DSE DK-MG1 Owner's Manual

OWNER'S MANUAL
DK-MG1
Camera with recorder mug for drinks

PRODUCT DESCRIPTION

The DK-MG1 is a VCR equipped with a built-in camera concealed in a thermos for drinks that
allows hidden cameras professional level; It is also equipped with high-sensitivity microphone.

ACCESSORIES AND PRODUCT DETAILS

• Thermos beverage
• Extra cover with camera and recorder
• USB cable
• 8GB Micro SD card with SD adapter
1. Slot external memory 1. Slot external memory
2. Formatting external memory key 2. Formatting external memory key
3. Microphone 3. Microphone
4. Switch ON / OFF Vibration 4. Switch ON / OFF Vibration
5. On / off key and start / stop 5. On / off key and start / stop

registration

6. RESET hole 6. RESET hole
7. HD / VGA Selector 7. HD / VGA Selector
8. USB 8. USB
9. Objective CMOS 9. Objective CMOS
DK-MG1 camera with recorder mug for drinks
DSE srl - Digital Surveillance Equipment - www.dse.eu

OPERATION DVR

Insert Micro SD card

The first thing to do is to insert the micro SD card into the compartment with the inscription of the
MICRO SD DK-MG1. To access the SD card compartment is necessary to open the lid as shown
in the picture below.
E 'can use SD cards with capacities up to 32 GB. Attention to the SD card inserting direction that
will slide in its seat only with the gold contacts facing downwards.
The package includes a micro SD card the memory capacity of 8GB.

Charge the battery

Before using the equipment it is advisable to fully charge the battery.
To do this we need to open the cover as shown previously for the insertion of the SD card, and
then connect the cable, supplied in the package, to the USB port of the computer or to a 5V
battery charger with USB port as our battery charger with USB port as our battery charger with USB port as our RE-AL4USB RE-AL4USB RE-AL4USB
charge will turn off. The duration of the refill lasts about two hours. Once the charging close the
lid to proceed to the first recording.
registration
Once the optimal settings set you can proceed with registration. Pressing the ON / REC button
(with the lid on the button is in correspondence of the area 10 in the figure below) the device turns
on and starts recording.
Document: DK-MG1 1D4 Document: DK-MG1 1D4 Document: DK-MG1 1D4
Page: 1 Page: 1
. At this point turns on a green LED that a full . At this point turns on a green LED that a full . At this point turns on a green LED that a full
