TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from Polygroup®! This tree comes with Quick Set® technology-Set up and can
light up your tree in less than 10 minutes! Carefully follow the instructions below on how to quickly and easily set up your
new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
Section 1
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective cap before inserting
into the assembled stand. Make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all wires are free of
branch hinges.
7. Insert adaptor plug into the wall outlet. (see Fig. B), your entire tree should now be lit.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out
one to the right, one to the left and one at the center of the main stem. (See Fig. C)
Fig. C
Top view
MODEL #: TG76P3G16D01
+1 (888) 919-0070
OR
Tree top
Section 2
Side view
Unfold the legs and lay the
stand in a flat area. Then slide
the locking disc downward and
snap into place.
Control box
Insert Green
Label Extension
Cord into Adaptor
1
*Electrical Rating For The Tree
(For Indoor Use Only)
Input:120V, 60Hz, 0.25A
Output: 29V DC 0.45A
Controller: 0.45A
Do Not Tamper
Internal Parts
Open the
cap cover
Align both arrows
in a straight line
before sliding
down to insert
Adaptor
To Be Plugged
Into Wall
Outlet
