TE Connectivity 2118326-1 Quick Start Manual

Part Number: 2118326-1

Product Facts

• Small and lightweight PCB antenna
assembly.
• RoHS compliant.

Recommendations

• For best performance follow Mounting
Guide and Keep Out Area on next page.

Test Orientation in Free Space

Azimuth
Legend:
5470 MHz
270º
Catalog: 1-1773726-7
Revised 02-14
www.te.com
www.antenna.te.com
Arrow.com.
Downloaded from
Antenna Solutions
4900-5875 MHz Single Band Antenna
(IEEE 802.11 a/g/n/ac, includes frequencies of Wi-Fi products)

Specifications

Frequency Range (MHz)
Peak Gain
VSWR
Polarization
Azimuth Beamwidth
Power Handling
Feed Point Impedance
Size
Weight
Mounting
Keep Out Area
Cable / Connector
Elevation
0º
Legend:
5dBi
5470 MHz
0dBi
-5dBi
-10dBi
-15dBi
-20dBi
-25dBi
-30dBi
90º
270º
180º
Dimensions are in inches and milli-
meters unless otherwise specified.
Values in brackets
are metric equivalents.
VSWR
5
3
1
4900
0º
5dBi
0dBi
-5dBi
-10dBi
-15dBi
-20dBi
-25dBi
-30dBi
90º
180º
Dimensions are shown for USA: 1-800-522-6752
reference purposes only. Canada: 1-905-475-6222
Specifications subject to change. Germany: +49 (0) 6251-133-1999
For other country numbers go to:
4900–5875
+2.4 dBi
< 2.5:1
Linear
Omni-directional
3 Watt cw
50 Ohms unbalanced
15.0 mm x 10.0 mm x 1.0 mm
1.0 g.
Adhesive. See diagram on page 2.
See diagram on page 2.
120 mm length. 1.13 mm dia. with U.FL connector
5388
Frequency (MHz)
Efficiency
100
50
0
4900 5388
UK: +44 (0) 800-267666
Netherlands: +31 (0) 73-6246-999
China: +86 (0) 400-820-6015
www.te.com/supportcenter
5875
5875
Frequency (MHz)
