Summary of Contents for Plymovent FLEX-3
- Page 1 Flexible extraction arm FLEX-3 FLEX-4 ULTRAFLEX-3 ULTRAFLEX-4 Installation and user manual www.plymovent.com...
-
Page 2: Table Of Contents
To improve comprehension for people whose first language is not English, we have written parts of this manual in Simplified Technical English (STE). STE is a controlled language originally developed for aerospace industry maintenance manuals. It offers a carefully limited and standardized subset of English, along with specific writing rules. 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4... -
Page 3: Preface
Outdoor use allowed 1.2.1 Flex-3 | Flex-4 These arms are provided with the EasyLift advanced friction system for light, user-friendly positioning of the arm. Systems with a central extraction duct, with or without filtration 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4... -
Page 4: Product Description
Operating the machine within the limits of its intended use also involves observing the instructions in the user Type: MFD, MFS or MFE manual. 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4... -
Page 5: Installation
Make sure that the workshop, in the vicinity of the product, contains sufficient approved fire extinguishers (suitable for fire classes ABC). When you install the arm on a mobile unit, the end stop is redundant 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4... - Page 6 For mounting of the wall brackets, refer to the • Install the cover. Tighten the four fastening bolts firmly. corresponding manual. Type: MFD, MFS or MFE Supplied with the mobile welding fume extractor Type: NMB 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4...
- Page 7 (B) with the bolts and nuts. For this purpose use the two indicated mounting holes (A). Supplied with the wall brackets (NMB) Supplied with the wall brackets (NMB) 10. Type: NEC 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4...
-
Page 8: Use
11. Such as a mobile welding fume extractor, an extraction fan or extraction system 12. If you have an automatic start/stop (WL-AST or WCS), the extraction device will start automatically when you start welding 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4... -
Page 9: Maintenance
For adjustment of the arm section (wall/unit side) (A): 13. If you have an automatic start/stop (WL-AST or WCS), the extraction device • proceed with paragraph 6.2.3 will stop automatically after a certain stop delay 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4... - Page 10 Pull the arm (including the hood) into a horizontal position. If the arm section falls down: • Turn the bolt M8 (A) clockwise to tighten the friction. 14. If the rubber protection cover is damaged, you must replace it 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4...
-
Page 11: Troubleshooting
After life of the product, dispose of it in accordance torn or installed seal(s) or install with federal, state or local regulations. incorrectly correctly Outside air is Make the duct extracted into system airtight the connected duct system 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4... - Page 12 Product combinations MOBILE use STATIONARY use Flex-3 Flex-3 Flex-4 Flex-4 Extraction arm: UltraFlex-3 UltraFlex-3 UltraFlex-4 UltraFlex-4 NEC-2 Extension crane: NEC-2 + EXT-NEC-4 Wall brackets: FAN-28 Fan: FAN-42 Filter unit: 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4...
- Page 13 A = Flex-3 | UltraFlex-3 B = Flex-4 | UltraFlex-4 Fig. III Pressure drop 1800 1600 1400 1200 1000 800 1000 1200 1400 1600 1800 2000 X = Airflow (m3/h) Y = Static pressure (Pa) 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4...
- Page 14 ANNEX Fig. IV Maintenance points Flex-3 | Flex-4 Lubricating grease Lubricating oil Adjustment 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4...
- Page 15 ANNEX Fig. V Maintenance points UltraFlex-3 | UltraFlex-4 Lubricating grease Lubricating oil Adjustment 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4...
- Page 16 0000102307 0050101230 0000102313 0000110344 0801800090 9880020010 (5x) 0801850090 9823000100 9823000990 0000110346 9880020030 (5x) 0000102408 (2x) 0000102308 0000102296 9823000000 0000102309 9823003000 0000102300 9824000040 0000102302 0000102303 0000102304 0000102298 0711010240 9820060100 9820060120 9824000180 9824000010 9824000100 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4...
- Page 17 Spring replacement set Flex-3 wall/unit side Flex-4 0000102298 Inner tube (aluminium) hood side Flex-4 0000102300 Threaded rod (Ultra)Flex-4 0000102303 Inner tube (sendzimir) wall/unit side (Ultra)Flex-4 0801800090 Arm section (Ultra)Flex-4/NEC 9820060120 Spring replacement set Flex-4 wall/unit side 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4...
- Page 18 0801800090 9880020010 (5x) 0801850090 9823000100 9823000990 0000110346 9880020030 (5x) 0000102408 (2x) 9823000000 0000102294 9824000170 9823003000 0000102300 0000102302 0000300188 9820060110 9820060020 9820060130 9824000180 0000102299 0000102301 0000102296 0000102309 9824000010 0000102308 9824000100 0000102303 0000102304 9820060140 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4...
- Page 19 Inner tube (aluminium) hood side UltraFlex-4 0000102300 Threaded rod (Ultra)Flex-4 0000102303 Inner tube (sendzimir) wall/unit side (Ultra)Flex-4 0000300188 Spring replacement set UltraFlex-4 hood side 0801800090 Arm section (Ultra)Flex-4/NEC 9820060130 Spring replacement set UltraFlex-4 wall/unit side 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4...
- Page 20 0507270010/020821/D Flex-3 | Flex-4 | UltraFlex-3 | UltraFlex-4 www.plymovent.com...
