Reading The Display Of A Bluetooth Logger; Reading The Display - Switrace LOG-IC 360 BT User Manual

Reading the Display

of a Bluetooth Logger
READING THE DISPLAY
• When turned ovofile, the display will
read "rdY" or "END."
• When turned on with an active profile deployed,
the display will show one of these four options:
- Current temperature.
- "SO" for soak .
- An "X" designating an alarm has been
triggered along with current temperature.
- A check mark showing that none of the alarms
have been triggered.
Continuously click and release the Power button
for more detailed temperature data:
• Minimum temperature reached.
• Maximum temperature reached.
• Average temperature reached.
• Battery life in percent.
switrace.com | +41 91 646 18 74 | info@switrace.com
14
ATI20-075 LOG-IC® BT & BT RH Users Guide
