E2S GNExS1R Series Instruction Manual page 11

2
1
A
Single Stage Configuration
Stage 1: Apply Power to Stage 1 Live & Stage 1 Neutral
B
C
Stage 1 Live IN
Stage 1 Live OUT
Stage 1 Neutral IN
D
Stage 1 Neutral OUT
Earth
E
F
DRAWING TO BS8888:2000
DRAWN
GEOMETRIC TOLERANCES TO ISO1101:1983
LINEAR DIMENSIONAL TOLS
R.S.RAIT
ANGULAR DIMENSIONAL TOLS
CHECKED
G
B.ISARD
STANDARDS
APPROVED
D1x
R.N.POTTS
3 4
Config.: 1a Three/Four Stage Configuration
Stage 1: Apply Power to Live & Neutral
Stage 2: Apply Power to Live & Neutral
& connect Stage 2 to Common
Stage 3: Apply Power to Live & Neutral
& connect Stage 3 to Common
Stage 4: Apply Power to Live & Neutral
& connect both Stage 2 & Stage 3 to Common
Live IN
L
Live OUT
L
Neutral IN
N
Neutral OUT
N
Earth
E
Common
Stage 2
Stage 3
SURFACE FINISH WEIGHT (Kg)
DATE
19/01/2022
MATERIAL
DATE
19/01/2022
ALTERNATIVE MATERIAL
DATE
19/01/2022
5
6
SWITCHES FOR STAGE OPERATION
CUSTOMER SUPPLIED
Config.: 1b
L
L
N
N
E
C
S2
S3
THIS DRAWING AND ANY INFORMATION OR DESCRIPTIVE
MATTER THEREIN IS COMMUNICATED IN CONFIDENCE AND
IS THE COPYRIGHT PROPERTY OF EUROPEAN SAFETY
SYSTEMS LTD. NEITHER THE WHOLE OR ANY EXTRACT MAY
BE DISCLOSED, LOANED, COPIED OR USED FOR
MANUFACTURING OR TENDERING PURPOSES WITHOUT THEIR
WRITTEN CONSENT.
EUROPEAN SAFETY SYSTEMS LTD.
C
AS PER LATEST DATE OF ISSUE SHOWN ABOVE
8 9
7
ISSUE MOD No.
INTRODUCTION
1
RSR - 19/01/2022
Two Stage Voltage Free Activation Configuration
Power: Live & Neutral
Stage 1: Connect Stage 1 to Common
Stage 2: Connect Stage 2 to Common
Stage 3: Connect both Stage 1 & Stage 2 to Common
Live IN
Live OUT
Neutral IN
Neutral OUT
Earth
Common
Stage 1
Stage 2
CUSTOM
CONFIGURATION
CONTACT E2S
WHEN ORDERING
ALL DIMENSIONS IN MM
2S
IF IN DOUBT, ASK -
DO NOT SCALE
warning signals
TITLE
D1xS1 / D1xS2 / GNExS1 / GNExS2 / STExS1 /
EUROPEAN SAFETY SYSTEMS LTD
STExS2 AC SOUNDER WIRING DIAGRAMS
IMPRESS HOUSE
MANSELL ROAD
ACTON
DRAWING NUMBER
LONDON W3 7QH SCALE SHEET
WWW.E2S.COM
NTS 1
1
OF
10
REASON - INITIAL - DATE
A
Config.: 2
B
C
L
L
N
D
N
E
C
E
F
A3
G
D190-06-005
