Alarm

Select the 3.Buzzer/Siren Setup 3.Buzzer/Siren Setup menu to set alarm conditions.
A.Set Alarm Trigger Mode [CH1 OR CH2] A.Set Alarm Trigger Mode [CH1 OR CH2]
Select one or two channels to link the alarm to (there are UA
sensors with two measurement channels).
B.Set Alarm CH1 Min [0.00] B.Set Alarm CH1 Min [0.00]
Enter the lower limit of the normal range allowed for Channel 1.
C.Set Alarm CH1 Max [0.00] C.Set Alarm CH1 Max [0.00]
Enter the upper limit of the normal range allowed for Channel 1.
D.Set Alarm CH2 Min [0.00] D.Set Alarm CH2 Min [0.00]
Enter the lower limit of the normal range allowed for Channel 2.
E.Set Alarm CH2 Max [0.00] E.Set Alarm CH2 Max [0.00]
Enter the upper limit of the normal range allowed for Channel 2.
F.Set BUZZER Alert Enable [SOUND ON] F.Set BUZZER Alert Enable [SOUND ON]
Determine to use the built-in buzzer.
G.Set Remote SIREN DEVICE Enable [OFF] G.Set Remote SIREN DEVICE Enable [OFF]
Determine to use a remote alarm beacon if such a device is installed.
Qlight's ST56EL-ETNS-2-WS alarm beacon is supported.
H.Set Remote SIREN DEVICE IP [192.168.xxx.xxx] H.Set Remote SIREN DEVICE IP [192.168.xxx.xxx]
Enter the alarm beacon IP address.
I.Set Remote SIREN DEVICE Port [2000] I.Set Remote SIREN DEVICE Port [2000]
Enter the port used by the alarm beacon.
