- Page 1 K8 / B6850, BP6850 Control elements This manual describes the controls of the K-8 oven. Instructions for K-Connect as well as the detailed Instructions can be found in separate documents.
-
Page 3: Table Of Contents
Content Control elements Legend ..................4 Softkeys ..................5 Buttons ..................6 Selectors ...................8 Interaktive and informative Elements ........9 Swipe indicator ..............10 Scala ..................12 Requests ................13 Edit profiles, recipes & notes ..........14 Keyboard ................15... -
Page 4: Legend
LEGEND Swipe up / down Swipe right Swipe left Information... -
Page 5: Softkeys
CONTROL ELEMENTS Softkeys 15:25 15:25 On/Off Tap and hold Light Tap and hold Childlock Hold Back Homescreen Enabled = lighted Disabled = not lighted... -
Page 6: Buttons
CONTROL ELEMENTS Buttons 1. Active 2. Inactive Functions are present but there is no condition for inter- action (missing internet connection) 3. Selected... - Page 7 4. Confirm A previously confirmed setting appears in this state. Interaction is possible during this state.
-
Page 8: Selectors
CONTROL ELEMENTS Selectors 1. The function is selected by wiping the roller 2. Confirm by tapping the middle tile 1, 2. The time is selected by wiping the rollers 3. Confirm by tapping the OK tile... -
Page 9: Interaktive And Informative Elements
Interactive and informative Elements Interactive elements of the headline are positioned on the left side. These allow quick access to functions such as end time, alarm or stopwatch. 1. Interactive elements: end time, timer, alarm, stopwatch, extra time, notes 2. Informative elements: WiFi, roasting thermometer, Turn the food, meat probe, childlock, doorlock, eco mode... -
Page 10: Swipe Indicator
CONTROL ELEMENTS Swipe-Indicator 1. Swipe left / tap the tile to show more functions... - Page 11 1. Swipe right to move from active back mode to settings 1. Back to the active baking mode...
-
Page 12: Scala
CONTROL ELEMENTS Scala Settings of the cooking level, the brightness, the contrast and the brightness 1. Touch Tile to select a cooking level 2. Confirmation of the selection. -
Page 13: Requests
Requests & Queries 1. Follow the instruction 2. The action is confirmed as soon as the door is opened... -
Page 14: Edit Profiles, Recipes & Notes
CONTROL ELEMENTS Edit profiles, recipes & notes 1. Press 3 sec. -
Page 15: Keyboard
Keyboard 1. Enter note / name 2. Confirm... - Page 16 IMPRINT Küppersbusch Hausgeräte GmbH Küppersbuschstraße 2 D-45883 Gelsenkirchen Telefon: +49 209 401-0 Telefax: +49 209 401-303 E-Mail: info@kueppersbusch.de...
