Taco Comfort Solutions 0018e-SF4 Instruction Sheet

SUPERSEDES: New
Plant ID No. 001-5025
DESCRIPTION:
The 0018e® stainless steel is a variable speed wet rotor circulator with an ECM, permanent
magnet motor. Operating modes include infinitely variable fixed speed, constant pressure,
proportional pressure, and activeADAPT™ self-adjusting proportional pressure. Adjust the
operating mode with the dial or the Taco 0018e™ ECM Circulator Mobile App using Bluetooth®
connectivity on your smartphone or tablet. The ECM high-efficiency motor reduces power
consumption by up to 85% compared to equivalent AC permanent split capacitor circulators.
APPLICATION:
• Maximum operating pressure: 150 psi (10 bar)
• Maximum water temperature: 230˚F (110˚C)
• Electrical specifications:
Voltage: 110-120V, 50/60 Hz, single phase
Maximum operating power: 44W
Maximum amp rating: 0.54
• Equipped with a stainless steel casing with
4-bolt universal flanges or 1" union connections
• Use on open loop potable hot water recirculation
systems with up to 1000 feet of pipe or closed loop
hydronic heating systems
• Not suitable for chilled water systems
• Taco circulator pumps are for indoor use only – employer uniquement a l'interieur
• Acceptable for use with water or maximum of 50% water/glycol solution
FEATURES:
• 3 operating modes in dial activation:
- Proportional pressure ( TRV - Panel Radiator ), variable speed - 2 variable
pressure differential settings (Med or High)
- Constant pressure ( ZV - Zone Valve ), variable speed - 2 constant pressure
differential settings (Med or High)
- Fixed speed ( ZONE CIRC - zoning with circulators ) - infinitely adjustable
MIN/MAX settings
• 4 operating modes in 0018eTM Mobile App activation:
- Fixed Speed - infinitely adjustable MIN/MAX settings
- Constant Pressure - variable speed - 9 constant pressure differential settings
- Proportional Pressure - variable speed - 9 variable pressure differential settings
- activeADAPT™ - Designed for constant circulation systems.
Automatically adjusts to system conditions
• Multi-color LED display showing operating mode and error code diagnostics
• Nut capture feature on flanges for easier fit up
• Dual electrical knockouts and 6" stranded wire leads for easy wiring
• Double insulated - no ground-wire required
• Whisper quiet operation
• SureStart® - automatic unblocking and air purging mode
• 4-bolt universal flange or 1" union connection, stainless steel casing
- Optional 1/2" & 3/4" union fittings sets available - sweat, NPT or press (sold separately)
• Integral Flow Check (IFC®) included - Field installed
Stainless Steel, Variable Speed
High-Efficiency ECM Circulator
Featuring Bluetooth® Communication
Instruction Sheet
-1-
EFFECTIVE: February 23, 2021
Figure 1:
Model# 0018e-SF4
Model# 0018e-SU
Certified to
NSF/ANSI 61 & 372
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any
use of such marks by Taco Comfort Solutions is
under license.
102-565
