×6]/[5×7]/[6×8]/[6×9]/ [SW LPF PHASE] [REVERSE] (180°)/ [NORMAL] (0°) [7×10] [SW LPF GAIN] [–08DB] to [00DB] [TWEETER] [SMALL]/[MIDDLE]/[LARGE]/[NONE] (not connected) 3-way crossover setting items [REAR]*1...
  • Page 38 Audio Settings [MID RANGE] [HPF FRQ] [30HZ]/[40HZ]/[50HZ]/[60HZ]/[70HZ]/[80HZ]/[90HZ]/ Digital Time Alignment settings [100HZ]/[120HZ]/[150HZ]/[180HZ]/[220HZ]/[250HZ]/ Digital Time Alignment sets the delay time of the speaker output to create a [THROUGH] more suitable environment for your vehicle. [HPF SLOPE] [–06DB]/[–12DB] • For more information, see “Determining the delay time automatically” on page 31.

  • Page 39: Display Settings

    Audio Settings Zone identification for brightness settings Determining the delay time automatically If you specify the distance from the currently set KD-T922BT: listening position to every speaker, the delay time will be automatically calculated. 1 Set [POSITION] and determine the listening...
  • Page 40 • KD-DB622BT/KD-X38MDBT: Not applicable to Dynamic Label display information (page 35, 36) while in DAB source. [FORMAT]*3 (For KD-T922BT/KD-X38MDBT) Press and hold Information below is shown on the supplementary display when Bluetooth Turn the volume knob to select an item (see the following table), then device is connected.

  • Page 41: References

    1 Select a zone ([ZONE 1], [ZONE 2]). (See the illustration on page 32.) 2 [RED]/[GREEN]/[BLUE]: Select a primary color. Handling discs (for KD-T922BT/KD-DB622BT) 3 [00] to [31]: Select the level. • Do not touch the recording surface of the disc.
  • Page 42 Playable file format: ISO 9660 Level 1/2, Joliet, Long file name – KD-T922BT: iPhone 5S, 6, 6 Plus, 6S, 6S Plus, SE, 7, 7 Plus, 8, 8 Plus, X, XS, XS MAX, XR, 11, • USB mass storage class device: 11 Pro, 11 Pro MAX (iOS 12.1 or later)

  • Page 43: Change The Display Information

    Change the display information Source name Display information: Main (Supplementary) CD/USB (For KD-T922BT) Each time you press , the display information changes. For CD-DA: • If the information is unavailable or not recorded, “NO TEXT”, “NO NAME”, or other information...
  • Page 44 References KD-DB622BT: Source name Display information: Main SPOTIFY BT Context title Context title with Music Synchronization Effect* Main display Song title Artist Album title Playing Time Date back to the beginning Clock display BT AUDIO Song title/Artist Song title/Artist with Music Synchronization Effect* Album title/Artist Playing time...

  • Page 45: Troubleshooting

    Troubleshooting Symptom Remedy Symptom Remedy Sound cannot be heard. • Adjust the volume to the optimum level. Disc cannot be ejected. Press and hold to forcibly eject the disc. Be careful • Check the cords and connections. not to drop the disc when it is ejected. “MISWIRING CHECK WIRING Turn the power off, then check to be sure the terminals Noise is generated.
  • Page 46 Troubleshooting Symptom Remedy Symptom Remedy • The source does not The USB port is drawing more power than the design limit. No Bluetooth device is • Search from the Bluetooth device again. change to “USB” when Turn the power off and unplug the USB device. Then, turn detected.

  • Page 47: Installation/Connection

    Installation/Connection Troubleshooting Symptom Remedy This section is for the professional installer. For safety’s sake, leave wiring and mounting to professionals. Consult the car audio dealer. “NOT SUPPORT” The connected phone does not support Voice Recognition feature or phonebook transfer. WARNING “NO ENTRY”/“NO PAIR”...
  • Page 48 Installation/Connection Part list for installation Installing the unit (in-dash mounting) (for KD-T922BT/KD-DB622BT) (A) Faceplate (×1) (B) Trim plate (×1) Do the required wiring. (Page 42, 43) (C) Mounting sleeve (×1) (D) Wiring harness (×1) Hook on the top side Orientate the trim...
  • Page 49 Installation/Connection Installing the unit (in-dash mounting) (for KD-X38MDBT) Do the required wiring. (Page 43) Hook on the top side Orientate the trim Dashboard of plate as illustrated your car before fitting. Bend the appropriate tabs to hold the sleeve firmly in place. Installing the unit (without mounting sleeve) Removing the unit (for KD-X38MDBT)
  • Page 50 Installation/Connection Wiring connection of KD-T922BT Rear output/3-way crossover: Tweeter output When connecting to an external amplifier, Front output/3-way crossover: Mid range output connect its ground wire to the car’s chassis to Subwoofer output/3-way crossover: Woofer output avoid damaging the unit.
  • Page 51 Installation/Connection Wiring connection of KD-DB622BT/KD-X38MDBT KD-X38MDBT: KD-DB622BT: When connecting to an external Rear output/3-way crossover: Tweeter output Rear/subwoofer output/ Front output/3-way crossover: Mid range output amplifier, connect its ground 3-way crossover: Woofer output wire to the car’s chassis to avoid Subwoofer output/3-way crossover: Woofer output damaging the unit.

  • Page 52: Specifications

    Usable Sensitivity (S/N = 26 dB) KD-DB622BT/KD-X38MDBT: Dynamic Range KD-T922BT: 91 dB 0.56 μV/75 Ω (6.2 dBf) KD-DB622BT: 92 dB KD-T922BT: 0.71 μV/75 Ω (8.2 dBf) Channel Separation KD-T922BT: 89 dB Quieting Sensitivity (DIN S/N = 46 dB) KD-DB622BT/KD-X38MDBT: KD-DB622BT: 90 dB 1.58 μV/75 Ω...
  • Page 53 -09 — +09 (-9dB — +9dB) WMA Decode Compliant with Windows Media Audio 1.35/ 1.5/ 2.0 AAC Decode KD-T922BT: AAC-LC “.aac”, “.m4a” files Frequency Through/ 30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/ 150/ 180/ 220/ 250 Hz WAV Decode...
  • Page 54 • Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. • Use of the Made for Apple badge means that an accessory has been designed to connect specifically to the Apple product(s) identified in the badge and has been certified by the developer to meet Apple performance standards.
