Taco Comfort Solutions 007e Series Instruction Sheet

SUPERSEDES: New
Plant ID No. 001-5023
DESCRIPTION:
The 007e® stainless steel is a variable speed, high-efficiency wet rotor
circulator with ECM permanent magnet technology. Its ECM performance
is equivalent to the legendary 007 and is ideal for open loop potable hot
water systems with up to 500 feet of recirculation piping. It reduces power
consumption by up to 85% compared to equivalent AC permanent split
capacitor circulators.
APPLICATION:
• Maximum operating pressure: 150 psi (10 bar)
• Maximum water temperature: 230˚F (110˚C)
• Electrical specifications:
Voltage: 110-120V, 50/60 Hz, single phase
Maximum operating power: 44W
Maximum amp rating: 0.54
• Equipped with a stainless steel casing with
4-bolt universal flanges or 1" union connections
• Use on open loop potable hot water recirculation
systems with up to 500 feet of pipe or closed loop
hydronic heating systems
• Not suitable for chilled water systems
• Taco circulator pumps are for indoor use only
– employer uniquement a l'interieur
• Acceptable for use with water or maximum of
50% water/glycol solution
FEATURES:
• ECM performance equivalent to Taco's legendary 007 circulator
• Use with Taco SmartPlug Instant Hot Water Control® for hot water when you need it
• Multi-color LED showing operating mode and error code diagnostics
• 4-bolt universal flange or 1" Union connection, stainless steel casing
- Nut-capture feature on flanges for easier fit-up
- Optional 1/2" & 3/4" union fitting sets available - sweat, NPT or press (sold separately)
• Dual electrical knockouts and 6" stranded wire leads for easy wiring
• Double insulated - no ground-wire required
• Integral Flow Check (IFC®) included - Field installed
• Whisper quiet operation
• SureStart® - automatic unblocking and air purging mode
• Green Mode active system monitoring and power optimization
Stainless Steel, Variable Speed
®
High-Efficiency ECM Circulator
Instruction Sheet
-1-
EFFECTIVE: February 23, 2021
Figure 1:
Model# 007e-SF4
Model# 007e-SU
Certified to
NSF/ANSI 61 & 372
102-563
