E2S D1xC1X05RDC024-D Instruction Manual

INSTRUCTION MANUAL
D1xC1 & D1xC2
Alarm Horn Sounder & Strobe
Class II & III, Zone 20, 21 & 22
1) Product Table
Unit Type Code
D1xC1X05RDC024-D
D1xC1X05RAC115-D
D1xC1X05RAC230-D
D1xC1X05FDC024-D
D1xC1X05FAC115-D
D1xC1X05FAC230-D
D1XC2X05RDC024-D
D1xC2X05RAC115-D
D1xC2X05RAC230-D
D1XC2X05FDC024-D
D1xC2X05FAC115-D
D1xC2X05FAC230-D
*Max = Tone 4
The table shows the input current taken by the various sounders.
The current levels shown above are for the 440Hz Continuous tone @ nominal input voltage.
Nominal current at nominal voltage.
Table 1: Electrical Ratings.
2) Warnings
CAUTION
TO REDUCE THE RISK OF IGNITION OF HAZARDOUS
ATMOSPHERES:
DISCONNECT FROM SUPPLY BEFORE OPENING.
KEEP TIGHTLY CLOSED WHEN IN OPERATION.
WARNING
FIT SEALING FITTING IN CONDUIT RUNS WITHIN 18 INCHES
FROM ENCLOSURE.
EQUIPMENT MUST NOT BE INSTALLED WITH THE HORN FACING
UPWARDS OF HORIZONTAL
DO NOT OPEN WHEN AN EXPLOSIVE ATMOSPHERE IS
PRESENT
DO NOT OPEN WHEN ENERGISED
POTENTIAL ELECTROSTATIC CHARGING HAZARD - CLEAN
ONLY WITH A DAMP CLOTH
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
Document No. D190-00-351-IS
D1xC1-R & D1xC2-R
Nominal
Input Voltage
24Vdc
115Vac
230Vac
24Vdc
115Vac
230Vac
24Vdc P2/P3: 647/1063mA
115Vac P2/P3: 255/415mA
230Vac P2/P3: 157/246mA
24Vdc P2/P3: 647/1063mA
115Vac P2/P3: 255/415mA
230Vac P2/P3: 157/246mA
†
Nom. = Tone 44
Issue 1
D1xC1-F
Nominal
Voltage Range
Input Current
508mA 20-28Vdc
200mA 110-120Vac 50/60Hz
127mA 220-240Vac 50/60Hz
508mA 20-28Vdc
200mA 110-120Vac 50/60Hz
127mA 220-240Vac 50/60Hz
20-28Vdc
110-120Vac 50/60Hz
220-240Vac 50/60Hz
20-28Vdc
110-120Vac 50/60Hz
220-240Vac 50/60Hz
ATTENTION
POUR REDUIRE
ATMOSPHÈRES DANGEREUSES :
COUPER L 'ALIMENTATION AVANT OUVERTURE.
CONSERVER FERMÉ PENDANT LE FONCIONNEMENT.
AVERTISSEMENT
CONDUITS DOIVENT ETRE SCELLES EN MOINS DE 18 POUCES.
ÉQUIPEMENT NE DOIT PAS ETRE INSTALLE AVEC LE KLAXON
TOURNEE VERS LE HAUT DE HORIZONTAL.
NE PAS OUVRIR UN PRESENCE D'ATMOSPHERE EXPLOSIVE
NE PAS OUVRIR ENERGIE
DANGER POTENTIEL CHARGE ÉLECTROSTATIQUE - NETTOYER
UNIQUEMENT AVEC UN CHIFFON HUMIDE
21-03-2022
D1xC2-F
Sound
Pressure Level dB(A)
.†
Max* Nom
94 90
98 94
P2/P3 P2/P3
96/98 92/94
P2/P3 P2/P3
106/109 103/105
LE RISQUE D'INFLAMMATION
www.e2s.com Tel: +44 (0)208 743 8880
DES
Sheet 1 of 6
