Outdoor Stage PAR
Quad TR1
LED PAR
user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stairville Quad TR1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for thomann Stairville Quad TR1

Summary of Contents for thomann Stairville Quad TR1

  • Page 1 Outdoor Stage PAR Quad TR1 LED PAR user manual...
  • Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 27.01.2022, ID: 515364, 518078 (V2)

  • Page 3: Table Of Contents

    Table of contents Table of contents General information..........................5 1.1 Further information........................... 6 1.2 Notational conventions........................7 1.3 Symbols and signal words....................... 8 Safety instructions..........................11 Features............................... 15 Installation..............................17 Starting up..............................21 Connections and controls........................24 Operating..............................30 7.1 Operating on the unit........................30 7.2 Menu overview..........................
  • Page 4 Table of contents Technical specifications........................59 Plug and connection assignments....................62 Troubleshooting............................63 Cleaning............................... 65 Protecting the environment......................66 LED PAR...

  • Page 5: General Information

    Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. Outdoor Stage PAR Quad TR1...

  • Page 6: Further Information

    General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly.

  • Page 7: Notational Conventions

    General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Displays Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’...

  • Page 8: Symbols And Signal Words

    General information Instructions The individual steps of an instruction are numbered consecutively. The result of a step is indented and highlighted by an arrow. Example: Switch on the device. Press [Auto]. ð Automatic operation is started. Switch off the device. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual.
  • Page 9 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
  • Page 10 General information Warning signs Type of danger Warning – dangerous optical radiation. Warning – suspended load. Warning – danger zone. LED PAR...

  • Page 11: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended for use as an electronic lighting effect by means of LED technology. The device is designed for professional use only and is not suitable for use in households. Use the device only as described in this user manual.
  • Page 12 Safety instructions Safety DANGER! Danger for children Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and choke! Never let children unattended use electrical devices.
  • Page 13 Safety instructions WARNING! Risk of epileptic shock Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at strobe lights. WARNING! Risk of burns The surface of the device can become very hot during operation. Do not touch the device with bare hands during operation, and after switching off wait for at least 15 minutes.
  • Page 14 Safety instructions NOTICE! Fire hazard due to exceedance of the maximum current The device can power other devices of identical construction. The current consumption of all other devices connected in series must not exceed the values indicated in the technical specifications. Otherwise you risk injuries and irreparable damages to the device. Only connect so many identical devices that the maximum current consumption is not exceeded.

  • Page 15: Features

    Features Features The Outdoor Stage Par Quad TR1 is due to its sturdy and weather-proof housing made of die- cast aluminium especially suitable for outdoor use. With its 12 LEDs, it is particularly suitable for ambient lighting or open-air stages. 12 ×...
  • Page 16 Features Information about protection Equipment with protection class IP65 are dust-tight and completely protected against contact class IP65 (first code number). They are also protected against splash water from any angle (second code digit). That is why this equipment can also be used outdoors. Event technology equipment is generally only designed for temporary use however (event lighting) and not for permanent use outdoors.

  • Page 17: Installation

    Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 18 Installation NOTICE! Risk of overheating Always ensure sufficient ventilation. The ambient temperature must not exceed the limits stated in the chapter Tech‐ nical Specifications of the User Manual. NOTICE! Use of stands When mounting the device onto a stand, ensure that the stand is in a safe and stable position and that the weight of the device does not exceed the maximum permissible load capacity of the stand.
  • Page 19 Installation NOTICE! Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi‐ nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. Mounting options You can install the unit in hanging or standing position.
  • Page 20 Installation Please note that this device must not be connected to a dimmer. LED PAR...

  • Page 21: Starting Up

    Starting up Starting up Create all connections while the device is off. Use the shortest possible high-quality cables for all connections. Take care when running the cables to prevent tripping hazards. Outdoor Stage PAR Quad TR1...
  • Page 22 Starting up Connections in DMX mode Connect the DMX input of the device to the DMX output of a DMX controller or another DMX device. Connect the output of the first DMX device to the input of the second one, and so on to form a daisy chain.
  • Page 23 Starting up Connections in ‘Master / When you configure a group of devices in ‘Master / Slave’ mode, the first unit will control the Slave‘ mode others. This feature is especially useful to start a show without much programming. Connect the DMX output of the master unit to the DMX input of the first slave unit.

