Snapper FAST-Vac Operator's Manual With Setup Instructions page 16

Collector Installation
Install Hose
1. Lower the mower deck to the lowest cutting
position.
2. See Figure 25. Install the hose (A) onto the
blower and secure with the removable clamp (with
knob) (B). At least two bands must cover the
outlet of the blower (C).
3. Cut the hose to fit properly between the blower
and collector as shown in Figure 25. At least two
bands must cover the inlet of the collector (D).
Secure with the stationary clamp (E).
A
B
Figure 25. Install Hose
A. Hose
B. Removable Clamp (with knob)
C. Blower Outlet
D. Collector Inlet
E. Stationary Clamp
14
A
C
A
www.snapperpro.com
E
D
