1006 300 371
Model #FZA71015R-2PKB
USE AND CARE GUIDE
ST. CHARLES 2PK CHAIR - BARE
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this chair. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Home Decorators Collection!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FZA71015R-2PKB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Home Decorators Collection FZA71015R-2PKB

Summary of Contents for Home Decorators Collection FZA71015R-2PKB

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this chair. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Planning Assembly ..............3 Important Safety Instructions ........2 Hardware Included ..............4 Save These Instructions ............2 Package Contents ..............4 Read All Instructions Before Use ..........2 Assembly ..............

  • Page 3: Warranty

    Warranty 5 YEAR FRAME WARRANTY WHAT IS COVERED We warrant the frame to be free of manufacturing defects to the original purchaser f years. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover is warranty.

  • Page 4: Package Contents

    Pre-Assembly PACKAGE CONTENTS Part Description Quantity Support Bar Backrest Left Arm Right Arm Seat Support Tube Left Leg Right Leg Connector Bar Back Cushion Seat Cushion...

  • Page 5: Assembly

    Assembly Inserting the Support Bar, Backrest and Seat to the Left Arm Place the left arm (C) on a soft surface. Insert the support bar (A), backrest (B) and seat (E) to the left arm (C). Attaching the Seat to the Left Arm Attach the seat (E) to the left arm (C) using M6x35 combination bolts (BB).
  • Page 6 Assembly (continued) Inserting the Right Arm to the Support Bar, Backrest and Seat Insert the right arm (D) to the support bar (A), backrest (B) and seat (E). Attaching the Right Arm to the Seat Attach the right arm (D) to the seat (E) using M6x35 combination bolts (BB). Do not tighten all bolts at this step.
  • Page 7 Assembly (continued) Connecting the Support Bar to the Arms Turn the chair right side up. Connect the support bar (A) to the left arm (C) and right arm (D) using M6x20 bolts (DD). Once all bolts are in place, fully tighten all bolts using the hex wrench (EE). Attaching the Support Tube to the Seat Place the chair upside down on a soft surface.
  • Page 8 Assembly (continued) Attaching the Legs to the Support Tube Attach the left leg (G) and the right leg (H) to the support tube (F) using M8x28 combination bolts (CC) and the wrench (FF). Connecting the Connector Bar to the Legs Connect the connector bar (I) to the left leg (G) and the right leg (H) using M6x20 combination bolts (AA) and the hex wrench (EE).

  • Page 9: Care And Cleaning

    Assembly (continued) Checking the Chair Turn the chair right side up. Ensure all connections are secure before use. Care and Cleaning For best results, clean the chair with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate.
  • Page 10 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use. Factory chair ID # FZM71015R...
