Rubinet 8ERBHXC Quick Start Manual

INS HX8E
WALL MOUNTED POT FILLER
MODEL 8ERBHXC or L
If you need assistance with installation, replacement parts or have any
questions regarding your Rubinet product, please call a Customer
service representative at: 905-851-6781 toll free 1-800-461-5901
or visit www.rubinet.com
REMOVAL OF FAUCET:
Always turn the water supply off before removing the existing faucet or
disassembling a valve. Open both faucet handles to relieve water
pressure and to ensure that the water has been successfully turned off.
8ERBHXC
BEFORE YOU BEGIN
READ ALL DIRECTIONS PRIOR TO INSTALLATION. ANY
ALTERATIONS MADE TO THE CARTRIDGES AND
FAILURE TO FOLLOW THESE INSTRUCTIONS MAY
CAUSE DAMAGE OR IMPROPER INSTALLATION WHICH
WILL NULLIFY THE WARRANTY.
• Observe and adhere to all local building and plumbing
codes.
• Shut off main water supply.
• Finished wall refers to the ultimate finished surface, Tile,
Marble etc.
• It is recommended that the pipes be flushed clean prior to
installation, in order to avoid problems with debris later.
• This Pot Filler is designed to be used in close proximity to
or directly above a stove top. The main consideration
8ERBHXL
therefore is what size is your largest pot and how high
off the surface of the stove top to mount the Pot Filler.
The standard height of a counter top is 36" a stove top is
generally 2" above that so mount the Wall Plate 16" above
the stove top for a total height of 54" from the floor. Allow
8" either side of the Wall Plate for the arm to swing. Plan
ahead!
SPECIFICATIONS
All brass construction
Two handle wall-mounted
Adjustable quarter turn ceramic disc cartridges
1/2" NPT connections
2.2 gpm flow rate at 60 psi
CARE OF FAUCET:
The use of warm water and a soft cloth is all that is required to clean
Rubinet products. The patina of our living finishes (Oil Rubbed Bronze &
Tuscan Brass) will change as a result of normal use. Applying Mineral Oil
on occasion will create a softer look, subtle color changes and character.
INS HX8E
