USER MANUAL
DK-V2M
Camera
black box for cars
Composition of the product
1. Dashcam camera in rear view mirror
2. Rear cameras
3. Connection cable for rear view camera
4. USB power cable from car lighter
Product description
DK-V2M is a rearview mirror car video recorder, equipped with an
integrated front camera and a second separate rear camera. It is
designed to be mounted on top of the original rearview mirror with
the special elastic fasteners that adapt to any vehicle.
1 - MONITOR ON AND OFF BUTTON 2 - MINIUSB CONNECTOR
FOR POWER SUPPLY 3 - REAR CAMERA MINIJACK CONNECTOR 4 -
MICROSD CARD SLOT (NOT INCLUDED)
5 - CONNECTOR NOT USED 6 - RESET
BUTTON (ON THE BACK)
Insert the microSD card
The first thing to do, if you want to make recordings, is to insert the
micro SD card into the appropriate slot in the DVR (4)
It is possible to use micro SD cards with capacities up toto 128 GB
in CLASS 10or higher. The SD card is not included in the package.
And video recorder
DSE srl - Digital Surveillance Equipment - www.dse.eu
DK-V2M Dash Cam Car Camera
One hour of recording of both cameras takes up an average of 6
GB, so about 20 hours of continuous recording can be stored on a
128GB SD card.
Format the microSD card
If you have inserted a new SD card you will need to format it before
you can use it for recording. You can do this later by performing the
first power up.
The camera alerts you with an on-screen message when it detects
an unformatted SD card.
Agree to format by tapping the button on the touchscreen to start
recording.
Installation of the dashcam with cigarette lighter power
supply
The dashcam is supplied with a cigarette lighter power cable that
takes the 12VDC from the vehicle lighter and supplies 5VDC to the
camera, with MiniUSB connector.
It is the fastest way to install the dashcam.