  • Page 24: Connections And Controls

    Connections and controls Connections and controls ö & MODE DOWN LED PAR...
  • Page 25 Connections and controls 1 Two-piece bracket for hanging or floor setup 2 Locking screws for the two-piece bracket 3 Infrared sensor for the optionally available remote control 4 Display 5 [MODE] Activates the main menu, toggles between the menu items or closes a submenu. [SET] Opens a submenu or confirms a value.
  • Page 26 Connections and controls 8 [DMX In] DMX input, designed as 3-pin XLR panel plug (IP65) 9 [DMX Out] DMX output, designed as 3-pin XLR panel socket (IP65) 10 [Power In] Input socket (Power Twist TR1) for powering the device 11 [Power Out] Output socket (Power Twist TR1) for powering further devices LED PAR...
  • Page 27 Connections and controls Infrared remote control (item no. 354223, optionally avail‐ Since the universal remote control can be used for several device types, some buttons able) may not be assigned and therefore have no function. & ö Outdoor Stage PAR Quad TR1...
  • Page 28 Connections and controls 1 [ON/OFF] Turns the device on and off. 2 [AUTO] Activates the ‘Automatic‘ mode. 3 [PRG] Activates the operating mode ‘Preprogrammed automatic show’. Select the desired programme with [+] and [–]. 4 [SOUND] Activates the Sound-controlled mode. Set the sensitivity of the built-in microphone with [+] and [–]. 5 [SPEED] Activates the setting mode for the programme speed.
  • Page 29 Connections and controls 8 [–] Decreases the set value. 9 [Dimming] Activates the dimming function for basic colours. Set the value for each basic colour using [+] and [–]. 10 [0 … 9] Numeric buttons for direct selection of a basic colour. 11 [R], [G], [B], [A], [W] Buttons to select the colour shade in dimmer mode.

