• The battery pack or batteries shall not be exposed to excessive heat such as sunshine, fire or the like. How to read this manual • Operations are explained mainly using buttons on the faceplate of KD-T408. • English indications are used for the purpose of explanation. You can select the display language from the menu. (Page 5) •...
BASICS Faceplate Remote control (RM-RK52) Symbolic button Loading slot Display window Remote sensor (Do not expose to bright sunlight.) Pull out the insulation sheet when using for the first time. Detach button Attach Detach How to reset How to replace the battery Your preset adjustments will be erased except stored...
For details on how to update the firmware, visit To set the date <http://www.jvc.net/cs/car/>. Press VOL +/– to select [DATE SET], then press * ENTER. Press VOL +/– to make the settings, then press * ENTER. * Not displayed when the corresponding source is selected.
RADIO GETTING STARTED [CLOCK] [TIME SYNC] [ON]: The clock time is automatically set using the Clock Time (CT) data in FM Radio Data System signal. ; [OFF]: Cancels. [CLOCK [ON]: The clock time is shown on the DISPLAY] display even when the unit is turned off. ; [OFF]: Cancels.
Page 6
RADIO Select a stored station [SSM] [SSM 01–06]/[SSM 07–12]/[SSM 13–18]: Automatically presets up to 18 stations for FM. “SSM” stops flashing when the first 6 stations are stored. Select Press one of the number buttons (1 to 6). [SSM 07–12]/[SSM 13–18] to store the following 12 stations. (or) Press [LOCAL SEEK]...
RADIO PTY code Preparation: You can listen to music from a portable audio player via the auxiliary input [NEWS], [AFFAIRS], [INFO], [SPORT], [EDUCATE], [DRAMA], [CULTURE], [SCIENCE], [VARIED], jack. [POP M] (music), [ROCK M] (music), [EASY M] (music), [LIGHT M] (music), [CLASSICS], •...
CD/USB/ANDROID Start playback The source changes automatically and playback starts. Eject disc Label side • To directly select USB source or ANDROID source, press USB. On the faceplate On the remote control Press and hold S / T. Press and hold H / I. Reverse/Fast-forward*3 USB input terminal Select a track/file...
AUDIO SETTINGS CD/USB/ANDROID Select music drive While in USB source, press 5 MODE repeatedly. Stored songs in the following drive will be played back. • Selected internal or external memory of a smartphone (Mass Storage Class). • Selected drive of a multiple drive device. Select a drive equalizer directly Select a file from a folder/list Drive equalizer boosts specific frequencies in the audio signal to reduce the...
Page 10
AUDIO SETTINGS Default: [XX] [TREBLE] Frequency : [10.0KHZ]/[12.5KHZ]/[15.0KHZ]/[17.5KHZ] Level [LVL–06] to [LVL+06] [EQ SETTING] [Q FIX] [PRESET EQ] Selects a preset equalizer suitable to the music genre. (Default [10.0KHZ]/[LVL 00]/[Q FIX]) • Select [USER] to use the settings made in [EASY EQ] or [PRO EQ]. [AUDIO CONTROL] [FLAT]/[DRVN 3]/[DRVN 2]/[DRVN 1]/[HARD ROCK]/[HIP HOP]/[JAZZ]/ [POP]/[R&B]/[TALK]/[USER]/[VOCAL BOOST]/[BASS BOOST]/[CLASSICAL]/ [BASS BOOST]...
Page 11
50 W to prevent damaging For connections through an external amplifier. (Page 21) the speakers.) ; [HIGH POWER]: The maximum volume level is 35. KD-T408: [D.T.EXPANDER] [ON]: Creates realistic sound by compensating the high-frequency...
DISPLAY SETTINGS AUDIO SETTINGS Zone identification for brightness settings Connection via speaker leads You can also connect the speakers without using an external amplifier (Symbolic button) but still being able to enjoy the subwoofer output with these settings. (Page 20) Audio signal through rear speaker lead Setting on [SPK/PRE OUT] L (left)
Page 13
DISPLAY SETTINGS Default: [XX] [COLOR] (for Symbolic button only) [DISPLAY] [PRESET] Selects an illumination color for the symbolic button. (See the illustration on page 12.) [DIMMER] Dims the illumination. • [COLOR 01] to [COLOR 49] [OFF]: Dimmer is turned off. Brightness changes to [DAY] setting. •...
For: – Latest firmware updates and latest compatible item list – Any other latest information About Android device Visit <www.jvc.net/cs/car/>. • This unit supports Android OS 4.1 and later. • Some Android devices (with OS 4.1 and later) may not fully support Android Open Accessory General (AOA) 2.0.
TROUBLESHOOTING REFERENCES Change the display information Symptom Remedy Each time you press , the display information changes. Sound cannot be heard. • Adjust the volume to the optimum level. • If the information is unavailable or not recorded, “NO TEXT”, “NO NAME”, or other information •...
Page 16
TROUBLESHOOTING Symptom Remedy Symptom Remedy “NOT SUPPORT” appears and Check whether the track is a playable format. Playback is intermittent or Turn off the power saving mode on the Android device. track skips. (Page 14) sound skips. “READING” keeps flashing. •...
SPECIFICATIONS Frequency Range 87.5 MHz — 108.0 MHz (50 kHz step) USB Standard USB 1.1, USB 2.0 (Full speed) Usable Sensitivity (S/N = 26 dB) 8.2 dBf (0.71 μV/75 Ω) Compatible Devices Mass storage class Quieting Sensitivity (DIN S/N = 46 dB) 17.2 dBf (2.0 μV/75 Ω) File System FAT12/16/32...
INSTALLATION/CONNECTION SPECIFICATIONS Warning Operating Voltage 12 V DC car battery • The unit can only be used with a 12 V DC power supply, negative ground. Installation Size (W × H × D) 182 mm × 53 mm × 158 mm •...
Page 19
INSTALLATION/CONNECTION Part list for installation Installing the unit (in-dash mounting) (A) Faceplate (×1) (B) Trim plate (×1) Do the required wiring. (Page 20) (C) Mounting sleeve (×1) (D) Wiring harness (×1) Hook on the top side Dashboard of Orientate the trim your car plate as illustrated before fitting.
Page 20
INSTALLATION/CONNECTION Wiring connection IMPORTANT We recommend installing the unit with a commercially available custom wiring harness specific for your car and leave this job to professionals for your safety. Consult your car audio dealer. Fuse (10 A) Vehicle dashboard Antenna terminal Factory wiring Light blue/yellow To the steering wheel remote...
Page 21
INSTALLATION/CONNECTION Connecting external components Connecting external amplifiers via output terminals KD-T408 KD-T406/ KD-T401 Remote wire (not supplied) Signal cord (not supplied) To remote lead (blue/white) of JVC Amplifier*2 the wiring harness. (Page 20) Output terminals Output terminals REAR Rear output...
