- Page 1 INSTALLATION & MAINTENANCE MANUAL LANT3 / LANT3W / LANT4 / LANT4W LANT3BKP / LANT3WP...
- Page 2 These instructions should be used to aid installation of the following products: LANT3 / LANT3W / LANT4 / LANT4W / LANT3BKP / LANT3WP SAFETY • This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671) and current Building Regulations.
- Page 3 INSTALLATION INSTALLATION • Provide power to the required point of installation (refer to BS7671 for correct cabling Provide power to the required point of installation (refer to BS7671 for correct cabling methods). • Suitable IP rated junction boxes should be used where required Suitable IP rated junction boxes should be used where required •...
- Page 4 • Refit the terminal enclosure to the baseplate • Refit the front cover • Switch on and check for correct operation PIR VERSION LANT4x The PIR is factory set as follows (these settings are not adjustable): Detection range: up to 8m Time settings: 60 seconds Lux settings: below 15 lux Detection angle: 90°...
- Page 5 WARNING This luminaire must be disconnected from the circuit if subjected to any high voltage or insulation resistance testing. Irreparable damage will occur if this instruction is not followed. GENERAL This product contains a light source of energy efficiency class D (LANT3x, LANT4x) / E (LANT3xxP) to Regulation (EU) No.
- Page 6 WARRANTY This product has a warranty of 3 years from date of purchase. Failure to install this product in accordance with the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place of purchase for a free of charge replacement.