  • Page 30: Operating

    Operating Operating 7.1 Operating on the unit 7.1.1 Navigating in the menu Connect the device to the power supply to start operation. After a few seconds, the display shows the software version of the device. The device is then ready for use. All set values are retained even when you switch the device off and disconnect it from the mains.
  • Page 31 Operating If you do not press any key for about 30 seconds, the display will automatically be locked. The display shows the current operating mode, the software version and the device temperature. To cancel the lock, hold down [MODE] and [SET] simultaneously for three seconds.
  • Page 32 Operating Make sure that this number matches the configuration of your DMX controller. The following table shows the highest possible DMX address for the various DMX modes. Mode Highest possible DMX address 4-channel 6-channel 9-channel DMX mode Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘DMX’...
  • Page 33 Operating 7.1.3 Operating mode ‘Slave’ In this mode, the device follows exactly the operation of the master that it is connected to. This setting is only relevant if the device is not controlled via DMX. Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘Slave’...
  • Page 34 Operating Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘Auto’ . Confirm the selection with [SET] and use [UP] or [DOWN] to choose between ‘Yes’ (Auto mode on) and ‘No’ (Auto mode off). To exit the menu item without making changes, press [MODE].
  • Page 35 Operating Settings for program 01 Static colours When you have selected programme ‘01’ , you can use [SET] and use [UP] or [DOWN] to select the menu item ‘Color’ . Confirm the selection with [SET] and use [UP] or [DOWN] to select a static colour in the range of ‘00’...
  • Page 36 Operating Settings for Programm 02 … 17 Programme running speed If you have selected a programme ‘02’ … ‘17’ , press [SET] and use [UP] or [DOWN] to select the menu item ‘Speed’ . Confirm the selection with [SET] and use [UP] or [DOWN] to set the programme running speed in a range from ‘001’...
  • Page 37 Operating 7.1.6 Selecting and configuring user programmes Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘User Program’ . Confirm the selection with [SET] and use [UP] or [DOWN] to select the menu item ‘Program’...
  • Page 38 Operating Individual settings Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘User Program’ . Confirm the selection with [SET] and use [UP] or [DOWN] to select the menu item ‘Edit’ and confirm the selection with [SET]. Use [UP] or [DOWN] to select the desired sub menu you want to edit and confirm the selection with [SET].
  • Page 39 Operating Menu level 3 Menu level 4 Description ‘Fade Time’ ‘00s…20s’ Fade time from 0 seconds to 20 seconds ‘Wait Time’ ‘00.0s…40.0s’ Wait time from 0 seconds to 40 seconds To exit the menu item without making changes, press [MODE]. Playing user programmes Press [MODE] to activate the main menu.
  • Page 40 Operating 7.1.7 Dimmer settings Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘Dimmer’ . Use [UP] or [DOWN] to select the desired sub menu you want to edit and confirm the selection with [SET]. The following sub menus are available: Menu level 2 Menu level 3...
  • Page 41 Operating 7.1.8 System settings 7.1.8.1 Setting the dimmer curve Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘Settings’ . Confirm the selection with [SET] and use [UP] or [DOWN] to select the menu item ‘Curves Select’...
  • Page 42 Operating 7.1.8.2 Setting the dimmer speed Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘Settings’ . Confirm the selection with [SET] and use [UP] or [DOWN] to select the menu item ‘Dimmer Speed’ and confirm the selection with [SET]. Use [UP] or [DOWN] to choose between ‘Fast’...
  • Page 43 Operating 7.1.8.3 Rotating the Display Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘Settings’ . Confirm the selection with [SET] and use [UP] or [DOWN] to select the menu item ‘Display’ and confirm the selection with [SET]. Use [UP] or [DOWN] to choose between ‘Normal’...
  • Page 44 Operating 7.1.8.4 PWM (pulse width modulation) Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘Settings’ . Confirm the selection with [SET] and use [UP] or [DOWN] to select the menu item ‘PWM Frequency’ and confirm the selection with [SET]. Use [UP] or [DOWN] to choose between ‘12K’...
  • Page 45 Operating 7.1.8.5 Behaviour on DMX control failure Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘Settings’ . Confirm the selection with [SET] and use [UP] or [DOWN] to select the menu item ‘Dmx Fail’...
  • Page 46 Operating 7.1.8.6 DMX synchronisation Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘Settings’ . Confirm the selection with [SET] and use [UP] or [DOWN] to select the menu item ‘Dmx Sync’ and confirm the selection with [SET]. Use [UP] or [DOWN] to choose between ‘On’...
  • Page 47 Operating 7.1.8.7 Display lighting Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘Settings’ . Confirm the selection with [SET] and use [UP] or [DOWN] to select the menu item ‘Lock’ and confirm the selection with [SET]. Use [UP] or [DOWN] to choose between ‘On’...
  • Page 48 Operating 7.1.8.8 Resetting the device to factory defaults Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘Settings’ . Confirm the selection with [SET] and use [UP] or [DOWN] to select the menu item ‘Factory’...
  • Page 49 Operating 7.1.9 System information Press [MODE] to activate the main menu. Press repeatedly [MODE] and select the menu item ‘Information’ . Confirm the selection with [SET]. Use [UP] or [DOWN] to select between ‘Version’ (firmware version), ‘PowerTime’ (oper‐ ating hours), ‘LED Time’ (LED runtime) and ‘UID’ (serial number) and display the relevant information.

  • Page 50: Menu Overview

    Operating 7.2 Menu overview Slave Auto Program User Program Dimmer Settings Information Address Mode Program Curves Select Version PowerTime LED Time Color Edit Step Green Fast Dimmer Speed Channels 4-ch Smooth 6-ch Display Normal 9-ch Speed Blue Inverted Green Blue Strobe White White...

  • Page 51: Functions In 4-Channel Dmx Mode

    Operating 7.3 Functions in 4-channel DMX mode Channel Value Function 0…255 Intensity red (0 % to 100 %) Intensity green (0 % to 100 %) 0…255 Intensity blue (0 % to 100 %) 0…255 0…255 Intensity white (0 % to 100 %) Outdoor Stage PAR Quad TR1...

  • Page 52: Functions In 6-Channel Dmx Mode

    Operating 7.4 Functions in 6-channel DMX mode Channel Value Function 0…255 Dimmer (0 % to 100 %) Intensity red (0 % to 100 %) 0…255 Intensity green (0 % to 100 %) 0…255 0…255 Intensity blue (0 % to 100 %) 0…255 Intensity white (0 % to 100 %) 0…10...

