RF-SHK-319-NN Wireless TOTAL Window Sensor

Description

The RF-SHK-319 is a wireless window
sensor designed for dual protection; open
and close and to detect vibrations made by
an intruder attempting to break a window.
The shock sensor contains a piezo
detection device that detects vibrations
when mounted on a window frame. The
detection circuit can be adjusted for
sensitivity during installation to ensure
maximum coverage. The device also has a
built-in reed switch to monitor the open and
close of the door or window.
When activated, the sensor transmits a
signal to the control panel. These are the
signals the unit provides: supervisory,
tamper and low battery (as needed). The
sensor is powered by (2) replaceable 3-
VDC, lithium coin-cell batteries.

Installation Guidelines

• Mounting the sensor on metal can affect
the transmitting range performance.
Therefore, test the sensor from the desired
location using the installer sensor test,
before permanently mounting it.
• Mount the sensor within 100 ft. of the
panel.
• Mount the sensor on the frame of the door
or window.
• The sensors can be mounted to either
wood or metallic surfaces.
I-RF-SHK-319 Rev.5 02092022

Testing and Adjusting the Sensor

1. Set the panel to the sensor test mode.
2. Take the sensor and magnet to the
3. Monitor the system after tripping the

Mounting the Sensor

Mount the sensor using the supplied
mounting tape or using small wood screws-
not included.
Note: The gap between the sensor and magnet
should not exceed a maximum of 3/8".

Adhesive Mounting Pads

1. Before applying mounting pads, ensure that
2. Apply mounting pads to the bottom of the
After mounting, test the sensor using the
procedure in the section "Testing and Adjusting
the Sensor".

Programming

The following steps describe the general
guidelines for programming sensor into panel
memory. Refer to the specific panel's
documentation for complete programming
details.
The internal magnetic reed switch and
shock zones use separate ID's.
For updated Installation Manual Revision go to Maxouttech.com and select Documentation page.
desired mounting location, making sure
to line up their alignment marks with
each other. Trip the sensor by pulling the
magnet away from the sensor.
sensor. Refer to the specific panel
documentation for interpretation of the
results to ensure desired signal
strength is achieved.
the desired location is a smooth, clean and
dry surface.
Note: When applying, evenly apply pressure
to ensure a good surface contact.
sensor and the magnet. Mount the sensor
and magnet at the desired locations,
ensuring the alignment marks line up with
each other.
