  • Page 1 User Manual 9BB Mono Solar Panel...
  • Page 2 Limitless energy, limitless life service@bougerv.com 1-669-232-7427 www.bougerv.com...
  • Page 3 Thank you for choosing BougeRV Solar Panel. Please read and understand the installation manual before installing BougeRV Solar Panel. With proper operation and maintenance, this solar panel could provide you with clean, renewable solar electricity for many years. This manual contains important installation, maintenance, and safety information.

  • Page 4: Limited Warranty

    Message through [Ask a Question] in BougeRV Amazon shop Ps: The limited warranties do not apply to any of the following: The solar panel which in BougeRV's absolute judgment have been subjected to misuse, abuse, neglect or accident, alteration, or improper installation, application, or removal.

  • Page 5: Safety Precautions

    • Broken J-boxes or connectors are electrical hazards as well as laceration hazards. Installers should remove any such solar panel from the array and contact BougeRV for disposal instructions. • Do not install or handle the solar panel when they are wet or during periods of high wind.

  • Page 6: Electrical Parameters

    Electrical Parameters 100W 180W 200W MODEL SOLAR PANEL SOLAR PANEL SOLAR PANEL 100W 180W 200W Peak Power Pm (W) 21.4V 23.0V 23.4V Open circuit voltage Voc (V) 18.15V 19.2V 19.8V Max.power voltage Vmp (V) 5.51A 9.38A 10.10A Max.power current Imp (A) 6.11A 10.23A 11.17A...

  • Page 7: Electrical Connections

    Electrical Connections Series Connection The panel may be wired in series to produce the desired voltage output. Electrical Connection Parallel Connection The solar panel can be wired in parallel to produce the desired current output with the parallel connector. Parallel Connection...

  • Page 8: Frequently Asked Questions

    Does it works with the portable power station? Yes, BougeRV solar panels with mc4 connectors are suitable for most portable power stations on the market. If you want to inquire about the specific model, please contact us.

This manual is also suitable for:

180w solar panel200w solar pane
