I-PLUG IPMH20 User Manual
Company: Switrace SA
Brand Name: I-PLUG TH
Product Description: Temperature and humidity Data Logger, multi or single use
Features and Advantages:
• Dimensions: 7.5 cm x 4 cm x 0.5 cm
• Temperature measurement range: -35 to +65 Degrees Celsius
• Temperature resolution: 0.01 °C
• Data storage capacity: 20 000 Measurements (10 000 for temperature, 10 000 for
humidity)
• Log cycle: 1 days to 365 days
• Program and read the device using free MANAGER software
• Track and trace of settings, graph and readings in web portal.
Standard available durations:
1
2
3
4
5
6
7
Appearance of I-PLUG IPMH20 :
September, 2016 V.1.0
Total Time (Days) Log Cycle (Minutes)
6
12
41
62
69
104
208
I-Plug TH
1
2
6
9
10
15
30
I-PLUG TH
Page 1 of 9
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Switrace I-PLUG IPMH20
Summary of Contents for Switrace I-PLUG IPMH20
- Page 1 • Program and read the device using free MANAGER software • Track and trace of settings, graph and readings in web portal. Standard available durations: Total Time (Days) Log Cycle (Minutes) Appearance of I-PLUG IPMH20 : September, 2016 V.1.0 I-Plug TH Page 1 of 9...
-
Page 2: How Does It Work
• Changing start delay • Entering text in the device memory You just need to plug it in a computer before being activated and use the iPlug Manager software. Contact your SWITRACE distributor to receive this free software. September, 2016 V.1.0 I-Plug TH... - Page 3 I-PLUG TH Understanding the LEDs indicators The LEDS will give you valuable information of the conditions of your shipment as indicated in below table. If you press START or STOP button briefly, while I-PLUG is running, LEDs will blink. Here are the meanings: Appearance of I-PLUG pdf Meaning 4 blinking LEDs...
-
Page 4: Connecting To The Computer
I-PLUG TH pdf is completely full. While the PDF report is downloading, LEDs will be lit in a circular way. Using I-PLUG Manager for immediate readings 1.Connect the device to your computer 2. open SWITRACE MANAGER for immediate readings 3. select “Read Temperatures” for immediate readings September, 2016 V.1.0 I-Plug TH... - Page 5 I-PLUG TH Pic.1 Temperature and humidity information will be displayed on the same page, Humidity graph in BLUE, and temperature graph in RED September, 2016 V.1.0 I-Plug TH Page 5 of 9...
- Page 6 I-PLUG TH Pic.2 September, 2016 V.1.0 I-Plug TH Page 6 of 9...
- Page 7 Online view requires internet connection If you want to access your saved data remotely, go to the www.switrace.com then insert the serial number of the logger in the SEARCH field, and you will have access to the web- application again (Pic.4)
- Page 8 I-PLUG TH Pic.4 Modify settings of I-PLUG TH: iPlug Manager allows you to modify all the pre-programmed setting and choose your own. Just modify all the parameters you need, then press the Save settings button (Pic.1). You can change hereafter parameters (Pic.1) trip duration sample frequency size Start delay...
- Page 9 I-PLUG TH For further questions Please contact: ACANDIA AB Vintervägen 2B 13540 TYRESÖ Phone: +46-8-52224030 E-mail: info@acandia.se September, 2016 V.1.0 I-Plug TH Page 9 of 9...