  • Page 53: Functions In 9-Channel Dmx Mode

    Operating 7.5 Functions in 9-channel DMX mode Channel Value Function 0…255 Dimmer (0 % to 100 %) Intensity red (0 % to 100 %) 0…255 Intensity green (0 % to 100 %) 0…255 0…255 Intensity blue (0 % to 100 %) 0…255 Intensity white (0 % to 100 %) Colour selection...
  • Page 54 Operating Channel Value Function 40…45 Red (255), green (170), blue (000), white (000) 46…51 Red (255), green (210), blue (000), white (000) 52…57 Red (255), green (255), blue (000), white (000) 58…63 Red (200), green (255), blue (000), white (000) 64…69 Red (160), green (255), blue (000), white (000) 70…75...
  • Page 55 Operating Channel Value Function 118…123 Red (000), green (255), blue (255), white (000) 124…129 Red (000), green (100), blue (255), white (000) 130…135 Red (000), green (000), blue (255), white (000) 136…141 Red (020), green (000), blue (255), white (000) 142…147 Red (050), green (000), blue (255), white (000) 148…153...
  • Page 56 Operating Channel Value Function 196…201 Red (255), green (000), blue (007), white (000) 202…207 Red (000), green (000), blue (000), white (255) 208…213 Red (255), green (000), blue (000), white (255) 214…219 Red (125), green (000), blue (000), white (255) 220…225 Red (000), green (255), blue (000), white (255) 226…231...
  • Page 57 Operating Channel Value Function 38…48 Programme 04 49…59 Programme 05 60…70 Programme 06 71…81 Programme 07 82…92 Programme 08 93…103 Programme 09 104…114 Programme 10 115…125 Programme 11 126…136 Programme 12 137…147 Programme 13 Programme 14 148…158 Programme 15 159…169 170…180 Programme 16 Outdoor Stage PAR Quad TR1...
  • Page 58 Operating Channel Value Function 181…191 Programme 17 192…202 User programme 01 203…213 User programme 02 214…224 User programme 03 225…235 User programme 04 236…255 User programme 05 0…255 Programme running speed (programme 02…programme 17), increasing speed 0…10 No function 11…255 Stroboscope effect (0 % to 100 %), not for user programmes 01…05 LED PAR...

  • Page 59: Technical Specifications

    Technical specifications Technical specifications Light source 12 × 4in1 RGBW LED, 4 W each Light source properties Colour temperature 100000 K Colour rendering index CRI 59 Optical properties Beam angle 25° Dimmer electronic, 0 %…100 % 246 mm Shutter electronic, 0 Hz…20 Hz Control DMX, buttons and display on the unit, IR remote control Number of DMX channels...
  • Page 60 Technical specifications DMX control XLR panel socket (IP65), 3-pin Power consumption max. 50 W Operating supply voltage 100 - 240 V 50/60 Hz Remote control battery Lithium-ion button cell CR2025, 3 V Protection class IP65 Mounting options hanging Dimensions (W × H × D) 246 mm ×...
  • Page 61 Technical specifications Further information Outdoor housing shape Studio housing Colour mixture RGBW LED type x-in-1 Floor housing Fanless Remote control Optionally available (item no. 354223) Wireless DMX Housing colour black (item no. 518078) White (item no. 515364) Outdoor Stage PAR Quad TR1...

  • Page 62: Plug And Connection Assignments

    Plug and connection assignments Plug and connection assignments Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment so that a perfect light experience is guaranteed. Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into a socket, the result of an incorrect connection may be a destroyed DMX controller, a short circuit or ‘just’...

  • Page 63: Troubleshooting

    Troubleshooting Troubleshooting NOTICE! Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi‐ nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. In the following we list a few common problems that may occur during operation.
  • Page 64 4. Check to see if the DMX cables run near or alongside to high voltage cables that may cause damage or interfer‐ ence to DMX interface circuits. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. LED PAR...

  • Page 65: Cleaning

    Cleaning Cleaning Optical lenses Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the light output. The frequency of cleaning depends on the operating environment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the optics of the device.

  • Page 66: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 67 Protecting the environment Disposal of your old device This product is subject to the European Waste Electrical and Electronic Equipment Directive (WEEE) in its currently valid version. Do not dispose with your normal household waste. Dispose of this device through an approved waste disposal firm or through your local waste facility.
  • Page 68 Notes LED PAR...
  • Page 69 Notes Outdoor Stage PAR Quad TR1...
  • Page 70 Notes LED PAR...
  • Page 72 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
