QuickSpecs
Overview
W h a t ' s N ew
Intel Mobile Pentium III 800MHz
with Speedstep™ technology or
Intel Celeron 700MHz processor
14.1-inch TFT XGA Display Panel
10GB or 15GB Hard Drive
Four Easy Access Internet
Buttons
A t A G l a n c e
Intel Mobile Pentium III 800MHz
with Speedstep™ technology
processor or Celeron 700MHz
processor
14.1-inch TFT XGA Display Panel
Configurations as light as
5.9 lbs/2.7 kg weight
1.3 in/3.4 cm thin
64MB SDRAM (100MHz),
Upgradeable to 320 MB
10GB or 15GB User Removable
Hard Drives
Integrated Mini PCI modem/NIC
combo
Full sized keyboard
Windows Millennium
2 USB port expansion options
available
Lightweight/Extended Capacity
Lithium Ion battery available
Protected by a one-year,
worldwide limited warranty —
Certain restrictions and
exclusions apply. Consult the
Compaq Customer Support
Center for details.
DA-10837
World Wide — Version 4 — June 12, 2001
Compaq Evo Notebook N150
1

Advertisement

Table of Contents
loading

Related Manuals for Compaq DA-10837

Summary of Contents for Compaq DA-10837

  • Page 1 Lightweight/Extended Capacity Lithium Ion battery available Protected by a one-year, worldwide limited warranty — Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center for details. DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150...

  • Page 2: Standard Features

    C o m m u n i c a t i o n s Type III Mini PCI Compaq Global Mini PCI 56K (V.90) Modem or Compaq 56K (V.90) Modem plus Intel PRO/100+ NIC Note: Designed only to allow faster downloads from V.90 compliant sources. Maximum achievable download Note: Modem availability is subject to country regulatory approval.
  • Page 3 P o w e r C o n s e r v a t i o n Compaq Services includes a one-year limited warranty, whole-unit replacement via second business day, pick-up S e r v i c e a n d S u p p o r t and delivery.
  • Page 4 QuickSpecs Compaq Evo Notebook N150 Standard Features The Etymology of a Model name: N a m i n g C o n v e n t i o n DA-10837 World Wide — Version 4 — June 12, 2001...
  • Page 5 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 6 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 7 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 8 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 9 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 10 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 11 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 12 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 13 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 14 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 15 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 16 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 17 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 18 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 19 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 20 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 21 Memory Optical Drive Hard Drive Modem Graphics DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM...
  • Page 22 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 23 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 24 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Pentium III 800 MHz 256KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...
  • Page 25 Hard Drive Modem Graphics Audio Software Battery DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 14.1-inch color TFT XGA Intel Celeron 700 MHz 128KB, L2 Cache 64 MB SDRAM Standard 320 MB SDRAM Maximum...

  • Page 26: Wireless Connectivity

    Memory 128-MB SDRAM Memory Module 64-MB SDRAM Memory Module (Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only Compaq branded memory modules to ensure compatibility.) Monitors Compaq TFT8020 Flat Panel Monitor 18-inch (carbon)

  • Page 27: Useful Accessories

    Compaq Workstation Case Compaq Global Case Compaq Executive Case Compaq Professional N Case Compaq Professional L Case For additional Compaq Brand cases, call 1-800-888-5903. Targus USB Port Expansion Solution Port Expansion Solutions Targus USB Port Expansion Solution DA-10837 World Wide — Version 4 — June 12, 2001...
  • Page 28 64 MB 64 MB 128 MB 64 MB 192 MB 64 MB 320 MB 64 MB Following are memory options available from Compaq: 64-MB Memory Upgrade 400312-B21 128-MB Memory Upgrade 400313-B21 256-MB Memory Upgrade 161554-B21 DA-10837 World Wide — Version 4 — June 12, 2001...
  • Page 29 System Drive Support Media 24X CD-ROM 8xDVD-ROM CD-RW Hard Drives 10-GB Hard Drive 15-GB Hard Drive DA-10837 World Wide — Version 4 — June 12, 2001 Quantity Drive Bay Supported Supported Removable Removable Removable Removable Removable Compaq Evo Notebook N150...

  • Page 30: System Unit

    Vibration Maximum Altitude (unpressurized) DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 12.2in x 9.8in x 1.3in/309mm x 248mm x 34mm 14-inch TFT with LiIon Battery 5.9 lbs/2.7 kg Nominal Operating Voltage 8 VDC...
  • Page 31 Brightness Pixel Resolution Backlight Character Display Total Power Consumption Refresh DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 8.42 x 11.22 in/21.4 x 28.5 cm 14.1 in/35.81 cm Internal 262K 180:1 150+ nit Pitch 0.279 x 0.279 mm...

  • Page 32: Hard Drives

    Width Interface Transfer Rate Seek Time (typical reads, including settling) Physical Configuration DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 10 GB 0.37 in/9.5 mm 2.5 in/63.5 mm ATA-5 UDMA 66MB/s Synchronous Single Track...
  • Page 33 DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 CD-ROM (Mode 1, 2 and 3), CD-XA ready (Mode 2, Form 1 and 2), CD-I ready (Mode 2, Form 1 and 2), CD-R (read only), CD Plus, Photo CD (Single and Multi-...

  • Page 34: External Ac Adapter

    Dimensions (HxWxD) Weight Cells Energy Temperature Compaq PCs use genuine Microsoft Windows www.microsoft.com\piracy\howtotell Microsoft and Windows are trademarks of Microsoft Corporation in the U.S. and other countries. DA-10837 World Wide — Version 4 — June 12, 2001 Compaq Evo Notebook N150 0.45 lb/0.21 kg...
