PORTABLE QUICK START
GUIDE
ALLIGATOR CLIPS
1. Remove Portable from the rigid nylon travel
case.
2. Unlatch the butterfly clasps (45watt does not
have clasps) and open panels flat.
3. Unfold tilt legs and place panels in direct
sunlight.
4. Clip the red alligator clip to the negative
battery terminal.
5. You are now charging your batteries.
* First time you use the unit you may need to configure the charge controller for the
ZampSolar.com
SIDE WALL
SOLAR PORT
1. Remove Portable from the rigid nylon travel
case
2. Unlatch the butterfly clasps (45watt does not
have clasps) and open panels flat.
3. Unfold tilt legs and place panels in direct
sunlight.
4. Remove/unclip the alligator clips at the SAE
connection.
5. Plug the SAE lead from the panel into the
sidewall port on your RV.
6. You are now charging your batteries.
appropriate battery type.
(541) 728-0924
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dometic ZAMP SOLAR
Summary of Contents for Dometic ZAMP SOLAR
- Page 1 PORTABLE QUICK START GUIDE ALLIGATOR CLIPS 1. Remove Portable from the rigid nylon travel case. 2. Unlatch the butterfly clasps (45watt does not have clasps) and open panels flat. 3. Unfold tilt legs and place panels in direct sunlight. 4. Clip the red alligator clip to the negative battery terminal.
- Page 2 PORTABLE QUICK START GUIDE WIRING FOR MULTIPLE 12V BATTERIES When wiring a solar port to multiple batteries, it is important to remember that your batteries are wired together. To gain the most from your solar, be sure to place the positive wire on the first battery in the sequence and the negative wire on the last battery in the sequence.
