Switrace LOG-IC 360 BT User Manual page 9

Creating a Custom Profile
for Temp + RH Devices
CREATING A CUSTOM PROFILE
FOR TEMPERATURE + RH DEVICE
Step 1) Select CREATE
Step 2) You can then select your parameters:
• Name Profile.
• Set Temperature Alarms.
- Select the red arrow next to Not Used
- Select what type of temperature you'd like
to monitor - Instant, Cumulative or Continuous
- Select whether you want to monitor a
temperature above or below a certain threshold
- Select your temperature threshold
- Set the critical humidity level or Not Used
- Set the time
- Select the blue OK
• Continue this process for up to 4 alarms.
• Within the Details section, you can set:
- Start Mode
- Soak Time
- Units of Measure
- Airplane Mode
- Log Interval
- High Speed Logging
- User Notes
- Circular Buffer - Older data will be overwritten
with new data once max time is met.
- Stop Monitoring Button - A long, 6-second
press of the power button
logger from recording.
switrace.com | +41 91 646 18 74 | info@switrace.com
9
ATI20-075 LOG-IC® BT & BT RH Users Guide
© 2020 American Thermal Instruments, Inc. All Rights Reserved All other trademarks are the properties of their respective owners.
*High speed logging will allow your logger to move to
1-minute sampling periods automatically after reaching
a temperature excursion. This will provide you with
detailed data about when the excursions occur.
will stop the
in partnership with American Thermal Instruments
