TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from Polygroup®!
This tree comes with Quick Set® technology - allowing you to set up your tree and light it up in minutes!
Carefully follow the instructions below on how to quickly and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
Section 1
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from bottom to the top. Start with the bottom section and remove the protective cap before inserting into the
assembled stand. Make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all wires are free of branch hinges.
7. Just plug the adapter (connecting with the tree power cord) into the wall outlet (See Fig. B), your entire tree should now be lit. If some
bulbs do not light or flickers, search for any loose plugs and/or broken, loose or missing bulbs. Replace bulbs promptly in order to maintain
the performance and life expectancy of your pre-lit tree.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out one to the
right, one to the left and one at the center of the main stem. (See Fig. C)
Fig. C
Top view
9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform look. Shift branches to fill any gaps.
Your Christmas tree is now complete and ready to be decorated.
STORAGE INSTRUCTIONS
1. Unplug adapter from the wall outlet first and then remove all ornaments and decorations.
2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to remove from section
below and fold all branches toward the pole.
MODEL #: TG76P3B20Y14
Tree Top
Section 2
Side view
Control box
Insert Green
Adapter
Label Extension
To Be Plugged
Cord into Adapter
Into Wall
1
Unfold the legs and lay the
stand in a flat area. Then slide
the locking disc downward
and snap into place.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: 120V, 60Hz, 0.38A
Output: 29V 0.621A
Controller: 0.621A
Do Not Tamper
Internal Parts
Open the
cap cover
Align both arrows
in a straight line
before sliding
down to insert
Outlet
